Laser Pegs FACTOID COMBAT FIGHTER Model Instructions

Please read manual before you begin! Failure to
G9005B
follow this manual's instructions may result in
damage to the Triangle Power Base, AC Adapter
COMBAT FIGHTER and/or Laser Pegs®. Not adhering to these
directions will void the manufacturer's warranty.
AGES 5+
Packing has to be kept since it contains
important information.
8 Models+
Any creation you can build
WARNING:
LIGHTED
CHOKING HAZARD
- Small parts.
CONSTRUCTION SET INCLUDES:
Not for children under 3 yrs.
Do not submerge in water.
• 10 Laser Pegs®
• 48 Construction Parts
• Triangle Power Base
• Instruction Manual
Requires 3 AA Batteries
EN71, RoHS COMPLIANT
This product complies to
Batteries NOT
all safety requirements
Included
of ASTM F 963
MODEL INSTRUCTIONS
All additional model instructions can
be downloaded at www.LaserPegs.com
Laser Pegs® Parts List
There is No LED In The 90 Degree Peg
x1
x1 x2 x1
x1
x1
Y PEG SQUARE 45° PEG 90° PEG
STRAIGHT
PEG
SQUARE
T-PEG
M-M PEG
Each Laser Peg® is color coded on the circuit board inside
Color
each shape. There is No LED In The 90 Degree Peg.
Code
Sound Activated
Laser Pegs
Triangle Power Base
Peg Cord
Construction Parts List
x3
x4
x2
x3
x4
x2
x2
x2 x2
x2
x2
x2
x8
x1
x1
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2014 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs® Ventures
LLC. 8304 Consumer Ct., Sarasota FL 34240. Contact: Support@LaserPegs.com
Connecting Pegs
To construct with Laser Pegs®, slide two pieces together to form a
connection. Slide each piece on and off smoothly. To build away from the
Triangle Power Base, use the peg cord in one of the top three peg holes to
illuminate your model! The 90° pegs are essential to construction but they
DO NOT ILLUMINATE.
Environmental Phenomena
* The unit may malfunction if subjected to radio-frequency interference. It SHOULD revert to
normal operation when the interference stops. If not, it may become necessary to turn the power
off and back on, or remove and reinstall the batteries.
* In the unlikely event of an electrostatic discharge, the unit may malfunction and lose memory,
requiring the user to reset the devise by removing and reinstalling the batteries.
Push Red
Red
Power Button
Power Button
to turn on/off
Push Red Power Button to
cycle through 4 different
light settings.
AC Adapter
SOUND/ON/FLASH/FLASH FASTER Connection
WARNING: STROBE LIGHTS
The toy is not to be connected to more than
MAY CAUSE SEIZURES
the recommended number of power supplies
Replacing Batteries
1. Remove the three (3) screws.
2. Place three (3) AA batteries in the correct
position - as displayed inside the Triangle
Power Base.
3. Reassemble the Triangle Power Base.
4. Replace the three (3) screws.
5. Push RED Power Button to turn on!
x3
6. Do not mix old and new batteries.
7. Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium,
NiMH) batteries!
8. Exhausted batteries are to be removed
STACKABLE
from the Triangle Power Base.
9. Never connect more than 200 Laser Pegs®
10. Non-rechargeable batteries are not to be
recharged.
11. Rechargeable batteries are only to be
recharged under adult supervision.
12. Rechargeable batteries are to be removed
from the toy before being recharged.
13. Batteries are to be inserted with the
correct polarity.
14. The supply terminals are not to be short-
circuited. Remove the three Phillips head
15. DO NOT THROW BATTERIES INTO FIRE!
screws with a 4mm screw driver.
Please dispose of batteries properly as per state and local regulations.
Using an
®
AC Adapt
er
Remove all batteries
from Laser Pegs® power
base before using the
x3
5-volt AC adapter.
*To avoid short-circuits, keep metal objects and
x3 other unauthorized materials from obstructing
the peg holes.
The AC adapter and the Triangle Power Base are to be regularly examined for
x2
damage to the cord, plug, enclosure and other parts, and in the event of such
damage, they must not be used until the damage has been repaired.
x2
WARNING! Each Laser Peg® draws current from the batteries. Therefore, the more
pegs you use, the quicker you will deplete your battery power! As the power
weakens, the current will slowly fail and some Laser Pegs® will illuminate (typically
the reds and yellows) and some won't. When the Laser Pegs® dim the Laser Pegs®
are not broken, they just need stronger batteries or an AC Adapter.
You have 3 simple options...
1. Use a 5-volt AC Adapter –available from www.LaserPegs.com
2. Change the batteries.
3. Use high quality batteries. They will last a little longer, but they will still deplete
rapidly the more laser pegs you connect!
DO NOT SUBMERGE IN WATER
OSPREY:multi-mission, military, tiltrotor aircraft with both a vertical takeoff and landing
(VTOL), and short takeoff and landing (STOL) capability.
OSPREY
Model
Difficulty
Level
Peg Holes
A
Remove the 3 Phillips head screws
STEP
3-AA Batteries
1
Requires (3AA) Batteries
When using an AC
Adapter, NEVER
place the adapter
STEP
plug into the Tri-
2
angle Power Base
top peg holes.
Never connect more than 200
Laser Pegs® when using a 5-volt
(2000mA) AC Adapter.
Questions? Comments?
For additional compliance info:
Contact: Support@LaserPegs.com
Laser Pegs® CARES
1-866-432-3735
STEP
3
STEP
4
STEP
5
STEP
6
