Summary of Contents for Halo Bolt Air+DC
- Page 1 PLEASE READ BEFORE OPERATING THIS EQUIPMENT...
- Page 2 Thank you for choosing HALO! Powerful and loaded with features including an easy to use digital display, the HALO BOLT AIR+ DC can be used to safely jump start your vehicle, in ate your tires and power your electronic devices anywhere.
-
Page 3: Safety Precautions
• Do not expose your HALO BOLT AIR+ DC to moisture, water, rain, or snow. • Keep your HALO BOLT AIR+ DC away from heat sources, including open ames, radiators, stoves, ovens, and any other devices that product heat. - Page 4 Incorrect reassembly may result in shock or re hazard. • Do not drop or subject to strong impacts. Do not operate your HALO BOLT AIR+ DC if it has received a sharp blow, or has otherwise been damaged in any way.
-
Page 5: Table Of Contents
TABLE OF CONTENTS Safety Precautions Included Items Operating Instructions 8-16 Troubleshooting Guide Speci cations Warranty and Contact Information POWER YOUR LIFE | 5... -
Page 6: Included Items
INCLUDED ITEMS - HALO BOLT AIR+ DC - Wall Charging Adapter - Jumper Cables - Interchangeable Air Nozzle Kit - AC Inverter - 24 Inch Air Hose Extension - Carrying Pouch - DC to DC Cable | Floodlight ON/OFF Button... - Page 7 POWER YOUR LIFE | 7...
-
Page 8: Operating Instructions
To charge your HALO BOLT AIR+ DC, use the provided Wall Charging Adapter, and plug the AC adapter plug into the charge input. Next, connect the AC adapter into a wall outlet. The HALO BOLT AIR+ DC will automatically begin charging. When the HALO BOLT AIR+ DC is fully charged, all ve battery indicator lights will be solid green and the digital screen will indicate 100% charge. - Page 9 The HALO BOLT AIR+ DC is designed to charge between 32°F-113°F (0-45° C). A "TEMP" indicator will be illustrated on the digital display if the HALO BOLT AIR+ DC is attempted to be charged outside of this temperature range. POWER YOUR LIFE | 9...
- Page 10 JUMP STARTING YOUR VEHICLE WITH THE HALO BOLT AIR+ DC 1. Plug the jumper cables into the jump start output on the HALO BOLT AIR+ DC. NOTE: Make sure the jumper cables are fully plugged into the jump start output before trying to jump your vehicle.
- Page 11 NOTE: The HALO BOLT AIR+ DC is designed to allow a jump start when used within a safe temperature range. A "TEMP" indicator will be illustrated on the digital display if used outside of the temperature operating range.
-
Page 12: Troubleshooting Guide
HALO BOLT ensure they are properly connected to the battery. Check and ensure AIR+ DC Jump The HALO BOLT AIR+DC is waiting to the vehicle battery voltage is Start button greater than 2.0V. If the SAFETY be connected to a battery or a SAFETY CHECK FAIL indicator is triggered CHECK FAIL has been triggered. - Page 13 HALO BOLT AIR+ DC COMPRESSOR The HALO BOLT AIR+ DC comes equipped with a 24 Inch Air Hose Extension and Interchangeable Air Nozzles. Simply twist on the corresponding nozzle to in ate balls, pool oaties, bike tires, and more! 1. Connect the air hose to the tire or use the appropriate nozzle to connect to your in atable device 2.
- Page 14 Connect one end of the supplied DC cable to the DC Input on the AC Inverter and the other end to the DC Output on the HALO BOLT AIR+ DC. Connect your device’s AC plug in the AC Inverter’s AC port. The LED on the AC Inverter will be solid green if no safety protection is triggered and the device is charging normally.
- Page 15 5V/2.4A USB OUTPUT PORT 1. Use the charging cable provided with your electronic device and connect the Standard USB end into either one of the HALO BOLT AIR+ DC US 5V/2.4A Output ports. 2. Turn on the USB charging by pressing the USB Power ON/OFF Button on the HALO BOLT AIR+ DC.
- Page 16 TECHNOLOGY to achieve higher compatibility for charging standard 5V USB electronic devices. The HALO SMART CHARGE TECHNOLOGY will allow the HALO BOLT AIR+ DC to communicate with your electronic device and provide the fastest and safest charge for that device.
-
Page 17: Speci Cations
SPECIFICATIONS Battery Cells: 3x Li-Polymer 5000mAh Battery Pack Energy: 55500 mWh Jump Start: 12V/600Amps Air Compressor: 100PSI max Input: 14V/0.85A USB Output: 2x USB 5V/2.4A DC Output: 12V/10A Dimensions: 4.65 x 9.52 x 1.85 inches Weight: 2.54 lbs Operating Temperature: 32°F - 113°F (0°C - 45°C) AC INVERTER DC Input:... - Page 18 COMPLIANCE WITH FCC REGULATION This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 19: Warranty And Contact Information
LIMITED WARRANTY HALO warrants its products to be free from defects in material and workmanship under normal use. For all questions or exchange requests, please call 888-907-6274, contact us at zagg.com/support or visit www.zagg.com/warranty-policies. This Limited Warranty sets forth the full scope of HALO’s obligations and liabilities with respect to the product. - Page 20 STE. 500, MIDVALE, UTAH 84047 WWW.ZAGG.COM/HALO © 2021 ZAGG Inc | www.ZAGG.com/HALO The HALO and H trademarks are the property of ZAGG Inc. All rights reserved. 314-00994-A. ZAGG Inc | 910 W Legacy Center Way, Ste. 500, Midvale, Utah 84047 Made in China.
