Safco 5509 Assembly Instructions

5509 - Large
Parts List / Liste des Pièces / Lista de Piezas:
Top/Bottom Panel Back Panel
Panneau Supérieur/Inférieur Panneau Arrière
Panel Superior/Inferior Panel Posterior
Qty./Qté./Cant. 2 Qty./Qté./Cant. 1
440000150 #5509 - 420000207
#5510 - 420000211
Side Panel Leg Assembly
Panneau Latéral Assemblage des Jambes
Panel Lateral Ensamblaje de la Pier
Qty./Qté./Cant. 2 Qty./Qté./Cant. 4
#5509 - 420000182 #5509 - 410000342
#5510 - 420000183 #5510 - 410000343
Hardware Pack / Paquet Matérial / Paquete Material:
900000378
Wood Dowel 8mm x 30mm Screw 8/32 x 1/2"
Chivelle en Bois 8mm x 30mm Vis 8/32 x 1/2"
Pasador de Madera 8mm x 30mm Tornillo 8/32 x 1/2"
Qty./Qté./Cant. 12 Qty./Qté./Cant. 8
920000309 9050000531
Leg Assembly
Back Panel
For questions or concerns, please call 1-888-971-6225
available Monday-Friday 7:30 AM to 5:00 PM CST (English-speaking operators)
Product Warranty is available at: safcoproducts.com
99000372, Page 1 of 2, Rev A, Rev Date 04-MAY-2021
Stackable Storage |
5510 - Small
Allen Wrench 3/32
Clé Allen 3/32
Llave Allen 3/32
Qty./Qté./Cant. 1
920000575
Leg Assembly
Safco Ready™ Home Offi ce
1) Insert 1 dowel in each of the holes on the short edges of
the Back Panel, and tap with a rubber mallet until they
cannot be inserted any further.
Back Panel
2) Insert 1 dowel in each of the holes on the short edges of
the Side Panel, tap with a rubber mallet until they cannot
be inserted any further. Repeat this step for the other
Side Panel.
SIde Panel
3) Insert the Back Panel into 1 of the Top/Bottom Panels
until fully seated.
Top/Bottom Panel
Assembly Instructions
SKU# 5509/5510
Back Panel
