- Page 1 Solo BC Style DIY Electric Guitar Kit Assembly Manual BCK-10 V 1.02 Copyright © 2011 Solo Music Gear. All rights reserved...
- Page 2 Post your photos to The Solo Café http://TheSoloCafe.com Remember, you can always find us online at http://SoloMusicGear.com to upgrade your parts, try a new kit, or ask us a question. Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
-
Page 3: Tools And Materials Needed
STEP 1 – The body and neck have been coated with a poly resin sealant. They need to be sanded before finishing. DO NOT SAND THE FINGERBOARD. For sanding both neck and body, use a flat sanding block for all flat surfaces and by hand for edges and Copyright © 2011 Solo Music Gear. All rights reserved v1.02... - Page 4 – you will be using these two screws later to adjust springs tension. Gently tap the bushings into place. Screw in the pivot studs. Mount the tremolo bridge into recess on guitar top. Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
- Page 5 Before mounting the toggle switch use the switch ring – find the proper position of the switch by rotating it, then tighten all mounting nuts. Before mounting the control cavity cover it’s good to check Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
- Page 6 String height is adjusted by the bridge height of tune-o-matic bridge. You may use a flat screwdriver to turn the adjustable studs – turning the stud clockwise sets the bridge lower, turning it counterclockwise sets it higher. Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
- Page 7 This method is less accurate because the fretted string sounds a bit sharper due to the height of the string, and the higher the action, the sharper it gets. Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
- Page 8 – you may find it more satisfactory sounding by setting it somewhat angled, depending on what you are looking for in the output sound. There are a few mm of real usable range where you can find the pickup tone that you’ll like the best. Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
- Page 9 Solo BC Style DIY Electric Guitar Kit BCK-10 Wiring Diagram Copyright © 2011 Solo Music Gear. All rights reserved v1.02...
