Summary of Contents for TMI Products VD3 Series
- Page 1 01032021 TECHNICAL GUIDE & PARTS CATALOGUE Cal.VD3 Series (VD33B/34B) ANALOGUE QUARTZ...
-
Page 2: Specification
Version-01 SPECIFICATION Cal.VD3 Series (VD33B/34B) Cal. No. VD33B VD34B Item Movement φ29.50 mm × 26.00 mm (3H-9H) Outside diameter Movement φ28.80 mm Casing diameter size Total height 4.57 mm 3.97 mm 3 Hands (Hour, Minute, Second) 3 Hands (Hour, Minute, Second) -
Page 3: Parts Catalogue
Version-01 PARTS CATALOGUE Cal.VD3 Series (VD33B/34B) Oil quantity Lubricating : Types of oil ㊺ ① → NORMAL QUANTITY Disassembling procedures Figs. Moebius 9010 ㊺ ① → Reassembling procedures Figs. Moebius 9030 ① 0012 079 ② 0808 368 (Cal.VD33 only) Auxiliary train wheel bridge screw Date dial guard ③... - Page 4 Version-01 PARTS CATALOGUE Cal.VD3 Series (VD33B/34B) Oil quantity Lubricating : Types of oil ① ㊺ → NORMAL QUANTITY Disassembling procedures Figs. Moebius 9010 ㊺ ① → Reassembling procedures Figs. Moebius 9030 ⑲ Battery ⑳ Winding stem 0351 177 (Cal.VD33) ㉑...
- Page 5 Version-01 PARTS CATALOGUE Cal.VD3 Series (VD33B/34B) Oil quantity Lubricating : Types of oil ① ㊺ → NORMAL QUANTITY Disassembling procedures Figs. Moebius 9010 ㊺ ① → Reassembling procedures Figs. Moebius 9030 ㉛ 0125 248 Train wheel bridge (A) ㉜ *Fourth wheel and pinion ㉞...
- Page 6 Version-01 PARTS CATALOGUE Cal.VD3 Series (VD33B/34B) Remarks: ③ Date dial (Cal.VD33 only) Position of Position of Color of Color of Part code crown date frame figure background 0878 220 Black White 0878 221 White Black Parts code Parts code Page...
-
Page 7: Technical Guide
Version-01 TECHNICAL GUIDE Cal.VD3 Series (VD33B/34B) ・The explanation here is only for the particular point of Cal.VD33&VD34 1.REMARKS ON INSTALLING THE BATTERY (1) Battery ・How to install the battery ① Remove the hook of the switch springs battery clamp portion. - Page 8 Version-01 TECHNICAL GUIDE Cal.VD3 Series (VD33B/34B) 2.To remove the winding stem (1) set the winding stem to normal position. (2) While pushing the indented portion of the arrow, pull out the winding stem. Push 3.How to attach hands Please put on the metal plate so as to avoid 6 protrusions.(Right figure:place of red circle)
-
Page 9: Operation
Version-01 OPERATION Cal.VD3 Series (VD33B/34B) DISPLAY AND CROWN / BUTTON OPERATION Minute hand Button A: - 1 hour / push Hour hand Dual time of 12 hour regulator hand adjustment First position VD33:First setting Dual time of 12 hour regulator hand... -
Page 10: Time Setting
Version-01 OPERATION Cal.VD3 Series (VD33B/34B) TIME SETTING 1.Pull out the crown when the second hand is at the 12 o'clock position. [ Crown position ] VD33:Second click VD34:First click 2.Turn the crown to set the hour and minute hands. (Check that 24 hour hand is set correctly) 3.Push the crown back normal position in accordance with... - Page 11 Version-01 OPERATION Cal.VD3 Series (VD33B/34B) DATE SETTING (Cal.VD33 only) *Before setting the date, be sure to set the time. 1.Pull out the crown to the first click. 2.Turn the crown to clockwise until the next date appears. 3.Push the crown back in to the normal position.
