owner's
manual
MODEL NO.
572.826121
CAUTION:
Read all instructions
carefully before starting
the installation.
Save this Manual for
future reference.
F642-9201
(10/18/94)
PRINTED IN U.S.A.
CRAFTSMAN
BATTERY OPERATED
BACKUP SUMP PUMP
SEARS CANADA INC.
• Installation
• Operation
• Repair Parts
TORONTO CANADA M5B 2B8
Advertisement
Table of Contents
Related Manuals for Sears CRAFTSMAN 572.826121
Summary of Contents for Sears CRAFTSMAN 572.826121
- Page 1 BACKUP SUMP PUMP owner’s manual MODEL NO. 572.826121 CAUTION: Read all instructions • Installation carefully before starting the installation. • Operation • Repair Parts Save this Manual for future reference. SEARS CANADA INC. F642-9201 (10/18/94) TORONTO CANADA M5B 2B8 PRINTED IN U.S.A.
- Page 2 ALL PARTS .......TWO (2) YEARS ALL LABOUR .....ONE (1) YEAR Sears will repair or replace the pump free of charge if it fails due to manufacturing defects. Damage caused by improper installation is not covered by this warranty. This warranty is in addition to any statutory warranty.
- Page 3 GENERAL INFORMATION Keep battery charger dry and protected from damage. The Battery-Powered Back-up Sump Pump is not a sub- stitute for your primary sump pump. It is designed as a In an emergency (such as an extended power outage) backup pump to pinch-hit for your primary sump pump which depletes the system battery, your automobile during a power outage or other problem which prevents battery may be temporarily substituted.
- Page 4 10. Using PVC glue, permanently reinstall tee in primary up well to long periods of little or no use. sump pump discharge pipe. In an emergency a Sears DieHard Size 27M or 24M stan- Hazardous fumes. Follow cement manu- dard automobile battery may be used. However, an auto- facturer’s instructions.
- Page 5 ELECTRICAL CONNECTIONS BATTERY MAINTENANCE Hazardous voltage. Can cause serious or NOTICE: To protect battery case from chipping and fatal electrical shock. Never operate charger unless it is gouging, do not let battery sit on concrete floor. Install grounded. battery on a shelf or protective pad (plywood, 2x4s, etc.). Always install battery in a dry location that is protected The charger has a three-prong electrical plug.
- Page 6 TROUBLESHOOTING 10. Remount block on band and cord clamp assembly on pump. Pump won’t run. 11. Strip black switch wire back 3/8" (9.5mm) from end of 1. Check all connections. wire. Crimp wire terminal onto end of wire and check 2.
- Page 7 SEARS Battery Backup Sump Pump Model 572.826121 REPAIR PARTS LIST Key No. Part No. Part Description PS217-5E Switch Assembly # PS17-41 Pump Complete*** U197-10 Cord Clamp Assembly U17-1148 Fuse Holder U17-1149 15-Amp Time-Delay Fuse (2 supplied †) Wire Terminal (4 Req.) Battery Terminal Clamps (2 Req.)
