WARNING To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture. The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage’ within the unit’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons The exclamation point within a quilateral triangle is intended to alert the...
Page 3
8. Accessories - Do not place this unit on an unstable can, stand, tripod, bracket, or table. The unit may fall, causing serious injury to a child or adult, and serious damage to the unit. Use only with a can, stand, tripod, bracket, or table recommended by the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer, 9.
Page 4
15. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock, 16. Object and Liquid Entry - Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or shod-out pads that could result in a fire or electric shock.
Page 5
TABLE OF CONTENTS 1. DESCRIPTION AND CONTROLS . 2. SETTING-UP REMOTE CONTROL UNIT 3. ORERATION OF REMOTE CONTROL 4. SETTING-UP THE UNIT 5. HOW TO CONNECT TO A TV MONITOR AND EXTERNAL EQUIPMENT 7 6. HOW TO USE AUTO FOCUS 7.
Page 7
CAMERA HEAD Rotate to shoot the printed material and three-dimensional objects in shooting area and to shoot the distance objects. REMOTE CONTROL STORAGE Remote control unit works also when seating in the remote control storage. S-VIDEO OUTPUT JACK Used to connect TV monitor or VCR with S-VIDEO input jack. VIDEO OUTPUT JACK (2) Used to connect TV monitor or VCR with video input jack.
Page 8
To insure safe operation, please • Use(2)AA type batteries. • Do not use different type batteries and a new and with a used battery. • Do not discharge and disassemble a battery. • Be sure the battery polarity should be set properly and do not contact anode and cathode terminal.
Page 10
CAUTION Disconnect power for setting up the unit. 1. Remove two legs from Leg stopper. 2. Spread two legs to the set up position. Lift up the legs to the set up position. 4. Rotate Camera head until Lens is aiming just below. Remove a Remote control unit.( it also works while it is seated in the Remote Control storage.
Page 11
CONNECT THE UNIT AND TV MONITOR WITH VIDEO CABLES SUPPLIED AS STANDARD ACCESSORIES. Video output jack of the unit connected to video input jack (S-VIDEO or VIDEO) of TV monitor with video cable. How to use S-VIDEO output jack. S-VIDEO and VIDEO signal are output simultaneously and the unit can be connected to a TV monitor with S-VIDEO input jack and VIDEO input jack respectively.
Page 12
There are three kinds of auto focus mode One-Shot Auto Focus Mode This mode is to fix the focus just once when an image is set up on screen, so it is proper for the still material or object. Auto Focus Mode This mode is to let focusing meet each image, so it is proper for the moving material or when materials are changed frequently.
Page 13
A. When displaying printed material. 1. Connect power of the unit. Blue back image appears on the monitor and then image of the printed material will be displayed. 2. Put the printed material below the lens and operate Zoom switch watching TV monitor according to the size of the material.
Page 14
Lens shooting Area (*1) Zooming Focusing Iris TV system Image pick-up element All picture element Effective picture element Synchronization Horizontal Resolution S/N ratio Video output level White balance Auto Shutter speed Brightness Adjustment (*2) Default Input terminal Output terminal f=5.4-64.Smm(F1 .8-2.7)+conversion lens 320x236mm(Max,) *1 28 X 21 mm(Min.) (12X)electric power zoom lens...
Page 15
Power supply Power consumption Dimensions Weight Standard accessories Operation Temperature Operation Humidity Shooting area will get a little bit smaller than 320X236mm when monitoring at overscanning. *1All functions can be controled only by the remote control unit. AC Adaptor DC 6.5V (as standard Acc.) 350(W) X 275(D) X 463(H)mm(SET-U P) 130(W)X500(D)X85(H)mm(FOLDED) 1.5Kg...
Page 16
EIKI INDUSTRIAL CO., LTD. 4-12 Banzai-cho Kita-ku OSAKA, JAPAN Tel:6-63I l-9479~Fax:6-63l 1-8486 EIKI INTERNATIONAL, INC. 26794 Vista Terrace Drive, Lake Forest, CA92630-8! 13 U.S.A Tel :949-4570200• Fax:949-457-7877 EIKI INTERNATIONAL,INC.CANADA BR. P.O. BOX 156 310 First Street Unit 2 Midland. Ontario. L4R 4K8 Canada Tel:800-563-3454•...
