Summary of Contents for Electro-Voice X-Array XF
- Page 1 ™ ™ Delivering the best possible sound to every seat in the house...
- Page 2 (see engineering data sheets and Xi-Series Manual*). *The user is responsible for deter- mining the loads on all mechanical components throughout the loud- speaker array and for ensuring that the working-load limits and resulting safety factors are not exceeded. ™ systems ™...
- Page 3 way systems – for down fill, far throw, delay rings, under balcony and low-frequency enhancement. Many of the two-way systems also provide superb performance on their own when room acoustics and geometry are appropriate. When performance demands are high, Xi-Series ™...
- Page 4 Two- and three-element line arrays Two- and three-element line better. They flanked the mid-bass horn with dual, spaced LF arrays extend vertical sources to form a three-element coverage-angle control to as line array, or “tripole.” They low as 125 Hz, for high intelli- found that by using the dual LF sources alone at low frequencies gibility in reverberant spaces...
- Page 5 Two- ways with special protection option Compact, two-way full-range intelligibility and musical clarity in reverberant spaces and systems for stand-alone use reduces the possibility of feed- back beneath the systems. in small- to medium-sized The Xi-2123/106F may also be installations and to comple- conventionally crossed over, ment the performance of without LF/MB overlap, with...
- Page 6 Low-frequency and subwoofer systems Xi-Series ™ low-frequency and cient to provide a 37 Hz low- frequency limit (3 dB down) subwoofer systems are without low-frequency lift (EQ). optimally vented designs This degree of low-frequency appropriate for single and extension is appropriate for multiple use, flown or ground most contemporary music.
- Page 7 ISP-100’s ® processors do not offer the can be used to augment loud- programming flexibility or DSP speaker management with power to handle these signifi- signal routing to fit many cant special applications. performing arts, church and At the heart of Merlin other applications.
- Page 8 System: Xi-1123/106 Frequency Response: 60-20,000 Hz Crossover Frequencies: 250/550 Hz, 1,760 Hz Power Handling, Long Term: 300/300/75 W, 300/300W Sensitivity (1 W/1 m), Triamp: 98.0/109.0/111.7 dB Biamp/FR: 101.4/106.7 dB Nominal Coverage Angle (H x V): 100°x 60° 100°x 60° Dipole/Tripole Configurable ®...
