Record your model number.
3
Slide the extension and handle
onto the stem. Check for proper
handle fit. If needed, cut the longer
extension for proper fit.
1377366-2-A
WARNING: Risk of scalding.
High water temperature can cause
severe burns. Set the water temperature
at or below 120°F (49°C) following the
adjustment procedure in the valve
Installation and Care Guide.
4
Remove the handle and secure
the extension with the screw.
Important Information
Follow all local plumbing and building
codes.
5
Make sure the valve is closed.
1
Using the plaster guard as a
handle, turn the water off.
6
Position the faceplate with the
notch at the bottom.
2
Remove the plaster guard.
7
Point the handle down.Thread the
bonnet onto the valve.
