PROFESSIONAL 2-WAY LCD REMOTE CAR STARTER & ALARM SYSTEM
With
Built in Temperature, Voltage Sensor
And Two-way Serial Port Data Link
OPERATION MANUAL
THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY
Congratulations on your purchase of the RS-730 LCD remote start vehicle security system. We sincerely hope the purchase
of the RS-730 remote start security system gives peace of mind to you.
The RS-730 LCD is a state-of-the-art two-way communication system. Please take the time to read over this manual to
thoroughly familiarize your self with the many features and options of the RS-730 LCD.
Auto Page, Inc. has over 25 years of experience in the vehicle security industry in the United States and is a wholly owned
subsidiary of Iwata Electric Co., of Tokyo, Japan. Iwata has been an industry leader for over 50 years, establishing a
reputation for ingenuity in its engineering capability and innovative communication products. Auto Page and Iwata maintain a
long tradition of providing the best value to their customers.
WARNINGS:
As with any product that performs automatic functions, there are certain safety precautions that you must practice and be
aware of.
1. Keep the transmitter out of children's reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it's in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is corrected.
8. The use and operations of this system is the sole responsibility of the operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle running on public streets.
10.It is not safe to remote start the vehicle if the vehicle is parked on a steep incline.
1
Advertisement
Table of Contents
Related Manuals for Auto Page RS-730
Summary of Contents for Auto Page RS-730
- Page 1 RS-730 LCD. Auto Page, Inc. has over 25 years of experience in the vehicle security industry in the United States and is a wholly owned subsidiary of Iwata Electric Co., of Tokyo, Japan. Iwata has been an industry leader for over 50 years, establishing a reputation for ingenuity in its engineering capability and innovative communication products.
-
Page 2: Battery Replacement
May/31/2009 LCD REMOTE CONTROL TRANSCEIVER : XT-74 LCD A. BATTERY REPLACEMENT: This system needs no specific maintenance beyond remote control battery replacement. The 2-way remote is powered by a 1.5V AAA battery. The 1-way remote is powered by a pair of 3V, CR2016 batteries. Battery Level Indicator (2-way remote) The Battery Level indicator has three level indicators that serve as a visual indication of battery charge. -
Page 3: Remote Transmitter Operation
May/31/2009 Remote Transmission In – Range Indicator You are within the range of the remote You are transmitting the signal to control. control unit Anti Car-Jack Mode Icon flash under check mode Activate the anti car-jacking mode Engine Cranking Engine Running Your vehicle engine Cranking by Your vehicle's engine is running remote control... -
Page 4: Active Disarming - Unlock & Disarm
May/31/2009 CHIRP INDICATORS: PARKING LIGHT: Chirp Function Parking light Function 1 chirp 1 flash 2 chirps 2 flashes Disarm Disarm 3 chirps 3 flashes Defective Reminder Disarm / Triggered 4 chirps 12 flashes Disarm / Triggered Car Locator 6 chirps Constant On Car Locator Under Remote Start... -
Page 5: Disarming Without A Transmitter
May/31/2009 TAMPER DISARMING: If the alarm is triggered, upon disarm the system’s siren will chirp 4 times, and the parking lights will flash 3 times telling you the alarm has been triggered during the last armed state. PATHWAY ILLUMINATION: When receiving an unlock /disarm signal, this feature will turn the parking lights “ON” for 30 seconds and for 10 seconds upon the lock signal. -
Page 6: Car Locator
May/31/2009 J. CAR LOCATOR Under armed mode, press the button to active car locator function. The siren will chirp 6 times. The parking light will flash 12 times, for you to easily locate your car. K. PANIC FUNCTION: The transmitter can be used as a remote panic switch to manually trigger the alarm in case of emergency. 1. - Page 7 May/31/2009 OVERRIDE THE SYSTEM TO TURN OFF ANTI CAR- JACKING: Turn the ignition switch from OFF to ON, and within 10 seconds push valet switch, the siren will stop and the system disarmed Note: If you use password pin code to double protect the vehicle security, you will need to use it to completely disarm the system.
- Page 8 May/31/2009 Standard Transmitter 1. Prior to pushing any button on the transmitter. Press the Select II II II II button first on the transmitter. 2. Once II II II II button is pressed the LED on the transmitter will illuminate for 3 seconds to indicate the second transmitter pin code has built-in.
-
Page 9: Temporary Stop Feature
May/31/2009 C. TEMPORARY STOP FEATURE: This feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate control on. - Page 10 May/31/2009 ” Press and hold the transmitter “ button first until 3 chirps are heard. Then press the Button three more times so that TEMP appears on the remote. Within 3 seconds press button; the in-door temperature will be shown on the LCD screen.
- Page 11 May/31/2009 Button for 2 second mode until 2 beeps sounded CH 4 Press one more time flashing Press button to activate channel within 5 seconds 4 function Table 3:THREE beeps to confirm(Press and hold until THREE Beeps are heard) Button LCD display Button STATUS...
- Page 12 May/31/2009 Parking Menu Default is PARK METER 0:30 - Parking hours - Adjusts parking hour 0 is flashing (value from 0 to 2). 0:30 - Parking - Adjusts parking minute 30 is flashing minutes (value from 0 to 59). - Toggle - Enables parking countdown.
- Page 13 May/31/2009 Power Save Default is - Toggle power - While the power save mode, the LCD save remote transceiver uses “0” current to save the battery power. - Power save OFF Exit: Press any button of the LCD remote transmitter to exit the “Power Save Mode”. Daily Start Timer Daily Start Time Adjust Only (ex.
- Page 14 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
