Summary of Contents for HY-LINE CLUX-1CAT4H
- Page 1 CLUX-1CAT4H 1 by 4 CAT6 to HDMI V1.3 Splitter Operation Manual CLUX-1CAT4H...
- Page 3 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Pin Definitions ……………...……..........…… IR Cable Pin Definition ............RJ-45 Pin Definitions..............Connection and Installation ….…………………..…..…..…..Acronyms ….................. -
Page 6: Introduction
1. Introduction The 1 by 4 CAT6 to HDMI 1.3 splitter is the smart way to link and display a single HDMI source on three or more screens simultaneously. Not only can it send an HDMI source to three different displays, but it can also act like a router, when connected to another CAT6 splitter it can transfer an HDMI signal to a further 3 displays, making a total of six showing the same source instead of only three. -
Page 7: Features
5. Features HDMI 1.3, HDCP1.1 and DVI1.0 compliant Deep color video up to 12bit, 1080p@60Hz Allows users to link up to three displays simultaneously HDCP keysets allows each output to work independently when connected to an HDMI display Supports both DVI source/display by using an HDMI to/from DVI adaptor ... -
Page 8: Specifications
6. Specifications Video Bandwidth 2.25Gbps (single link) Input Ports 1 x CAT6 input Video/1 x CAT6 input DDC Output Ports 1 x CAT6 output Video/1 x CAT6 output DDC 3 x HDMI female ports (Type A connector) EDID STD / TV HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.1, DD+, D-TrueHD, DTS-HD... -
Page 9: Operation Controls And Functions
7.1 Front Panel HDMI CAT 6 POWER HDMI / DVI HDCP SYNC CLUX-1CAT4H 1x4 CAT6 HDMI 1.3 SPLITTER ① ② ③ ④ ⑤ ① HDMI/DVI indicators: When LED turns on this means the input source is with HDMI content and when the input source is DVI the LED will not switch on. - Page 10 ③ EDID Control Switcher: Switch the EDID between STD & TV. Switch to STD to use the built-in EDID or switch to TV to use TV ’ s EDID. Default factory setting is on TV, leave as is when the display is working properly. Note: 1.
-
Page 11: Pin Definitions
8. Pin Definitions 8.1 IR Cable Pin Definitions IR Blaster IR Receiver ① Power 5V ① IR signal ② IR blaster signal ② Power 5V ③ NC ③ Grounding ① ② ③ ① ② ③ Note: The frequency on both IR Receiver & Blaster can support 20~60KHz. 8.2 RJ-45 Pin Definitions Video TX2+... - Page 13 60°...
-
Page 14: Acronyms
Acronyms Acronym Complete Term CAT6 Category 6 cable Digital Visual Interface EDID Extended Display Identification Data HDCP High-Bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television Infrared LPCM Linear Pulse Code Modulation Standard SYNC Synchronize SXGA Super Extended Graphics Array Video Graphics Array... - Page 16 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20091208 MPM-CLUX1CAT4H...
