- Page 1 CP-1262HST HDMI to PC/Component Converter with Audio Box Operation Manual CP-1262HST...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 3 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Operation Controls and Functions ..........4 Front Panel ..............4 Rear Panel .............. -
Page 5: Introduction
1. Introduction This converter box is designed to convert HD signal to Analog PC or SD/HD timings. It enables to convert HDMI sources to any analog PC timing for PC monitor, Projector or TV. Its high bandwidth capability supports a wide range of PC and HDTV resolutions. -
Page 6: Specifications
• HD: 480i@60, 480p@60, 576i@50, 576p@50, 720p@50, 720p@60, • 1080i@50, 1080i@60, 1080p@24, 1080p@50, 1080p@60 • HDMI input support 8-bits without Deep Color support • HDMI input compatible with DVI format when using HDMI to DVI adaptor • HDMI audio input support LPCM 2CH and sampling rate support from 32KHz to 96KHz. - Page 7 1080p@50, 1080p@60 HDMI Audio Input LPCM 2CH HDMI input Color Space RGB, YUV ESD Protection ± 8kV (air-gap discharge) ± 4kV (contact discharge) Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified) Dimensions (mm) 76(W) x 30(D) x 92(H) Weight(g) Chassis Material Aluminum Silkscreen Color Silver...
-
Page 8: Operation Controls And Functions
7.1 Front Panel HDMI In DC 5V YPbPr CP-1262HST HDMI to PC/HD . YPbPr/RGB switch: ① Set the switch to RGB when your HDMI source equipment is PC graphic card or other digital RGB source signal. Use HD-15 to HD-15 VGA cable to connect between the unit ’... -
Page 9: Hdmi Connector Pin Assignment
8. HDMI Connector Pin Assignment Pin# Function Assignment Pin# Function Assignment TMDS Data2+ TMDS Data2 Shield TMDS Data2- TMDS Data1+ TMDS Data1 Shield TMDS Data1- TMDS Data0+ TMDS Data0 Shield TMDS Data0- TMDS Clock+ TMDS Clock Shield TMDS Clock- Reserved (N.C. on device) DDC/CEC Ground +5V Power Hot Plug Detect... -
Page 10: Input/Output Resolution
9. Input/Output resolution Output switch Input/ PC Output Component Output Output Resolution 480i60 480p60 576i50 576p50 720p50 720p60 1080i50 1080i60 1080p24 1080p50 1080p60 640x480@60,72,75,85 800x600@56,60,72,75,85 1024x768@60,70,75,85 1152x864@70,75,85 1280x768@60RB,60 1280x800@60RB,60,75 1280x960@60,85 1280x1024@60,75,85 1366x768@60RB,60 1400x1050@60RB,60 1440x900@60RB,60,75 1600x1200@60 1680x1050@60RB,60 1920x1200@60RB Note: When the TV didn’t support 1080p@24 input, the user needs to disable the 1080p@24 from source equipment, such as Blue-ray player or PS3 etc.). -
Page 11: Connection And Installation
8. Connection and Installation Connection 1(RGB out) VGA cable HDMI out 3.5mm to 2 RCA audio cable LCD Monitor/TV Projector Set-Top-Box HDMI cable DVI out DVI to HDMI adaptor Connection 2 (YPbPr out) YPbPr cable D-Sub to 3 RCA cable HDMI cable Set-Top-Box Audio... -
Page 12: Acronyms
Acronyms Acronym Complete Term Digital Visual Interface EDID Extended Display Identification Data HDCP High-bandwidth Digital content protection HDMI High-Definition Multimedia Interface Macintosh Macintosh CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw MPM-CP1262HST...
