Assembly Instructions for Recliner
FRS62227R
PART
NO.
A
B
C
D
E
AA
M6*30
BB
CC
Step 2: Line up lower screw holes on back
frame (B) with corresponding screw holes on
seat frame (A). Secure with M6*30 bolt (AA)
and plastic washer (BB) using hex wrench (CC)
to tighten. Do not completely tighten screws
now. Please see Fig.2.
Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905-4107, 8:30 a.m. – 5:00 p.m. PST /11:30 a.m.- 8:00 p.m., EST, Monday- Friday.
NOTE: Do not completely tighten screws first!
DESCRIPTION
QTY
Seat Frame
1
Back Frame
1
Back Cushion
1
Seat Cushion
1
Pillow
1
Bolt
4
Plastic Washer
8
Allen Wrench
1
B
A
Fig. 1
Step 1: Attach back frame (B) to seat frame
(A) by lining up upper screw holes on back
frame (B) with corresponding screw holes
on seat frame (A). Secure with M6*30 bolt
(AA) and plastic washer (BB) using hex
wrench (CC) to tighten. Do not completely
tighten screws now. Please see Fig. 1.
B
A
Fig. 2
BB
AA
BB
BB
BB
AA
