ASSEMBLY INSTRUCTIONS
8'X10' SEG BACKWALL - SEG810WSGH
IMPORTANT SAFETY INFORMATION:
Please take time to read all instructions before start assembling the unit. Be sure you fully understand all of the
steps needed to finish the assembly. Two or more persons are required.
PARTS LIST
A. Bottom Panel (with holes to fit Foot Plate)
B. Top Panel
C. Middle Panel
D. Side Panel
E. Support Bar - Horizontal
F. Support Bar - Vertical
G. Foot Plate
H. Corner Connector
I. Flat Head Screw
J. Wing Nut
K. Bar Connector
A
B
C
D
E
NOTE:
(1) Lay out all extrution panels on a clean, non-abrasive surface and identify each part.
(2)
Make sure that you have all included parts before you begin the assembling.
(3) The SEG frame is 8' in height and 10' in width. The assembling space must be large enough to house the
entire frame.
(4) For your safety, DO NOT use ladder when assembling the SEG backwall.
(5) Every panel/bar has numbers on both ends. Assemble the frame by matching the numbers.
Ver. 05/19
