NENKO 25002477 Quick Start Manual

1. Product
Gel Floor Tile - Red + Adaptor
2. Product Code
25002477
3. Description
A great visual experience that encourages everyone to move. Each illuminated tile is filled with liquid
gel. Step or move on the tile and make sure the liquid gel shifts in a particular pattern. The tile is
resistant to jumping and strenuous use by children and adults, as well ass the weight of a wheelchair.
the tiles can also be incorporated into a customized pvc floor mat. Antislip
4. Colour
Red
5. Sensory simulations
Vision
6. Technical Data
Size: 50 x 50 cm per tile
Adapter: AC100 240V / DC12V 3A (One adapter can hold up to 4 units)
Max power consumption: 8W / pc.
Lighting: 42 LEDs
Electricity specification: Working voltage: DC 12V ± 0.5V
7. Contents
Tile
Corner protectors
Adapter
8. Start-up
1. As one unit
Insert the adapter into the tile, then connect the plug to the adapter, plug it in and turn it on.
2. Two or more units
First check that each unit operates independently according to the instructions above. Once they all
work independently, you can connect all units together through the connectors on the base of each
tile. Assemble these connectors and connect one of the tiles to the adapter, then insert the plug into
the adapter and connect it to the wall.
3. See included in your package 4 corner protectors to be used. These should be glued to every
corner of every tile or series of tiles for your own protection. These are easy to apply, just take off
the back and hold it firmly on the corner of the tile until it is tight.
