Sygonix 2338745 Operating Instructions

Operating Instructions
Solar Garden Light
Item No. 2338745
Intended use
The product is intended for use as decoration and is not suitable for domestic lighting. A flicker-
ing, amber-colored LED serves as the illuminant. The light turns on automatically at nightfall.
The product is powered by a battery that recharges via the integrated solar panel during the
daylight hours.
The product has an IP44 ingress protection rating. It is splash proof and suitable for outdoor
use. Do not submerge!
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged.
In addition, improper use can result in short circuits, fires or other hazards. Read the instruc-
tions carefully and store them in a safe place. Make this product available to third parties only
together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• 1x solar garden light (1x rechargeable battery inserted)
• 2x standpipes
• 1x ground spike
• Operating instructions
Up-to-date operating instructions
Download the latest operating instructions at www.conrad.com/downloads or
scan the QR code shown. Follow the instructions on the website.
Explanation of symbols
The symbol with the exclamation mark in the triangle is used to indicate important
information in these operating instructions. Always read this information carefully.
This product is constructed according to protection class III.
The arrow symbol indicates special information and advice on operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling in this manual, we assume no liability for any resulting per-
sonal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
a) General information
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become dan-
gerous playing material for children.
• Protect the product from extreme temperatures, strong jolts, flammable gases,
steam and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Do not short circuit the battery terminals.
• Consult an expert when in doubt about the operation, safety or connection of the
product.
• Maintenance, modifications and repairs must only be completed by a technician
or an authorised repair centre.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
b) LED light
• Attention, LED light:
- Do not look directly into the LED light!
- Do not look into the beam directly or with optical instruments!
c) Rechargeable battery
• Correct polarity must be observed while inserting the rechargeable battery.
• The rechargeable battery should be removed from the device if it is not used
for a long period of time to avoid damage through leaking. Leaking or damaged
rechargeable batteries might cause acid burns when in contact with skin, therefore
use suitable protective gloves to handle corrupted (rechargeable) batteries.
• Rechargeable batteries must be kept out of reach of children. Do not leave re-
chargeable batteries lying around, as there is risk, that children or pets swallow
them.
• Rechargeable batteries must not be dismantled, short-circuited or thrown into fire.
Never recharge nonrechargeable batteries. There is a risk of explosion!
Operating elements
1 2 3 4
Assembly
1
1. Assemble the shaft as shown.
2. Connect the shaft to the base
Location
• Insert the ground spike (6) into a level and suf-
ficiently firm surface (e.g. soil). A stony subsurface
will cause damage to the ground spike.
Hold the ground spike while inserting. Do not hold
the lamp head (1). This helps prevent damage to
the lamp head.
Make sure the ground spike is inserted securely
and cannot tip over.
• To optimize charging, place the solar panel (2) in a
location exposed to maximum sunlight. Do not set
up the solar panel in the shade or under any cover.
• Do not install the product in the direct proximity of
other light sources such as yard or street lights, oth-
erwise the product will not switch on automatically
at nightfall.
• The product is suitable for use in unprotected outdoor areas. Do not submerge!
Solar charging
When using for the first time or after prolonged periods of low sunlight, you should fully re-
charge the battery.
Operation
For first time use, remove the battery insulation strip. See section "Operation -
a) First time use and light on".
a) First time use and light on
This product comes with a battery installed. For first time use, you must remove the battery
insulation strip to activate the power supply.
1. Gently turn the lamp head (1) anticlockwise to unlock, then remove it from the base (3).
2. Find the battery insulation strip on the bottom of the lamp head (1) and simply pull the bat-
tery insulation strip out of the battery compartment.
3. Reattach the lamp head to the base (2).
When detaching or reattaching the lamp head from the base, make sure no moisture
enters the battery compartment.
1
2
1 Lamp head
2 Solar panel
3 Base
4 Upper standpipe
5 Lower standpipe
5 6
6 Ground spike
2
3
Battery
insulation sheet
