- Page 1 SK-1131-SPQ Access Control Keypad with Proximity Card Reader Manual...
-
Page 2: Quick Installation Guide
ENFORCER Access Control Keypad with Proximity Card Reader Quick Installation Guide: This page is for installers looking to do a basic installation and programming of the keypad. For more in-depth installation and programming instructions, see the Table of Contents on page 4. -
Page 3: Quick Programming Guide
ENFORCER Access Control Keypad with Proximity Card Reader Quick Programming Guide: This page is for installers looking to do a basic installation and programming of the keypad. For more in-depth installation and programming instructions, see the Table of Contents on page 4. -
Page 4: Table Of Contents
Programming the Door-Propped-Open Warning and Delay Time ........... 27 Programming the Door Open Alarm and Timing................27 Programming the Egress Delay/Warning/Alarm ................ 28~29 Direct Access to Programming (DAP) ..................... 30 User’s Guide to Operating the SK-1131-SPQ ................. 31 Notes ............................... 32 Also Available ..........................32 SECO-LARM U.S.A., Inc. -
Page 5: Features
ENFORCER Access Control Keypad with Proximity Card Reader Features: • • Built-in proximity card reader Keypad illuminates when a button is pressed; • 12~24 VDC/VAC Operation backlight can be programmed for FULL or • Up to 1,000 possible user codes (000~999) AUTO in standby mode •... -
Page 6: Overview
ENFORCER Access Control Keypad with Proximity Card Reader Overview: Parts List: 1x Keypad 1x Back box 2x Installation screws 2x Mounting screws 1x Diode 4 ⁄ ” 1x Manual (117mm) 1½” 2 ⁄ ” (73mm) (38mm) LED Indicators and Keypad Sounds:... -
Page 7: Installation
ENFORCER Access Control Keypad with Proximity Card Reader Installation: Find a suitable location to mount the keypad. Install it at the height at which most users will be able to easily operate the keypad. Install one mounting screw on the wall. After the screw has been installed, hang the back box by the top mounting hole. -
Page 8: Wiring Diagram
ENFORCER Access Control Keypad with Proximity Card Reader Wiring Diagram: Connection Terminals Backlit Terminal Description FULL AUTO jumper Output #1 N.C. BACKLIT K or A KEY ALARM Output #1. NO/NC/COM, relay output, jumper Output #1 COM K or A max. 1A@30VDC Output #1 N.O. -
Page 9: Sample Applications
ENFORCER Access Control Keypad with Proximity Card Reader Sample Applications: Stand-Alone Door Lock: In this application, the keypad is connected to a single door lock and an egress pushbutton. SK-1131-SPQ (–) OUTPUT 1 DOOR SENS N.C. N.O. 12~24 AC/DC (–) -
Page 10: Getting Ready To Program
ENFORCER Access Control Keypad with Proximity Card Reader Getting Ready to Program: Codes and/or Cards: The SK-1131-SPQ can be set to be activated by users in one of three ways: Keypad code only – There are five types of keypad codes: •... - Page 11 ENFORCER Access Control Keypad with Proximity Card Reader Getting Ready to Program (cont.): Power Up the Keypad: When the keypad is first powered up, it will beep continuously for about 1 minute. During this power-up time, if needed, use Direct Access to Programming (DAP) to reset the master code (see “Direct Access to Programming (DAP)”...
-
Page 12: Programming Format And Default Programming Values
ENFORCER Access Control Keypad with Proximity Card Reader Programming Format and Default Programming Values: In this manual, the format used for programming the keypad is as follows: • A 2-digit ( ) FUNCTION identifier to tell the keypad what is being programmed. -
Page 13: System Restore
ENFORCER Access Control Keypad with Proximity Card Reader System Restore: System restore will reset all programming values except the master code back to the default values shown on page 12. Make sure the keypad is in programming mode (see “Enter and Exit Programming Mode” on page 11). -
Page 14: Programming The Super User Code
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Super User Code: The super user code has two functions: • Unlike user codes, the super user code can operate output #1, output #2, and output #3. • The super user code can also enable or disable output #1. An administrator may want to disable output #1 in the evening or on the weekend to prevent other users from entering a protected premises. -
Page 15: Programming Common User Codes
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Super User Code (cont.): To toggle operation of output #1 ON or OFF: 2580 # 7 NOTE: • This function is used to leave output #1 active for extended periods of time. -
Page 16: Programming User Codes And Proximity Cards
– Output #3, up to 100 possible user codes and proximity cards. Security Levels and Card/Code Deletion: There are four possible security levels for the SK-1131-SPQ: • Card only – The most basic, convenient level of security. Just tap a previously-programmed proximity card over the keypad to activate outputs #1, #2, or #3. -
Page 17: Programming Visitor Codes For Output #1
ENFORCER Access Control Keypad with Proximity Card Reader Programming User Codes and Proximity Cards (cont.): User IDs: • – 1,000 unique user IDs for user codes and prox cards for output #1. • – 100 unique user IDs for user codes and/or prox cards for output #2 or output #3. - Page 18 ENFORCER Access Control Keypad with Proximity Card Reader Programming Visitor Codes for Output #1 (cont.): • If the keypad is powered down, any programmed visitor codes will be deleted. When programming visitor codes, use this general formula: 40 aa bb cccc # –...
-
Page 19: Programming Duress Codes
ENFORCER Access Control Keypad with Proximity Card Reader Programming Duress Codes: Duress codes allow users to trigger a silent alarm or alert if they are forced to allow access to a protected area. If a user uses a duress code instead of his or her normal user code, outputs #1, #2, or #3 will activate as normal, but the duress output will simultaneously activate to trigger a silent alarm or alert. - Page 20 ENFORCER Access Control Keypad with Proximity Card Reader Programming Duress Codes (cont.): Examples: Set the duress ID #1 code for output #1 to 1360: 41 01 1360 # Set the duress ID #1 code for output #2 to 23980: 42 01 23980 #...
-
Page 21: Programming The Output Mode And Output Timing
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Output Mode and Output Timing: The relays for outputs #1, #2, and #3 can be programmed to trigger ON and OFF with a user code or user card (toggle mode), or to trigger for a programmed length of time of up to nearly 28 hours before automatically turning OFF. -
Page 22: Programming The Real-Time Clock
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Real-Time Clock: A 24-hour real-time clock provides the baseline time needed to start and stop the output #1 auto- disable time (see “Programming the Output #1 Auto-Disable Time” below). If the output #1 Auto-Disable Time is not programmed, it is not necessary to set the real-time clock. - Page 23 ENFORCER Access Control Keypad with Proximity Card Reader Programming the Output #1 Auto-Disable Time (cont.): • If the programmed start time is before the end time, output #1 is auto-disabled within a single day. If the programmed start time is after the end time, the end time will be on the following day.
-
Page 24: Programming The Wrong-Code System Lock-Up
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Wrong-Code System Lock-Up: The keypad can be programmed to lock up in order to secure the premises against unauthorized entry if multiple wrong codes are entered or multiple wrong user cards are tapped. -
Page 25: Programming The Keypad Sounds
ENFORCER Access Control Keypad with Proximity Card Reader Programming the User Code Entry Mode (cont.): NOTE: If the keypad was previously programmed for manual code entry mode and then is reprogrammed for auto entry mode, any codes whose length exceeds the number of digits of the master code will no longer operate the keypad. -
Page 26: Programming The Center Led Flashing During Standby Mode
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Center LED Flashing during Standby Mode: The keypad’s center green LED typically flashes while the keypad is in standby mode, but can be programmed off if needed. Enable center green LED flashing during standby mode (default):... -
Page 27: Programming The Door-Propped-Open Warning And Delay Time
ENFORCER Access Control Keypad with Proximity Card Reader Programming the Door-Propped-Open Warning and Delay Time: If the keypad is connected to an optional magnetic contact or other door protection switch or device, the keypad can be programmed to beep when a door has been propped open. This prompts authorized users to close a door that was not closed properly or to investigate a door that may have been deliberately propped open. -
Page 28: Programming The Egress Delay/Warning/Alarm
– Program Egress Delay/Warning/Alarm – Egress Mode – Delay Time Egress Modes: There are six possible egress operation configurations for the SK-1131-SPQ: • Momentary contact with no warning or alarm (default) – Press the egress button momentarily for silent egress operation. - Page 29 ENFORCER Access Control Keypad with Proximity Card Reader Programming the Egress Delay/Warning/Alarm (cont.): NOTE: When the egress button is programmed to hold for a delay time before the door is released, it is important to put a sign near the egress button to notify users of the delay time.
-
Page 30: Direct Access To Programming (Dap)
Direct Access to Programming (DAP): Direct Access to Programming (DAP) is used to reset the master code if it is forgotten. DAP will not change the programming of the SK-1131-SPQ in any other way. To Use DAP: Disconnect the keypad’s power. -
Page 31: User's Guide To Operating The Sk-1131-Spq
ENFORCER Access Control Keypad with Proximity Card Reader User’s Guide to Operating the SK-1131-SPQ: See “Programming the Master Code” and “Programming the Super User Code” on pages 13~15 for functions specific to those authorized to use those codes. Opening the Door:... -
Page 32: Notes
ENFORCER Access Control Keypad with Proximity Card Reader Notes: Also Available: Proximity Cards Proximity Keyfobs (sold in packs of 10) (sold in packs of 10) PR-K1S1-A PR-K1K1-AQ FCC COMPLIANCE STATEMENT FCC ID: K4E1131SPQ THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO...
