Electro-Voice Dx38 Digital Controller:
The Dx38 digital electronic loudspeaker
controller has a two-in/four-out architec-
ture, with each output having program-
mable high-pass and low-pass filters, four-
band equalization, signal delay, compres-
sor and limiter functions. Program
parameters for optimal performance of the
X-Array™ systems are available. Electro-
Voice, 600 Cecil St., Buchanan, MI 49107
USA, 616/695-6831
Electro-Voice P3000 Power Amplifiers:
The stereo P3000 power amplifiers are rated
at 800 watts into 8 ohms, or 93-volts rms
short term. The amplifiers are 3-U high and
weigh 28 kg (62 lb) each. Electro-Voice,
600 Cecil St., Buchanan, MI 49107 USA,
616/695-6831
X-Array™ Amplifier Racks: These 22-U
racks will hold six Electro-Voice P3000
power amplifiers, one Klark Teknik DN8000
digital controller, 1-U light module, and a
2-U multipin patch panel. The aluminum-
frame/wood-panel racks are vibration-iso-
lation mounted on heavy-duty wheel
boards and come prewired for AC power,
audio and control signal sends and Neutrik
Speakon speaker connectors. db Sound,
L.P., 1219 Rand Road, Des Plaines, IL 60016
USA, 847/299-0357
X-Array™ Speaker Cables: Eight con-
ductor cable with four #11 AWG conduc-
tors and four #13 AWG connectors. The
larger conductors are used in the LF bands
for increased damping factor. Lengths
made to order. Standard terminations are
TM
Neutrik Speakon NL8FC connectors
wired to X-Array™ standards; however,
custom terminations are available. Enter-
tainment Technology Cable, 1247 Rand
Road, Des Plaines, IL 60016 USA,
800/529-6312

Miscellaneous Accessories:

X-Array™ Loudspeaker Covers: Heavy-
duty covers are available for the X-Array™
speakers. These covers wrap around the
enclosures, while sitting on a dolly, and
Velcro together at the back for fast instal-
lation and removal. db Sound, L.P., 1219
Rand Road, Des Plaines, IL 60016 USA,
847/299-0357
X-Array™ Dolly Boards: Double-wide
Xn Three-Way, LF/MB/HF System Xn Three-Way LF/MB/HF System
dolly built to hold four X-Array™ loud-
speakers, two wide by two high. The
double-thick 18-mm birch-plywood con-
struction includes cutouts and keys for
loudspeaker enclosure shape and align-
ment feet. The dolly boards are painted
black and utilize four extra-heavy-duty 4-
inch x 2-inch casters. Custom-designed
dolly boards are also available to meet spe-
cific requirements. R&R Cases and Cabi-
nets, 1217 Rand Road, Des Plaines, IL 60016
USA, 847/299-8100
Racks and Road Cases: A variety of gen-
eral purpose, custom racks and hard-shell
road cases are available for touring or per-
manent-installation applications. R&R
Cases and Cabinets, 1217 Rand Road,
Des Plaines, IL 60016 USA, 847/299-8100
Uniform Limited Warranty
Electro-Voice products are guaranteed
against malfunction due to defects in ma-
terials or workmanship for a specified pe-
riod, as noted in the individual product-
line statement(s) below, or in the individual
product data sheet or owner's manual, be-
®
ginning with the date of original purchase.
If such malfunction occurs during the
specified period, the product will be re-
paired or replaced (at our option) without
charge. The product will be returned to the
customer prepaid. Exclusions and Limita-
tions: The Limited Warranty does not ap-
ply to: (a) exterior finish or appearance; (b)
certain specific items described in the indi-
vidual product-line statement(s) below, or
in the individual product data sheet or
owner's manual; (c) malfunction resulting
from use or operation of the product other
than as specified in the product data sheet
or owner's manual; (d) malfunction result-
ing from misuse or abuse of the product;
or (e) malfunction occurring at any time
after repairs have been made to the prod-
uct by anyone other than Electro-Voice Ser-
vice or any of its authorized service repre-
sentatives. Obtaining Warranty Service: To
obtain warranty service, a customer must
deliver the product, prepaid, to Electro-
Voice Service or any of its authorized ser-
vice representatives together with proof of
purchase of the product in the form of a bill
of sale or receipted invoice. A list of autho-
rized service representatives is available
from Electro-Voice Service at 600 Cecil Street,
Buchanan, MI 49107 (800-234-6831 or FAX
616-695-4743). Incidental and Consequen-
tial Damages Excluded: Product repair or re-
placement and return to the customer are
the only remedies provided to the customer.
Electro-Voice shall not be liable for any inci-
dental or consequential damages including,
without limitation, injury to persons or prop-
erty or loss of use. Some states do not allow
the exclusion or limitation of incidental or
consequential damages so the above limita-
tion or exclusion may not apply to you. Other
Rights: This warranty gives you specific le-
gal rights, and you may also have other
rights which vary from state to state.
Electro-Voice Speakers and Speaker Sys-
tems are guaranteed against malfunction due
to defects in materials or workmanship for a
period of five (5) years from the date of origi-
nal purchase. The Limited Warranty does
not apply to burned voice coils or malfunc-
tions such as cone and/or coil damage re-
sulting from improperly designed enclo-
sures. Electro-Voice active electronics asso-
ciated with the speaker systems are guaran-
teed for three (3) years from the date of origi-
nal purchase. Additional details are included
in the Uniform Limited Warranty statement.
Electro-Voice Accessories are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a period of one (1)
year from the date of original purchase. Ad-
ditional details are included in the Uniform
Limited Warranty statement.
Electro-Voice Flying Hardware (including
enclosure-mounted hardware and riggings
accessories) is guaranteed against malfunc-
tion due to defects in materials or workman-
ship for a period of one (1) year from the
date of original purchase. Additional details
are included in the Uniform Limited Warranty
statement. For warranty repair, service in-
formation, or a listing of the repair facilities
nearest you, contact the service repair de-
partment at: 616/695-6831 or 800/685-2606.
For technical assistance, call: 800/234-6831.
Specifications subject to change without
notice.
