First Team, Inc.
RETROFIT42
Assembly Instructions
Bill of Materials
A (1) RetroFit42 H-Frame Bracket
F (4) 3/8"x 1 ½" Carriage Bolt
B (8) 3/8" x 1 ¼" Hex Bolt
C (12) 3/8" Flatwasher
D (12) 3/8" Lockwasher
E (12) 3/8" Hex Nut
*Note: Immediately unpack components and cross check with bill of
materials. Report any shortages to First Team customer service at 1-888-884-
6677.
Advertisement
Table of Contents
Related Manuals for First Team RETROFIT42
Summary of Contents for First Team RETROFIT42
- Page 1 B (8) 3/8” x 1 ¼” Hex Bolt C (12) 3/8” Flatwasher D (12) 3/8” Lockwasher E (12) 3/8” Hex Nut *Note: Immediately unpack components and cross check with bill of materials. Report any shortages to First Team customer service at 1-888-884- 6677.
- Page 2 Your RetroFit42 H-Frame Backboard Support is designed to allow most First Team (42” tall) backboards to be hung on virtually any existing basketball post having a minimum 6”x6” mounting plate at the end of the post’s extension arm. 1. Unpack and lay backboard face down on flat surface.
- Page 3 tightening nuts. DO NOT OVERTIGHTEN NUTS! If the lockwasher is fully compressed, it’s tight enough. Attach coverplate to rim and hang net. 7. Finally, check rim height for 10’. If raising or lowering is necessary, loosen the (4) 3/8” hex nuts on the (4) carriage bolts and adjust as needed until rim is at 10’...
