Troubleshooting Guide - Forza SL-802UL-A User Manual

UPS mode
Battery mode
The icon is displayed when
battery level is low
Overload in battery
mode
The icon is displayed on the
screen

7. Troubleshooting guide

If the UPS system does not operate correctly, use the table below to troubleshoot the problem.
Fault condition
The output is short circuited
Overload fault
Overcharge
Defective or severely
discharged battery
High output voltage
Over-temperature
For further assistance, please contact us at tech@forzaups.com
LCD Description
When the UPS is in battery mode and
battery voltage begins to dwindle, the unit
will beep once every 10 seconds. Also when
the LCD is touched, the information will be
displayed in the following order:
1. Output voltage
2. Input voltage
3. Load level
4. Battery capacity
When the UPS is overloaded, the unit
beeps every 0.5 second to warn about
such condition
LCD Solution
Disconnect short-circuited
loads and restart the UPS
Remove all connected loads
and restart the UPS
Call for technical assistance
immediately
Please replace the battery
Call for technical assistance
immediately
1. Turn off and wait for the unit
to cool
2. Or remove excessive loads
and wait for the unit to cool
8. Technical specifications
MPN SL-802UL-A
General
Capacity
800VA/480W
Input
Nominal voltage
Voltage range
Frequency
AC plug style
Output
Nominal voltage
Frequency
Frequency stability
Waveform
4 (Argentina Type I)
Total outlets
Full battery with surge
3
protection outlets
Surge protection only outlets 1
Network protection
Phone/modem/fax protection
USB Management
Battery
Battery type and quantity
12V /9Ah (1)
Backup time 32 min**
Recharge time
Voltage regulation
High cutoff
Boost
Buck
Low cutoff
Frequency regulation
Automatic frequency
regulation
Line/Battery transfer
Typical transfer time
Low-line transfer to battery
High-line transfer to battery
Alarms/Indicators
Easy to read LCD with blue backlight that displays battery status, input
Visual indicators
Audible tone
Protection
Joules 510J
Special features
Cold "start option"
Auto charge
Environment
Operating temperature
Storage humidity
Relative humidity
Audible noise
Physical appearance
Housing
Color
Dimensions 11.8x3.9x 5.6in
Weight
11lb
Additional information
Warranty
* 2 years on batteries
**Calculated with a single PC plus monitor
SL-1012UL-A
1000VA/600W
220V
162-268VAC
45-65Hz (autosensing)
Argentina Type I
220V +/- 10%
50/60Hz
+/- 1Hz battery mode
Modified sine wave
6 (Argentina Type I)
5
1
RJ-45
RJ-11
Included with ForzaTracker software
12V / 7Ah (2)
50 min**
4 hours to 90% after complete discharge
268V +/- 5%
162-204V +/- 5%
236-268V +/- 5%
162V +/- 5%
Included
2-4ms
162VAC +/- 5%
268VAC +/- 5%
voltage, output voltage, load level, and UPS status
Battery mode: Sounds every 10 seconds
Low battery: Sounds every second
Overload: Sounds every 0.5 second
Fault: Sounds continuously
660J
Included
Included
32-104°F
-4-113°F
0-90% non-condensing
<40dB at one meter
ABS fire retardant plastic
Black
12.6x5.1x7.2in
17.6lb
3 years *
