Function and working temperature range.
Introduction
Cooling in summer
In hot summer, Air conditioner can cool down
room air by transferring heat out.
Operating auto
According to room temperature change, microcomputer can automatically set COOL or FAN operation mode,
so as for the best effect.
Window type room air conditioners of GREE can regulate the room
temperature,dry the room. It is convenient for your work,study and
life. It can be widely used in residence, shop, hotel, office, library and
laboratory, and so on.
Dehumidifying in rainy or
humid season
Without reducing room temp, Air conditioner
can dehumidify and make room air dry and
comfortable.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KC-32/C1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GREE ELECTRIC KC-32/C1

Summary of Contents for GREE ELECTRIC KC-32/C1

  • Page 1 Function and working temperature range. Introduction Window type room air conditioners of GREE can regulate the room temperature,dry the room. It is convenient for your work,study and life. It can be widely used in residence, shop, hotel, office, library and laboratory, and so on.

  • Page 2: Technical Specifications

    Technical Specifications Model KC-32/C1 KC-32/C1A Function Mechanic control cool only type Remote control cool only type Cooling capacity(w) 3200 Power supply 220-230V~ 50Hz Power input(w) 1880 Refrigerant Noise (dB(A)) (indoor/outdoor) Climate type Dimension(cm) Weight (Kg) If there is any change, we will not give you notice here, the correct parameter is in the nameplate of your air-conditioner.

  • Page 3: Operating Condition

    Operating Condition Please operate air condition in correct conditions as following Cool mode operation DRY mode operation Outdoor temperature should be in range of 18 Outdoor temperature should be in range of 18 to 43 , to 43 , Otherwise it is possible for air conditioner otherwise it is possible for air conditioner to breakdown.

  • Page 4: Installation

    Installation Caution for use: Please associate special technician to install the window type conditioner. Install air conditioner unit far away TV set or radio etc.,to avoid disturbing video or voice. In salt and coastal area or place where is near thermal springs and polluted by sulphurous gas, or other special areas, please contact with seller before use.

  • Page 5: Installation Procedure

    Installation procedure: 1.Remove sticker from front panel. 2.Put unit into installation hole. When installation,unit Horizontal line should be slanted down to the back to avoid enlarge of noise or vibration.(slant between 6-10mm) Installation place should be strong enough to avoid enlarge of noise or vibration.

  • Page 6: Installation Precaution

    Installation precaution Remove When remove air conditioner to other place, it needs special technician, so contact with seller firstly. Noise * Install on place firmly enough to avoid transmitting or increasing noise and vibration. * Do not put objects in front of outdoor unit air outlet, to avoid increasing noise. * Be sure not to make trouble to neighbors with hot air or noise from outdoor unit.
  • Page 7 Product Component Identification of Mechanic control of Window type air condition Air intake grill Air outlet grill Control panel Control panel HIGH Thermostat Power supply cord Air filter Operating instructions Auto swing Switch Directs the cool air right and SWING left automatically.

  • Page 8: Refrigeration Principle

    Air-conditioning Principle Refrigeration principle Accomplished by continuously circulating of refrigerant in a closed system. Low pres- sure refrigerant gas from evaporator is pumped, increased its pressure, and discharges to the condenser by compressor. When axial flow fan working, heat exchanging occurs between the high pressure gas and outside air,it changes into liquid.Then passing through the capillary tube,it’s pressure and temperature becomes lower and lower.
  • Page 9 Mechanic control of Windows type air conditioner operation procedure Turn the main switch to position, air-conditioner stop work. Turn the main switch to position, just operates the fan. Turn the main switch to the position as follow: Cooling with low fan. Cooling with middle fan.

  • Page 10: Remote Control Operation Procedure

    Remote control operation procedure Name and Function-Remote control Note: Be sure that there are no obstrutions between reciever and remote controller. The remote control signal can be received at the distance of up to about 8m. Don’t drop or throw the remote control. Don’t let any liquid in the remote controller and put the remote controller directly under the sunlight or any place where is very hot.
  • Page 11 Name and Function-Remote control Note: This type of remote controller is a kind of new current controller. Some buttons of the controller which are not available to this Air conditioner will not be described below. Operate on unmentioned buttons would not impact on the normal use.

  • Page 12: Cool Mode Operation Procedure

    COOL mode operation procedure According to difference between room temp. and set temp., microcomputer can control cooling on or not. If room temp. is higher than set temp.,compressor runs at COOL mode. If room temp. is lower than set temp., compressor stops and only indoor fan motor runs. SET TEMP.

  • Page 13: Dry Mode Operation Procedure

    DRY mode operation procedure If room temp. is lower than set temp.,compressor, outdoor and indoor fan motor stop.If room temp. is between of set temp., Air conditioner is drying. If room temp. is higher than set temp. 2 , it’s at COOL mode. SET TEMP.should be in range of 16 to 30 AUTO SWING...

  • Page 14: Sleep Mode Operation Procedure

    SLEEP mode operation procedure As the unit is cooling or drying ,if SLEEP operation is set, SET TEMP. would increase 1 in 1 hour and 2 in 2 hours. SWING 4.Press FAN button, set fan speed. 2.Press MODE button. eration mode. 6.SLEEP button Press it to set SLEEP operation.

  • Page 15: Auto Mode Operation Procedure

    AUTO mode operation procedure Under Auto mode operation, standard SET TEMP. is 25 for COOL mode, fan speed can be changeable. If room temp. is in range of 23 to 26 , air conditioner is at FAN mode. If room temp. is higher than 26 , it’s at COOL mode. AUTO 2.Press MODE button, operation mode,...

  • Page 16: Timer Mode Operation Procedure

    TIMER mode operation procedure T-ON button At stopping, press T-ON button, set ON TIME in range of 0 to 24 hour to start the unit automati- cally. Timer cancellation T-ON T-OFF T-OFF button At operating, press T-OFF 1 / 0 button, set OFF TIME in range of 0 to 24 hour to stop the unit automatica-...

  • Page 17: How To Insert Batteries

    How to insert batteries 1.Remove the cover from the back of the remote control. 2.Insert the two batteries (Two AAA dry - cell batteries). 3.Re - attach the cover. Remove the NOTE: cover. Don’t confuse the new and worn or different Re - attach types of batteries.

  • Page 18: Operation Tips

    Operation Tips Operation for comfort and economy Do not overcool the room Keep the room, Do not let sun- Keep blind or curtains closed, temperature, This is not good for shine enter the room directly Adjust the vertical and horizontal health and waste electricity.

  • Page 19: Emergency Run Operation Procedure

    Emergency run operation procedure If wireless remote controller is lost, open the surface panel and operate as following: Note: When operating emergency switch, we should use something rigid and long, with its size less than 2.5mm in diameter. Exert properly to avoid damage. * According to room temp.
  • Page 20 Caution 1) The plug must be accessible after the appliance is positioned. 2) Do not use this appliance in the laundry. 3) If the power cord is damaged, it must be replaced by the manufacture or its service agent in void of hazard. Do not use the air conditioner Do not pull out the power cord.

  • Page 21: Care And Maintenance

    Care and maintenance Always turn off the air conditioner and main power supply before cleaning to ensure safety. Clean unit Air filter 1. Plug out first before cleaning. The air filter behind the intake grille should be washed at least every two weeks or as often as it needs cleaning.

  • Page 22: When Trouble Shooting

    When trouble shooting Please check the following items before ask for repair,it saves your time and money. Fault phenomenon Trouble-shooting * Is power fail? * Is plug out? * Is power fuse or switch off? Air conditioner dose not * Is voltage higher than 253 or lower than 198? operate at all * Is SET TIME suitable? * Is air inlet or outlet locking?
  • Page 23 Immediately stop all operations and plug out,contact with your dealer in the following situations. *Operation starts or stops abnormally; *Power fuse or switch often breaks; *Carelessly splash water or something into air conditioner; *Electrical lines are much hot or lines cover breaks; *Other strange situations.
  • Page 24 WINDOWS TYPE ROOM AIR CONDITIONER OPERATING MANUAL MODELS: Tüv Rhelnland Thank you for choosing a GREE Air conditioner. Please read this OPERATING MANUAL carefully prior to use.
  • Page 25 GREE ELECTRIC APPLIANCES. INC. OF ZHUHAI Add:JinJi West Rd.Qianshan Zhuhai,Guangdong China Tel:(0756)8617555(After-sale Service Dpt.) Cable: 8143 Post code: 519070 C GREE 66161006...
