Auto Page RS-8601cd Operation Manual

Professional remote car starter with alarm system & 2-way lcd communication
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
RS-860lcd
PROFESSIONAL REMOTE CAR STARTER
WITH ALARM SYSTEM
&
2-WAY LCD COMMUNICATION
OPERATION MANUAL
THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-8601cd and is the answer not in the manual?

Questions and answers

Related Manuals for Auto Page RS-8601cd

Summary of Contents for Auto Page RS-8601cd

  • Page 1 RS-860lcd PROFESSIONAL REMOTE CAR STARTER WITH ALARM SYSTEM & 2-WAY LCD COMMUNICATION OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS: LCD REMOTE TRANSMITTER: A. REMOTE TRANSMITTER OPERATION…………………………….…4 B. BATTERY REPLACEMENT ………………………………………..….. 5 C. THE REMOTE LCD ICONS WITH FUNCTION ……………..…...…...6 C. PROGRAMMING OF THE LCD REMOTE TRANSMITTER ………...7 1. Screen Lamp ON 2. Power Save Mode 3. Clear The Flash Icon and Melody Sound 4.
  • Page 3 Daily Timer Start Exit the Timer Start F. TEMPERATURE CHECK …………………….….……….…….…..… 24 G. TO TURN OFF THE REMOTE START ………………………..…...…24 H. SHUT-DOWN INPUT FOR REMOTE STARTER ………...……...… 24 I. DISABLING THE REMOTE START SYSTEM …………………...…. 25 WARRANTY PROVISSIONS……………………………………………….26 WARRANTY CARD…………………………………………………………..27...

  • Page 4: Lcd Remote Transmitter

    WARNINGS: As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of. 1. Keep the transmitter out of children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3.

  • Page 5: Battery Replacement

    A. BATTERY REPLACEMENT: A 1.5V type AAA Alkaline battery powers the Remote Transmitter. When the power of the battery weakens a icon shall be displayed on the LCD screen. When the old battery is replaced to new one, there will be beep sounds indicate the power is up and the clock on the LCD screen returns to AM12:00 after displaying all the icons.

  • Page 6: The Remote Lcd Icons With Function

    B. THE REMOTE LCD ICONS WITH FUNCTION: Door Lock Your vehicle doors are locked Armed Mode Your vehicle is in armed mode Remote Transmission You are transmitting the signal to control unit Door Open Warning Doors are illegally opened (Zone 3) Shock Sensor Trigger Trigger on Shock Sensor (Zone 4)

  • Page 7: C: Programming Of The Lcd Remote Transmitter

    C: PROGRAMMING OF THE LCD REMOTE TRANSMITTER: Transmitter Button Description LCD screen lamp turns on (1 second) 5 seconds. Timer Programming Mode. (3 seconds) Power Save Mode (5 seconds) Clear the Flash Icon and Melody Sound on the LCD Screen Transmitter (2-second) Button Lock ( disable...

  • Page 8: Vibration / Melody Mode

    5. Button Lock: It is useful if you want to disable the transmission function of the remote control temporarily to prevent from any inadvertent pressing of buttons by others. Press the button first, within 3 seconds press and hold the ( ) button for 2 seconds to activate or cancel the button lock function, the icon will displayed on the LCD screen to show...

  • Page 9: D.clock & Timer Setting

    D. CLOCK & TIMER SETTING: Transmitter Button Description Clock Setting (Hour) Press & Hold the *Flash digit for adjusting button until hour flashes Time setting (Minute) Press the button *Flash digit for adjusting once Alert Alarm Time Setting Press the button (Hour) once.
  • Page 10 2. Alert Alarm Timer Setting: Example to PM 6:30 1. Press & hold the button for 3 seconds, with two-melody sound and the “Hours” digit flashes for adjusting. 2. Press the button twice, the LCD screen will shows digit is flashing for adjustment. 3.

  • Page 11: Time Set-Up For "Daily Timer Start

    4. Time Set-Up For “Daily Timer Start”: Example to AM 6:30 1. Press & hold the button for 3 seconds, with two-melody sound and the “Hours” digit flashes for adjusting. 2. Press & hold the button for 2 seconds, the LCD screen will flash icon and “Hours”...

  • Page 12: Button Lock

    LCD DISPLAY TRANSMITTER OPERATION ONLY: Transmitter Button System Function System’s Trigger Record Check System’s Status Check Button Lock Optional Driving Pager Monitor Indoor Temperature Daily Timer Start LCD screen lamp turns on for 5 seconds. Clear the Flash Icon and Melody Sound on the LCD Screen Transmitter Warning: Press the...

  • Page 13: Led Display

    C. LED display: Function Disarmed Slow Flash Armed Flash Passive Starter Disable Fast Flash Passive Arming On (Solid) Valet Mode D. CHIRP INDICATORS: Chirp Function 1 chirp 2 chirps Disarm 3 chirps Defective Reminder 4 chirps Disarm / Triggered 6 chirps Car Locator F.

  • Page 14: Passive Arming

    System Arm Door Ajar DEFECTIVE SENSOR REMINDER: If the siren sounds 3 chirps, then you have left a door, trunk, or hoodlid ajar. SILENT ARMING / DISARMING: Press the transmitter the same time will arm or disarm your security system, No chirp sound will be heard, arm / disarm confirmation will be through the vehicles parking lights only.

  • Page 15: Two Steps Door Unlock

    System Disarm Doors Trigger Shock SensorTrgr Ignition Trigger TAMPER DISARMING: If alarm is triggered upon disarm, the systems siren will chirp 4 times, and parking light flash 3 times. PATHWAY ILLUMINATION: This feature turns the parking light seconds upon a unlock signal and for 10 seconds upon the lock signal. TWO STEPS DOOR UNLOCK: This feature will independently unlock the driver’s door only when disarming the security system.

  • Page 16: Valet Mode

    4. Within 15 seconds, enter your chosen of the second digit code by pressing and releasing the Valet Switch. 5. Turn the ignition switch “OFF” position. 4] Chirps form siren/horn, [3] flash from parking light to indicate the system was disarmed. Note 1: You must override the alarm within 60 seconds.

  • Page 17: Trigger The System

    1. Press and hold the button for 3 second. The alarm will immediately sound. 2. During panic mode, the normal function of this transmitter button will be disabled. The transmitter buttons can be used to lock and unlock the door (if the option is installed), however once the button is pressed, the vehicle’s starter disable device, (where installed) will be disengaged allowing the vehicle to start.

  • Page 18: Anti Car- Jacking

    Circuit” will interpret this pattern of triggers as false alarm. After the third trigger, “Noise Abatement Circuit” ignores, or bypasses, that sensor or switch until the other sensor or switch is trigger. “Noise Abatement Circuit” covers doors (Hood/Trunk) differently: If the alarm is triggered by an open door for three full cycles, the doors will be bypassed until the trigger ceases.

  • Page 19: System's Trigger Check

    P. SYSTEM’S TRIGGER CHECK Press the transmitter first, within 3 seconds press (C) button. It responds with one melody sound and all trigger’s records will immediately displayed on the LCD screen. Q. SYSTEM’S STATUS CHECK When you want to check the system’s present status through the LCD screen, Press the transmitter button twice, within 3 seconds press It responds with one melody sound.

  • Page 20: Dome Light Convenience Delay & Supervision

    S. DOME LIGHT CONVENIENCE DELAY & SUPERVISION The alarm with a unique feature which will turn on your vehicle dome light as following: 1. Upon disarming, the interior light will remain on for 30 seconds. 2. If the vehicle is intruded, the interior light will flash for the same duration as the siren.

  • Page 21: Second Vehicle Security Operation

    Y. SECOND VEHICLE SECURITY OPERATION: Your 5-button remote transmitter can be utilized to control a second vehicle security system, To program the remote control transmitter to a second vehicle, follow the instructions for Transmitter programming. Programming the Transmitter to 2 Enter: Turn the ignition key ON 3 times.

  • Page 22: Remote Start Operation

    REMOTE START OPERATION: A. TO REMOTE START THE VEHICLE: When you want to start your vehicle, 1. Press button once on the transmitter. 2. The parking light will activate to indicate the remote start received the signal. 3. The engine will start approximately 5 seconds. 4.

  • Page 23: 3 Hours Timer Start With Temperature-Control Off

    Turbo charge mode keeps the engine running after arriving at your destination for a programmable period of 1, 3 or 5 minutes, This allows the vehicle’s engine time to conveniently cool down the turbo after you have left the vehicle. To activate: 1.

  • Page 24: Temperature Check

    Press the brake pedal The vehicle will shut down and turn off to indicate engine stopped. the parking light H. SHUT-DOWN INPUT FOR REMOTE STARTER: If any of the following conditions exist while the system is operating, the engine will not start or will shut down immediately: 1.

  • Page 25: Disabling The Remote Start System

    4. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed. Press button once on the remote transmitter under remote start mode. 6. Move the optional remote start enable toggle switch to OFF position. (If installed) 7. The vehicle refused to start running after {3} unsuccessful attempts. I.

  • Page 26: Warranty Provissions

    After one (1) year, the purchaser should ship the unit prepaid to Auto Page with a money order in the amount of $30.00 to cover shipping and handling charges. Note: The enclosed Warranty Card may be required to receive warranty services.

  • Page 27: Warranty Card

    This WARRANTY CARD is for your record. However, Autopage reserves the right to request you to submit this WARRANTY CARD, which must have complete information to receive warranty service. Please keep this card in a secured place. AUTOPAGE WARRANTY SERVICE CARD _______________ Model: Serial # _______________...
  • Page 28 960 Knox Street Unit B Torrance, California 90502 Main Office: 310-323-1800 Customer Service: 800-262-2527 Ext. 462 www.autopageusa.com...
