Exhausto VEX300 Series Assembly And Installation Manual

Hide thumbs Also See for VEX300 Series:

Advertisement

Quick Links

3004248-2021-05-07
VEX308 EXact
Assembly and installation
Product information........................................ Chapter 1 + 4
Mechanical assembly..................................... Chapter 2
Electrical installation.......................................Chapter 3
EXHAUSTO A/S
Odensevej 76
DK-5550 Langeskov
Tel. +45 65 66 12 34
Fax +45 65 66 11 10
exhausto@exhausto.dk
www.exhausto.dk
VEX308 EXact2
Unit supplied with (factory fitted):
ePM
60%-
-filter Extract
10
ePM
55%-
-filter Outdoor
1
VEX308 with heatingcoil water
SMALL - HW308SE
LARGE - HW308LE
VEX308 with heatingcoil electrical 2,4 kW - HE30802E
Condensation pump, CONPUMP
CO2-sensor, CO2B
Humidity sensor, RHB
Motion sensor, PIRB
Webserver/EXact, WEBE
LSR308 Closing damper (outdoor)
Smoke detector, SDB
The following accessories are supplied
separately:
Operation panel, HMI
Closing damper for vertical exhaust, LS315
TIMERBUTTON2
pieces, Outer wall grilles, YGC Ø315
Serial no.:
Prod. order no.:
Sales order no.:
