- Page 2 CLEAR SET-UP AND CONFIGURATION Select amplifier type and activate through "drag and drop." Each amplifier is displayed showing address, operation mode, input level, and network mode (on-line/off-line). Double-click on one amplifier link to the individual control panel for more detail. Amplifiers and channels may be assigned to control groups on customized group control panels with dedicated control parameters.
- Page 3 STATE-OF-THE-ART SIGNAL PROCESSING WITH 24 FILTERS, 5 DELAYS , 2 COMPRESSORS AND 2 LIMITERS Menu control for selection of DSP parameters, speaker assign, impedance monitoring or protocol. Each block of DSP functions shows the amount of active parameters. Filter response, delay times and dynamic settings are displayed as a thumbnail. The DSP functions are: Master-EQ with five filters, each selectable as Low or Hi-Shelf, Low or Hi-Pass, or PEQ.
- Page 4 RANGE OF AMPLIFIERS FOR HIGH AND LOW-IMPEDANCE APPLICATIONS P3000 RL The flagship, with 2 x 1300 watts into 4 ohms and 2 x 1800 watts into 2 ohms, the digital controlled version of the legendary P3000 amplifier. Loudspeaker outputs on Neutrik Speakon NL4 connectors.
- Page 5 AUDIO PERFORMANCE, REMOTE CONTROL AND SUPERVISION AT THE HIGHEST LEVEL Electro-Voice is famous for its 75 years of experience in designing and manufacturing loudspeakers and microphones. Many audio professionals, however, don’t know that it also has 50 years of design experience in power amplifiers and more than 20 years in digital audio processing.
- Page 6 GP1 and GP2 RJ-45 CAN bus (in) connectors RJ-45 CAN Audio inputs bus (out) (from mixer) To Amp 2 NOTE: All amps link through CAN bus MEDIUM SYSTEM CONFIGURATION — PERFORMING ARTS CENTER ¤ Crestron touch screen Audio signal RJ-45 CAN...
- Page 7 ¥ Up to 250 amplifiers per system ¥ Up to 1000m per run ¥ Single run: No loop requirements Midas Heritage 3000 Audio signal Main PA FRi+122/64 (two per amp) Sky boxes Sx300PI (two per amp) Under-balcony fill Audio signal Main PA...
- Page 8 EVI Audio (Austl.), Unit 23, Block C, Slough Business Estate, Silverwater N.S.W. 2128, Australia, Phone: 61/2-9648-3455, FAX: 61/2-9648-5585 Hong Kong EVI Audio Limited, Unit E & F, 21/F, Luk Hop Industrial Bldg., 8 Luk Hop St., San Po Kong, Kowloon, Hong Kong, Phone: 852-2351-3628, FAX: 852-2351-3329 Japan EVI Audio Japan, Ltd.,5-3-8 Funabashi, Setagaya-ku, Tokyo, 156-0055 Japan, Phone: 81-3-5316-5020, FAX: 81-3-5316-5031...
