SPE BEF320-2A Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BEF320-2A
Operating Manual
This manual is provided to persons purchasing an
SPE machine and may not be reproduced in part or full
without written permission of
SPE International Ltd.
This manual provides the basic information required
and is only to be used as a guideline.
The SPE machines are manufactured and covered by
SPE design registrations granted and pending.
SPE International Ltd reserves the right to alter the
equipment design and specification as required
without notice.
The SPE product range is subject to amendment and
improvement as a result of on going research
Honeyholes Lane, Dunholme, Lincoln LN2 3SU, England
Tel: +44 (0) 1673 860709 Fax: +44 (0) 1673 861119
Email:
sales@spe-int.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEF320-2A and is the answer not in the manual?

Questions and answers

Related Manuals for SPE BEF320-2A

Summary of Contents for SPE BEF320-2A

  • Page 1 BEF320-2A Operating Manual This manual is provided to persons purchasing an SPE machine and may not be reproduced in part or full without written permission of SPE International Ltd. This manual provides the basic information required and is only to be used as a guideline.
  • Page 3 WARNING Failure to follow this instruction may result in serious personal injury or death. SPE disclaims all responsibility for damage to persons or objects arising as a consequence of incorrect handling of...
  • Page 4 BEF320-2A Operating Manual INDEX Page No Starting Work General Operation Dust Control Maintenance Basic Maintenance Checklist Safety Accessories 9-11 Cutter Drum Set Up Spare Parts Breakdown Body Components Undercarriage Components Height Adjuster Components Drum Drive Components Hydraulic Tank Components Hydraulic Drive Components...

  • Page 5: Starting Work

    BEF320-2A Operating Manual STARTING WORK CHECK the following prior to starting the equipment: - Check condition of cutter drum assembly - Check all bolts for tightness - Check drive belt condition and tension - Check drive pulleys are undamaged and clean...

  • Page 6: General Operation

    To control any dust created by the operation connect an industrial dust collector or vacuum to the 50mm port at the side of the machine. We recommend the SPE 316 for almost 100% dust control. In the absence of a dust control unit it is acceptable to spray water onto the surface or to feed water down the vacuum port.

  • Page 7: Maintenance

    BEF320-2A Operating Manual MAINTENANCE PRIOR TO ANY MAINTENANCE OR ADJUSTMENT STOP ENGINE. After use: Clean the machine to remove all build up of dust and surface residues. Drum Removal: Remove bolts on side plate and then screw two bolts back into the two tapped holes in the side plate.
  • Page 8 BEF320-2A Operating Manual Height Adjustment Maintenance: Ensure the height screw thread is cleaned and then lightly oiled. Periodically it should be removed and the female threaded section cleaned out and oiled. At the same time the self-aligning bearing should be greased.
  • Page 9 BEF320-2A Operating Manual BASIC MAINTENANCE/CHECKLIST DAILY: (or every 8hrs to 10hrs) Check cutters Check flail shafts Check all bolts and nuts for tightness Check belt tension Clean air filter elements Check engine oil Check hydraulic oil level. Clean any debris from drum enclosure and ensure drum turns freely.
  • Page 10 Note: It is possible that the noise level produced by the BEF320 could exceed 90dbA. Personal noise protection must be worn. To control dust it is recommended that an SPE dust control unit/vacuum is fitted. Never leave the BEF320 unattended while in use. Always stop the engine and set the height adjustment fully up before leaving the machine.
  • Page 11 BEF320-2A Operating Manual ACCESSORIES Part number Description Application Hardened steel cutter with tungsten inserts, for all concrete texturing, scabbling, planing and grooving applications. Removal of bridge Heavy duty drum complete with deck and car park membranes, 32001 T.C.T. cutters and spacers.
  • Page 12 BEF320-2A Operating Manual ACCESSORIES For the removal of thermoplastic road/runway markings, rubber 20mm based deposits and cold plastic 80600N coatings from asphalt and Milling cutter: Tipped with tungsten concrete. carbide. Heavy duty drum complete with For use with various cutter 32000 flail shafts.
  • Page 13 Spacer Web Site: http://www.spe-int.com E-mail: sales@spe-int.com 80120 Beam Flail THIS DRAWING IS THE CONFIDENTIAL COPYRIGHT PROPERTY OF SPE INTERNATIONAL LIMITED Drawn TITLE Drum c/w Beam Flails This drawing should not be used, D.G.A. copied, shown or handed to a third Drawing No.
  • Page 14 Fax: +44 (0) 1673 861 119 Web Site: http://www.spe-int.com E-mail: sales@spe-int.com 80600N Milling Cutter THIS DRAWING IS THE CONFIDENTIAL COPYRIGHT PROPERTY OF SPE INTERNATIONAL LIMITED Drawn TITLE Drum c/w Milling Cutters This drawing should not be used, D.G.A. copied, shown or handed to a third Drawing No.
  • Page 15 Fax: +44 (0) 1673 861 119 Web Site: http://www.spe-int.com E-mail: sales@spe-int.com 80800 TCT Cutter THIS DRAWING IS THE CONFIDENTIAL COPYRIGHT PROPERTY OF SPE INTERNATIONAL LIMITED Drawn TITLE Drum c/w Tungsten Carbide Tips This drawing should not be used, D.G.A. copied, shown or handed to a third Drawing No.
  • Page 16 BEF320-2A Operating Manual...
  • Page 24 3045 3041 3040 3046 3044 Ram 3008 3037 3044 3038 3038 3042 3038 3038 3038 3037 3037 3039 3037 3037 Pipe No. Description ½" hose + 90º bend & straight connectors 3037 3038 ½" hose + 2 x 90º bend connectors ½"...

  • Page 26: Specification Sheet

    BEF320-2A Operating Manual SPECIFICATION SHEET Specifications Petrol Type BEF320-2A Part Number Power Output (hp) Voltage Cycles 1000 Cutter head speed (rpm) Manual Starter 0-12 Travel speed mtr/min Machine Dimensions (mm) 1230 Length Width 1220 Height Weight (kg) c/w cutter drum...
  • Page 27 BEF320-2A Operating Manual RECORD OF NOISE AND VIBRATION ASSESSMENT Manufacturer: Type: Scarifier Model No. BEF 320-2A Motor: Honda Petrol Operation : Concrete floor surface Inserted Tool: TCT cutters Running Conditions: 2800 rpm HAV Note: Acoustic Associates HAND-ARM VIBRATION Frequency Weighted Energy Equivalent Accelerations (a...

  • Page 28: Warranty

    Conditions of Sale (copy attached). Warranty start date: As despatch date Model: BEF320-2A Serial no: Customer name: Customer Address: Manufacturer: SPE International Ltd Honeyholes Lane Dunholme Lincoln LN2 3SU England Telephone: +44 (0) 1673 860709 Fax: +44 (0) 1673 861119 Email: sales@spe-int.com...

  • Page 29: Declaration Of Conformity

    BEF320-2A Operating Manual DECLARATION OF CONFORMITY SPE INTERNATIONAL LTD Honeyholes Lane Dunholme Lincoln LN2 3SU DECLARE that under our sole responsibility for the supply/manufacture of the product (Description/name) BEF320 Multiplane (Model/type) BEF320-2A to which this declaration relates is in conformity with the following standards and other normative documents following the provisions of Directive 2006/42/EC.
  • Page 30 BEF320-2A Operating Manual CONDITIONS OF SALE The quotation overleaf and any order placed following such quotation are subject to the following conditions of sale in which SPE International Limited is referred to as the “Company”. Validity of quotation No order received from a customer by the Company shall constitute a contract until accepted in writing by the Company.
