VEX370H

Mechanical Assembly

EXact2 control system

Product information........................................Chapter 1 + 6

Mechanical assembly.....................................Chapter 2 + 3

Electrical installation.......................................Chapter 4

Maintenance...................................................Chapter 5

EXHAUSTO A/S

Odensevej 76

DK-5550 Langeskov

Tel. +45 65 66 12 34

Fax +45 65 66 11 10

exhausto@exhausto.dk

www.exhausto.dk

VEX370H EXact2

Unit supplied with (factory fitted):

Bag filter, FB

M5-compact filter, FP

F7-compact filter, FP

OD - roof for outdoor

Mounting base, (unassembled)

Webserver

MLON

HCW370I - Integrated heating coil (water)

The following accessories are supplied

separately:

HCW-heating coil (water), duct-fitted

Motor valve, MVM ______K

Motorvalve outdoor, MVM-OD

(partially mounted)

DX cooling/heating coil

CCW-cold water coil

Closing damper, LS600x1200, (LSA exhaust)

Closing damper, LS600x1200, (LSF outdoor)

Closing damper, LSR600x1200, with

spring-return (LSAR exhaust)

Closing damper, LSR600x1200, with

spring-return (LSFR outdoor)

pieces, Fire thermostat, BT40

pieces, Fire thermostat, BT50

pieces, Fire thermostat, BT70

pieces, control panel, HMI

pieces, Motion sensor, MIO-PIR

pieces, Constant pressure control, MPT-DUCT

Humidity sensor, MIO-RH

-sensor, MIO-CO2-DUCT

-sensor, MIO-CO2-ROOM

Temperature sensor, MIO-TS-DUCT

Temperature sensor, MIO-TS-ROOM

Control for external cooling unit, MXCU

Serial no.:

Prod.order no.:

Sales order no.:

Original instructions

-value

Table of Contents

Need help?

Do you have a question about the VEX300 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Exhausto VEX300 Series

Page 1 Product information........Chapter 1 + 6 Prod.order no.: Sales order no.: Mechanical assembly........Chapter 2 + 3 Electrical installation........Chapter 4 Maintenance...........Chapter 5 Original instructions EXHAUSTO A/S Tel. +45 65 66 12 34 Odensevej 76 Fax +45 65 66 11 10 DK-5550 Langeskov exhausto@exhausto.dk www.exhausto.dk...
Page 2: Table Of Contents
3004793-2016-10-03 1. Product information 1.1. Designations used in these instructions.............6 Model overview....................6 1.1.1. Designations used in these instructions............7 1.2. Application......................8 1.3. Location requirements..................8 1.3.1. Space requirements..................9 1.3.2. Requirements for underlying surface...............9 1.3.3. Outlet.......................9 1.3.4. Requirements for duct system.................9 1.4. Description......................10 1.4.1.
Page 3 3004793-2016-10-03 6.4.1. MVM motor valve ..................41 6.5. Capacity diagram....................42 6.5.1. Capacity diagram, ventilation with heat recovery...........42 6.5.2. Capacity diagram, ventilation with bypass operation........43 6.6. Ordering spare parts...................43 3/44...
Page 4 Scope This instruction manual is for use with EXHAUSTO VEX-type air handling units. Please refer to the product instructions regarding accessories and extra equipment. The instructions must be fully observed to ensure personal safety and to protect the equipment and ensure its correct operation.
Page 5 ● Or use a padlock. Use the handle’s built-in padlock fixture. Padlock fitting Rating plate The VEX unit rating plate shows: ● VEX model (1) ● Production order no. (2) Always have the production number ready when contacting EXHAUSTO A/S. 5/44...
Page 6: Product Information
Product information 3004793-2016-10-03 1. Product information 1.1 Designations used in these instructions Model overview Elements Explanation Compact filter Bag filter 1,1,A or B Extract air spigot NB: In cases where the unit has two spigots (extract air/flue gases), the filter is always loca- ted by the extract air spigot 1,2,A Exhaust air spigot...
Page 7: Designations Used In These Instructions
Product information 3004793-2016-10-03 Fan placement Air directions RIGHT 1,1,B 2,2,B 1,1,A 2,2,A 1,2,A 2,1,A Spigot location B option not available with outdoor models. 1.1.1 Designations used in these instructions The simplified diagram shows a VEX unit with LEFT fan placement. Component Function Bypass damper extract air/exhaust air...
Page 8: Application
Temperature sensor, supply air 1.2 Application Comfort ventilation EXHAUSTO VEX is used for comfort ventilation tasks. Operating temperature range for the unit – see section "Technical data". Prohibited uses The VEX unit is not to be used to transport solid particles or in areas where there is a risk of explosive gases.
Page 9: Space Requirements
Product information 3004793-2016-10-03 1.3.1 Space requirements The drawing below indicates how much space is required to open the side-mounted doors for servicing, replacing filters, cleaning, etc. The drawing shows compact filters. For servicing purposes, a free height of at least 200 mm is required above the unit’s connection box.
Page 10: Description
● heating/cooling losses Condensation Condensation in the ducts may occur when the exhaust/outdoor air has high hu- midity. EXHAUSTO recommends a condensation outlet is also fitted at the lowest point in the ducts. No duct connection If one or more of the spigots is not connected to a duct: Fit a pro- tective net to the spigots with a maximum mesh width of 20 mm.
Page 11 Product information 3004793-2016-10-03 1,1,B/flue gas 2,2,B 2,2,A 1,1,A 2,1,A 1,2,A Pos. no. Part Function Spigot 1,1,A Extract air spigot The spigot can also be positioned on the top of the unit (1,1,B). Does not apply to units designed for out- door fitting Spigot 1,2,A Exhaust air spigot...
Page 12: Main Aim
Product information 3004793-2016-10-03 Pos. no. Part Function Connection box Connection box for supply voltage, exter- nal ventilation components, HMI panel, BMS and Ethernet Connection box Cover plate HMI panel Operation of the control system MPT3 Measures pressure loss across the coun- ter flow heat exchanger Extract air filter Filters extract air.
Page 13 Product information 3004793-2016-10-03 VEX370H, Left 1104 1,1,A 2,2,A 1,2,A 2,1,A DN32 1500 3268 1366 1200 1200 1,1,A 2,2,A 1200 1200 1,2,A 2,1,A 1) Allow for space in front of the VEX unit, so the doors can be opened 2) Allow for free height over the VEX unit, so the connection box can be serviced 3) The legs under the VEX unit can be adjusted for height between 55mm and 110mm.
Page 14 Product information 3004793-2016-10-03 VEX370C, Right 1104 1,1,A 2,2,A 1,2,A 2,1,A DN32 1500 3268 1366 1200 1200 1,1,A 2,2,A 1200 1200 1,2,A 2,1,A 1) Allow for space in front of the VEX unit, so the doors can be opened 2) Allow for free height over the VEX unit, so the connection box can be serviced 3) The legs under the VEX unit can be adjusted for height between 55mm and 110mm.
Page 15: Handling
Handling 3004793-2016-10-03 2. Handling 2.1 Unpacking Supplied compo- The following components are supplied: ● VEX unit with associated base. nents ● Supplied accessories (as indicated in the checklist on the front page of the in- structions) Packaging The unit is delivered in three sections on separate disposable pallets; packed in cardboard and clear plastic.
Page 16: Internal Transport With Reduced Weight
Handling 3004793-2016-10-03 Width - fan sections The list below shows how large an opening has to be for the fan sections to pass through: If the opening width is Then Less than 900 mm The unit will not pass through Between 900 and 1,153 mm For fan section with integrated heating coil: ●...
Page 17 Handling 3004793-2016-10-03 Section Subcomponents Weight Compact or bag filters, 3 items of 6 kg 2 kg weight Exchanger section, 1 x 430 kg Exchanger section, empty cabinet 285 kg Counter flow heat exchangers, 6 x 114 kg 19 kg Doors, 2 x 15.5 kg 31 kg Integrated heating coil HCWI, 58 Base, 1 x 90 kg...
Page 18 Handling 3004793-2016-10-03 How to remove the doors (2 in no.) to the heat exchanger sections: ● Open the door ● Unscrew the door hinge from the front panel (1) and take the door off. To remove the fan unit DETAIL A Step Action Remove the fixing screws (1) on the sliding rail (out towards the operating...
Page 19: Disassembly Of Integrated Heating Coil, Hcw370I
Handling 3004793-2016-10-03 Removing the coun- See section "Servicing" ter flow heat ex- changers 2.2.3 Disassembly of integrated heating coil, HCW370I Step Action Support the heating coil before disassembling it. NB: The heating coil weighs 58 kg. - make sure there are at least two persons to lift the coil off.
Page 20: Mechanical Assembly
Mechanical assembly 3004793-2016-10-03 3. Mechanical assembly 3.1 Installing the unit 3.1.1 Assembly instructions The assembly of VEX370 is divided into 4 steps as shown below, see the following sections for a detailed description of each step. Step 1, assemble the base Step 2, push the sections onto the base Step 3 - 4, tighten the VEX section joints Base...
Page 21: Step 1-4
Mechanical assembly 3004793-2016-10-03 3.1.2 Step 1–4 Step 1, Base: Assemble the base as shown in the drawing below. Base assembly Drawing The base consists of the fol- lowing parts: M10x35 M10x25 21/44...
Page 22 Mechanical assembly 3004793-2016-10-03 Base assembly Drawing The following tools are re- quired: 2x17mm 2x30mm Assemble the base levelling bolts, by tapping the threa- ded bar securely into the foot. Screw a nut onto the threa- ded bar and put a washer on. Lay the base parts on the floor with the top facing downwards, as shown in the...
Page 23 Mechanical assembly 3004793-2016-10-03 Base assembly Drawing Assemble the long pieces: ● Front long piece: Join A, B and C with nuts and M10x25 bolts. ● Rear long piece: Join A, B, C and G with bolts and nuts. Fit the two small tension fit- tings (F) on each side of the short members (G) and se- cure firmly using nuts and...
Page 24 Mechanical assembly 3004793-2016-10-03 Base assembly Drawing Screw the last long piece on using nuts and bolts. M10x25 Screw the levelling bolts on the base with M20 nuts and washers Turn the base with legs down and place it so that the tension fittings face away from the operating side It is important that the base is levelled before the VEX unit is placed...
Page 25 Mechanical assembly 3004793-2016-10-03 Step 2, VEX sections Manoeuvre the sections onto the base by pushing them directly from the pallet onto the base. 1. Push a fan section onto the base first 2. Next, push the exchanger section onto the base 3.
Page 26: Condensation Drain
Mechanical assembly 3004793-2016-10-03 Step 4, Smooth To ensure joints are sealed at the condensation tray, the transition between the joints at the conden- bottom motor and the condensation tray must be sealed: sation tray Action Smooth the two joints (front and rear on the transition) with a finger.
Page 27: Integrated Water Heating Coil
3004793-2016-10-03 Solution with HT Use HT pipe (HT, DN32, DIN4102), if the above solution is not employed (not sup- pipe plied by EXHAUSTO). 3.3 Integrated water heating coil 3.3.1 Principles for connecting the water heating coil Mixing loop The diagrams below are simplified. The dimensioning of valves, pipes, etc. and heating coil connection must always be carried out by authorised fitters in accord- ance with applicable regulations and legislation.
Page 28 The heating coil pipes must not be in the way when opening the nearest door on the VEX for extraction of the fan section. Use a 90° bend on the heating coil connection spigots. *) not EXHAUSTO delivery (refer to the technical specifications in section 7). Bleeding Following connection of water supply to the unit: ●...
Page 29: Mvm Valve
Mechanical assembly 3004793-2016-10-03 Fitting motor valve The valve must not be fitted with the motor facing down Insulate the water The pipes to and from the heating coil must be insulated according pipes to applicable regulations 3.3.2 MVM valve Screening Screen the valve motor from direct sunlight.
Page 30: Electrical Installation
VEX360H-370H with EXact2 control system”. VEX370H EXact2 3004829-2013-06-06 VEX350H-360H-370H Electrical Installation Guide - EXact2 control system Electrical installation........Chapter 1 + 2 Original instructions EXHAUSTO A/S Tel. +45 65 66 12 34 Odensevej 76 Fax +45 65 66 11 10 DK-5550 Langeskov exhausto@exhausto.dk www.exhausto.dk 30/44...
Page 31: Maintenance
(access code 1111) to check the unit's operating status. 5.2 Maintenance Schedule Recommended in- The following chart details the recommended maintenance intervals, under normal tervals operating conditions. EXHAUSTO recommends maintenance is adjusted to suit the actual operating requirements. Component Procedure Once a...
Page 32: Hygiene
● EUROVENT certification is only valid if original filters are used ● Use of non-original filters may cause leakage in the VEX and impair filter func- tion ● EXHAUSTO recommends that you register the filter replacement date to ensure filters are replaced at the correct intervals 5.3 Hygiene...
Page 33 Maintenance 3004793-2016-10-03 Summary of parts in There is a difference in the sequence for removing counterflow heat exchangers, the heat exchanger depending on whether the VEX is a left or right-hand unit. One a left-hand unit the section heat exchanger to the left is removed first, while on a right-hand unit the right-hand heat exchanger is removed first.
Page 34 Maintenance 3004793-2016-10-03 VEX370R Step Action Start by opening the door to the fan sec- tion (right-hand section for a left-hand unit) and release the 6 tensioners: turn the tensioner clockwise 7 times. Loosen the finger screws on the brack- et. Push the bracket to one side and re- move it.
Page 35 Maintenance 3004793-2016-10-03 Step Action Remove the sealing profile in front of the heat exchangers (unhooks). Remove the sealing panel between the heat exchangers (pull the handle). Remove the first heat exchanger. NB: A single heat exchanger weighs 19 kg. Push the other heat exchanger to the side and remove it also.
Page 36: Servicing And Cleaning
Maintenance 3004793-2016-10-03 Step Action Use the first of the two panels on the in- side of the door in the heat exchanger section as an underlay for the next row of heat exchangers. Lay the panel at the side from which the heat exchanger is to be removed.
Page 37 Maintenance 3004793-2016-10-03 Step Action Vacuum clean the heating coil Cold water coil: clean the condensation tray 37/44...
Page 38: Technical Data
Technical data 3004793-2016-10-03 6. Technical data 6.1 Weight, corrosion class, temperature ranges Weight Weight 1,018 kg Corrosion class Corrosion class Corrosion class C4 in accordance with EN ISO 12944-2 Temperature ranges Outdoor air temperature -40ºC to +35ºC Ambient temperature -30ºC to +50ºC At temperatures below -25˚C (with outdoor installation), use of a thermostatically controlled heater in automated control box is recommended.
Page 39: Compact Filters
Technical data 3004793-2016-10-03 Motor damper Motor damper type LS600x120024 LSR600x120024 Designation LSA/LSF LSFR Motor type NM24-F AF-24 Rotation time 75–150 s open: 150 s close: 16 s Ingress protection IP42 IP42 Ambient temperature -20ºC to +50ºC -30ºC to +50ºC Damper depth (LS rail system) 115 mm 115 mm Damper depth (METU rail system)
Page 40: Bag Filters
Technical data 3004793-2016-10-03 EUROVENT certification is only valid if original filters are used. For more details about original filters, see section "Maintenance". AHU n° 10.12.505 Range: VEX100/200/320-370 6.3 Bag filters Pressure loss curves for M5 and F7 filters Filter data Filter area h x b (qty.
Page 41: Integrated Water Heating Coil Hcwi
Fin spacing 2.3 mm Permissible media temperature 5..0.95°C Recommendation A precise calculation of the heating coil is recommended, to be carried out with calculation program EXselect, available on www.exhausto.dk. 6.4.1 MVM motor valve Valve 1.0 - 4.0 Test pressure 1600 kPa 1600 kPa Max.
Page 42: Capacity Diagram
Technical data 3004793-2016-10-03 6.5 Capacity diagram 6.5.1 Capacity diagram, ventilation with heat recovery Ventilation with heat recovery Capacity diagram with M5 filters SFP-curve (J/m ) Operating curves A: Pressure supplement with F7 filters B: Pressure supplement with cold water coil/ heating coil 42/44...
Page 43: Capacity Diagram, Ventilation With Bypass Operation
VEX guidelines and on the VEX rating plate. Contact: Contact your local EXHAUSTO office service department to order a spare part. Contact information is given on the back cover of these instructions. See also the "Layout" section for an overview of the position and designation of parts in the VEX.
