O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. To make assembly easier, use the Hardware Identifier on page 9 to identify and sort all
fasteners. Check all cartons for kits. All hardware may not be located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together. Leave locknuts slightly loose until you are instructed to
tighten them.
5. Tools required for assembly: Phillips Screwdriver, 3/8 Wrench, and Two 7/16 Wrenches (adjustable
wrenches may be substituted for the wrenches).
6. Save this instruction and your proof of purchase (receipt) in the event that the manufacturer
has to be contacted for replacement parts.
Please Do Not Return This Product To The Store!
Contact Escalade
Phone:
1-866-873-3528
Fax:
1-866-873-3533
E-mail:
tabletennis@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
Sports customer service department at:
®
SPORTS PRODUCT INFORMATION
®
Toll – Free !
Toll – Free !
www.escaladesports.com
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
TABLE TENNIS TABLE
MODEL NOS.
T8612
T8612A
2L-4127-02
2013 Escalade Sports
Advertisement
Related Manuals for ESCALADE Stiga T8612
Summary of Contents for ESCALADE Stiga T8612
- Page 1 ® 2L-4127-02 Escalade® Sports products may be manufactured and/or licensed under the following patents. 6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563 Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
- Page 2 For aid in identifying hardware, see hardware identifier on page 9. Figure 1 Table Top U-support 1. Lay table top #1 painted side down, on a smooth, flat surface. Use the shipping container to protect the painted surface of the table top. Plastic Align U-Support (#7) and U-Leg (#2) on Table Top as shown in Figure 1.
- Page 3 This end is the middle of the table 35 (RH) Figure 3 Lay out rails #25 and 26, as shown in Figure 3, around edges of table top. Slide Left #36 and Right #35 Vinyl End Caps onto the ends of the Side Rails #25 as shown.
- Page 4 Figure 6 10. Attach end of linkages #4 with two holes to INSIDE of U-leg #2 as shown in Figure 6. Secure through end hole with screws #23, locknuts #15 and plastic spacers #31. Tighten hardware snug enough to keep table stable but do not overtighten.
- Page 5 19. Repeat steps 1 through 12 on second table half. CAUTION: 20. Gently tap caster sockets #12 into U-support #7 on second table half until flange on sockets touches the edge of the tube. DO NOT AT LEAST TWO ADULTS ARE NEEDED TO HIT CASTER SOCKETS TOO HARD WITH A HAMMER.
- Page 6 Figure 10 23. Make sure the legs on the first table top half (the half with the name panel #5) are open. With one person on each side of the table, lift and set table half on its legs. Place table against a wall as shown above to help stabilize table top half while second half is being attached. Be sure there is enough room to connect second half.
- Page 7 OPENING AND CLOSING INSTRUCTIONS READ OPERATING INSTRUCTIONS CAREFULLY BEFORE OPERATING TABLE! DO NOT ALLOW CHILDREN TO OPEN TABLE! DO NOT CLIMB, STAND OR JUMP ON TABLE! SERIOUS OR FATAL INJURY MAY RESULT! THIS IS NOT A TOY! TABLE IS CAUTION: TO BE OPENED OR CLOSED BY ADULTS ONLY! FAILURE TO COMPLY WITH OPENING AND CLOSING INSTRUCTIONS COULD RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE.
-
Page 8: 90-Day Limited Warranty
WARRANTY COVERAGE: ESCALADE SPORTS warrants to the original Consumer Purchaser that any Product of its manufacture is free from defects in material and workmanship when used for the intended purpose under normal use and conditions. THIS WARRANTY IS VOID IF THE... -
Page 9: Care And Maintenance
CARE AND MAINTENANCE You have purchased a quality product that will give you years of enjoyment. By following these simple maintenance steps, you will add to the life of your new table. THE TABLE TOP The top (playing surface) of your table is made of particle board. Like all products made of wood, it can be affected by atmospheric changes in both temperature and humidity. - Page 10 PRODUCT PARTS LIST - T8612 & T8612A Key # Part# Description Key # Part# Description 4A-5468-00 Table Top T8612 - 1/2” Black 1B-4089-00 #8-32 x 1 1/4” Sheet Metal Screw 4A-5468-05 Table Top T8612A - 5/8” Black 1B-6451-00 #8 x 7/16 Sheet Metal Screw #8 x 1 7/16 Hex/Phil Hd.
