REFRIGERATOR - FREEZER
Models CP972SS
CP962
Use and Care Guide
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
Felix Storch, Inc.
Summit Appliance Division
Write the Serial Number here:
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY10474
www.summitappliance.com
0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit CP962
Summary of Contents for Summit CP962
- Page 1 Models CP972SS CP962 Use and Care Guide BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS Felix Storch, Inc. Summit Appliance Division Write the Serial Number here: An ISO 9001:2015 registered company 770 Garrison Avenue Bronx, NY10474 www.summitappliance.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFEGUARDS ........................2 INSTALLATION ..........................2 - 8 Location ..............................2 Reversing the Door Swing ........................3 - 6 Door Space Requirements ........................7 Leveling the Unit ............................7 Cleaning before Use ..........................7 Before Using Your Unit ..........................7 Interior Accessories ........................... -
Page 3: Important Safeguards
1. IMPORTANT SAFEGUARDS 1) WARNING―Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. 2) WARNING―Do not damage the refrigerant circuit. 3) WARNING―Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. -
Page 4: Reversing The Door Swing
2.2 Reversing the Door Swing Tools Required: Phillips style screwdriver / Flat-bladed screwdriver / Hexagonal wrench Ensure the appliance is unplugged and empty. Adjust the two leveling feet to their highest position. We recommend you have someone to assist you. 1) Remove the right top hinge cover. - Page 5 3) Move the top-hinge and the top-door limit block and the door bearing bush to the other side. Remove the nut with sleeve. Take off the washer then move the axis to the other side and fix in place. Remove the door limit block Find the other door limit block, with screw mounting to the door 4) Disassemble the screws holding the bottom-hinge with a Phillips screwdriver.
- Page 6 5) Replace the bottom door bearing bush and the limit block. 6) Replace the bottom hinge to the other side, then fix it with screws 7) Replace the mid-hinge. 8) Set the bottom door right position, fix the mid-hinge.
- Page 7 9) Replace the top-hinge. 10) Set the upper door into the right position, fix the top-hinge and hinge cover. 11) Install the four screw caps and two catches to the corresponding positions. 12) Replace the leveler to the other side and adjust it to make sure the cabinet is level.
-
Page 8: Door Space Requirements
2.3 Door Space Requirements The unit's door must be able to open fully as shown. W×D ≥ 35.5 X 41.4 inch 2.4 Leveling the Unit To do this, adjust the two leveling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly. -
Page 9: Interior Accessories
2.7 Interior Accessories Various glass or plastic storage shelves are included with your appliance – different models have different combinations. You should always slide one of the full-size glass storage shelves into the lowest set of guides, above the fruit and vegetable container (crisper), and keep it in this position. To do this, pull the storage shelf forward until it can be swiveled upwards or downwards and removed. -
Page 10: Location Of Parts
3. LOCATION OF PARTS Steel shelf Thermostat Refrigerator tray Glass shelf Crisper cover Crisper Adjustable foot *All images in this instruction manual are for indication only; please refer to your individual unit for details. -
Page 11: Operation
4. OPERATION 4.1 Switching On Your Unit The temperature selector knob is located on the right hand wall of the refrigerator interior. Setting “Off”：Unit Off Setting “Min”：Less Cool Temperature Setting “Med”：Normal Operation (adequate for most situations) Setting “Max”：Coolest Temperature ... -
Page 12: Cleaning
5. CLEANING 5.1 Cleaning the Interior and Exterior of the Unit Remove all the shelves and the crisper. To remove the crisper, first remove the lower door shelf. Wipe the inside of the unit with a weak solution of bicarbonate of soda and then rinse with warm water using a wrung-out sponge or cloth. -
Page 13: Maintenance
6. MAINTENANCE 6.1 Defrosting This appliance combines a manual defrost freezer compartment and an automatic defrost refrigerator compartment. The refrigerator compartment defrosts itself, but when frost builds to ¼ inch in the freezer compartment, you should defrost it carefully according to this procedure: 1. -
Page 14: Troubleshooting
If the problem is not due to one of the items listed above, contact the dealer or authorized service company. You can also call our SUMMIT® Customer Service line at 1-800-932-4267 weekdays from 8:30 AM to 5:00PM (ET). 7.1 Normal phenomena: 1. -
Page 15: Tips For Energy Saving
8. TIPS FOR ENERGY SAVING Try not to open the doors too often, especially when the weather is damp and hot. Once you open a door, close it as soon as possible. Every now and then check if the appliance is sufficiently ventilated (adequate air circulation behind the appliance). ... -
Page 16: Limited Warranty
10. LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory- specified parts and repair labor to correct defects in materials or workmanship.
