Icom IC-M35 Service Manual page 9

Feb. 2012
[MAIN UNIT]
REF PARTS
NO. NO.
C364 4030016950 S.CER C1005 JB 1A 473K-T
C365 4030016950 S.CER C1005 JB 1A 473K-T
C366 4030016950 S.CER C1005 JB 1A 473K-T
C367 4030016950 S.CER C1005 JB 1A 473K-T
C370 4030018070 S.CER C1005 CH 1H 300J-T
C371 4030017400 S.CER C1005 CH 1H 220J-T
C372 4030016930 S.CER C1005 JB 1A 104K-T
C373 4030018900 S.CER C1005 JB 0J 474K-T
C374 4030018900 S.CER C1005 JB 0J 474K-T
C375 4030018900 S.CER C1005 JB 0J 474K-T
C377 4030017740 S.CER C1005 JB 1H 821K-T
C378 4030017780 S.CER C1005 JB 1H 472K-T
C379 4030017420 S.CER C1005 CH 1H 470J-T
C380 4030017460 S.CER C1005 JB 1H 102K-T
C381 4030017460 S.CER C1005 JB 1H 102K-T
C382 4030018860 S.CER C1005 JB 0J 105K-T
C383 4030018860 S.CER C1005 JB 0J 105K-T
C384 4030016930 S.CER C1005 JB 1A 104K-T
C385 4030016790 S.CER C1005 JB 1E 103K-T
C386 4030018900 S.CER C1005 JB 0J 474K-T
C387 4030017460 S.CER C1005 JB 1H 102K-T
C389 4550007520 S.TAN F931A106MAABMA
C390 4030017460 S.CER C1005 JB 1H 102K-T
C391 4030017460 S.CER C1005 JB 1H 102K-T
C392 4030017460 S.CER C1005 JB 1H 102K-T
C393 4030016950 S.CER C1005 JB 1A 473K-T
C394 4030016950 S.CER C1005 JB 1A 473K-T
C410 4030017420 S.CER C1005 CH 1H 470J-T
C411 4030017420 S.CER C1005 CH 1H 470J-T
C412 4030017420 S.CER C1005 CH 1H 470J-T
C413 4030017420 S.CER C1005 CH 1H 470J-T
C414 4030017440 S.CER C1005 CH 1H 221J-T
C415 4030017440 S.CER C1005 CH 1H 221J-T
C417 4030017460 S.CER C1005 JB 1H 102K-T
C421 4030016790 S.CER C1005 JB 1E 103K-T
C422 4030016950 S.CER C1005 JB 1A 473K-T
C423 4550004040 S.TAN TEESVA 0J 685M8R
Eqv. 4550007170 S.TAN F930J685MAABMA
C424 4030017460 S.CER C1005 JB 1H 102K-T
C426 4030018860 S.CER C1005 JB 0J 105K-T
C427 4030016930 S.CER C1005 JB 1A 104K-T
C428 4030016960 S.CER C1005 JB 1E 183K-T
C429 4030016960 S.CER C1005 JB 1E 183K-T
C430 4030017730 S.CER C1005 JB 1H 471K-T
C431 4030016930 S.CER C1005 JB 1A 104K-T
C432 4030017460 S.CER C1005 JB 1H 102K-T
C433 4030016930 S.CER C1005 JB 1A 104K-T
C434 4030016950 S.CER C1005 JB 1A 473K-T
C435 4030018890 S.CER C1005 JB 0J 224K-T
J250 6450001910 CON HSJ1594-010150
J253 6510021901 S.CON BM02B-ASRS-TF(LF)(SN)
DS240 5040003060 S.LED SML-512WWT86
DS241 5040003060 S.LED SML-512WWT86
DS242 5040002310 S.LED SML-311YTT86
DS243 5040002310 S.LED SML-311YTT86
DS244 5040002310 S.LED SML-311YTT86
DS245 5040002310 S.LED SML-311YTT86
DS246 5030003001 LCD S11000-1 <SUC>
MC250 7700002710 MIC EM6027P-46C33-G <HOR>
S250 2260001900 SWI SW-149 (SKHLLD)
EP2 6910014690 S.BEA MPZ1608S221A-T
EP3 6910014690 S.BEA MPZ1608S221A-T
EP4 6910012350 S.BEA MMZ1608Y 102BT
EP5 6910012350 S.BEA MMZ1608Y 102BT
EP6 6910012350 S.BEA MMZ1608Y 102BT
EP7 6910012350 S.BEA MMZ1608Y 102BT
EP360 8930077940 LCD SRCN-3168-SP-N-W (SHJ)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T
T
T
B
B
B
T
T
T
B
B
B
T
T
B
B
B
B
T
T
B
B 105.1/29.3
B
B 103.2/34.4
T
T
T 105.3/41.8
T 103.4/46.4
T 109.6/38.1
T 100.8/44.3
T 100.8/45.2
T 103.4/45.5
B
B
B
B
B
B
B
B
B
B
B
T
B
B
B
B
T
T
T
T
T
T
B
B
T 103.0/43.1
T 105.4/39.8
T 111.8/35.7
T 104.8/45.4
H/V
94.9/41.3
96.6/41.3
99.3/40.7
93.1/41.3
95.0/30.9
95.6/32.1
84.7/35.9
87.5/35.2
89.9/37.8
89.0/38.1
9.1/28.2
9.4/26.1
12.2/25.4
87.3/13.4
99.5/14.3
27.6/46.2
13.9/37.8
79.8/44.3
9.1/35.1
90.0/39.3
91.3/41.5
90.9/23.5
60.4/45.2
97.5/41.3
92.2/41.5
14.1/39.1
52.6/47.6
45.2/39.4
54.3/44.5
75.8/37.6
73.9/42.1
74.4/43.3
69.2/45.3
69.1/44.1
68.5/42.0
74.3/35.2
98.4/41.3
68.7/38.2
73.7/39.7
99.5/27.7
78.9/39.3
92.2/4.7
99.7/4.7
47.7/34.0
62.9/34.8
47.7/18.4
62.9/17.6
72.3/16.0
80.4/13.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
4
S.=Surface mount
