WisyCom MRK16 Quick User Manual page 2

Antenna Matrix
Green when area is active
Red if RF overload
Off is area in not active
Power Over Ethernet (PoE)
• Dual input (ETH2 & ETH4)
• Output (ETH1) to supply
external device (i.e. Wifi)
Dual redundant
USB-C
DC power input
Control &
• XLR-4M
Charging
9-28Vdc
5 ports manageable Gbit switch
• ETH1/3 control via Wisycom
Manager
• ETH2/4 Dante audio
• ETH5 internal optical SFP slot
(with MRK-SFP accessory)
Antenna Booster
Green if booster on
Red if antenna fault
Off if booster off
B A
T
2
4
SCAN SYNC
PWR MENU
EXIT SEL
fn
Bluetooth 5 long range
class 1 (100mW)
remote control
Analogue
AES59
Dual DB25 connector
DB25 connection
(Tascam standard):
AES72
Left: Rx 1 to 8
Dual Cat5 connection
Right: Rx 9 to 16
Power Supply
ON/OFF
Green if present
Switch and
Blue if used
Led
Red if voltage fault
Off if no power
B
ON BT
1 2
3 4
SCAN SYNC
fn
EXP2 Antenna outputs
GPIO
Chain the RFoF signal
General purpose
with the desired input
input/output
(optional)
Fan Module
Next generation
silent fan
Rotary Knob
• Rotate to adjust volume
• Quick push to select RX and confirm
• Long push to enter MRK16 setup
menu
Audio Monitoring
6.35mm plug mono to
listen any of the 16 RX
Optical connector
RF over fiber conenctor
LC/APC - Singlemode
Antenna Inputs
Dual zone antenna
inputs A1A2/B1B2
Antenna Outputs
Use the outputs to daisy
chain up to 4 MRK16
