Weatherproof Keypad
with Proximity Reader
SK-1322-SPQ
Installation Manual
ENFORCER SK-1322-SPQ Weatherproof Keypad with Proximity Reader is a dual-output access
control keypad that supports up to 1,010 users and can be mounted in a standard single-gang back
box. It includes a tamper alarm and a backlit keypad for ease of use at night or in dark areas.
12~24 VAC/VDC operation
1,010 User codes
2 Form C relays, each rated 1A@30VDC
Each relay output time is programmable from 1~99 seconds or toggle
Output #2 can be programmed for use with a doorbell
2 Egress inputs for exiting the premises without keying in the code
Backlit keys for easy nighttime use
Can be mounted to a single-gang back box
Door sensor input for anti-tailgating operation
All features are programmed directly from the keypad – no need for an external programmer
EEPROM memory protects programmed information in case of power loss
Optical tamper for added security
Circuitry is fully sealed with epoxy for outdoor use
IP65 weatherproof rating, ABS plastic housing
Built-in proximity card reader
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ENFORCER SK-1322-SPQ
Summary of Contents for ENFORCER SK-1322-SPQ
- Page 1 SK-1322-SPQ Installation Manual ENFORCER SK-1322-SPQ Weatherproof Keypad with Proximity Reader is a dual-output access control keypad that supports up to 1,010 users and can be mounted in a standard single-gang back box. It includes a tamper alarm and a backlit keypad for ease of use at night or in dark areas.
-
Page 2: Table Of Contents
Weatherproof Keypad with Proximity Reader Table of Contents Sample Wiring and Applications ....6-7 Features ............2 User Control Chart ........8-9 Specifications ..........2 Accessories ..........2 Programming Instructions ...... 10-13 Dimensions ........... 3 Resetting the Keypad ........14 Manually Resetting the Master Code .. -
Page 3: Led & Audible Indicators
Weatherproof Keypad with Proximity Reader Overview Side Front " (115mm) " (22mm) (75mm) LED & Audible Indicators LED Bar Keypad Status Blue Power ON Green (Yellow Green) Programming mode Dark Green Waiting to program code/card (code+code access mode) Code/card already present Cyan Relay 1 activated Magenta... -
Page 4: Important Notes
Weatherproof Keypad with Proximity Reader Important Notes IF USING THE KEYPAD WITH A MECHANICALLY OPERATED DOOR OR GATE, MOUNT THE KEYPAD AT LEAST 5' (15m) FROM THE DOOR OR GATE TO PREVENT USERS FROM BEING CRUSHED OR PINNED. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. ... -
Page 5: Installation
Weatherproof Keypad with Proximity Reader Installation Mounting screws Mounting base Single-gang box mounting point Keypad Mounting screws Security screw 1. Find a suitable location to mount the keypad. Do not install where it will be too high or too low for most users to operate the keypad. -
Page 6: Sample Wiring And Applications
Weatherproof Keypad with Proximity Reader Sample Wiring and Applications Connection to Lock Device and Alarm System Arm/Disarm Control NOTE: Sample applications are based on VDC power supplies. Red—12~24 VAC/VDC (+) Pink—Output #1 (COM) Black—12~24 VAC/VDC (–) 12~24 VDC Power Supply Green—Common ground (–) Egress Orange—Egress Input 1 (N.O.) - Page 7 Weatherproof Keypad with Proximity Reader Door Sensing N.C. Dry Contact The door sensing input is used for anti- Brown—Door tailgating. When used with an N.C. Sensing magnetic contact the relay will de-energize one second after the door has been closed. Green—Common ground This will bypass any existing relay timing.
-
Page 8: User Control Chart
Weatherproof Keypad with Proximity Reader User Control Chart Output #1: Toggle / Timed (____ sec.) Programmed for __________________________________ User ID Username Access Code User ID Username Access Code SECO-LARM U.S.A., Inc. - Page 9 Weatherproof Keypad with Proximity Reader User Control Chart Output #1: Toggle / Timed (____ sec.) Programmed for __________________________________ User ID Username Access Code User ID Username Access Code Output #2: Toggle / Timed (____ sec.) Programmed for __________________________________ User ID Username Access Code User ID...
-
Page 10: Programming Instructions
Weatherproof Keypad with Proximity Reader Programming Instructions Codes are programmed to be 2~6 digits in length. All codes must be the same length. Before inputting any of the following, enter Programming Mode by entering the Master Code twice. The default Master Code is 1234. To enter Programming Mode, enter To exit Programming Mode, press the key. - Page 11 Weatherproof Keypad with Proximity Reader First Time Keypad Use (Continued) D. Program the Master Card In addition to a Master Code, a Master Card can also be programmed. Swiping a Master Card will give direct access to Programming Mode. 1234 1.
- Page 12 Weatherproof Keypad with Proximity Reader Programming Output #1 (Continued) C. Programming Both User Codes and Cards 1. Enter a user ID number. ( 2. If the LED is red, previous user data exists. Clear it by entering . The keypad will beep in confirmation and the LED will turn green.
- Page 13 Weatherproof Keypad with Proximity Reader Deleting or Changing Users and Cards (Continued) Deleting or Changing an Output #1 User Step 1 Step 2 Step 3 Enter a user ID number: Delete the existing Master Card by Swipe a new Master Card entering: Enter a new user code NOTES...
-
Page 14: Resetting The Keypad
Weatherproof Keypad with Proximity Reader Resetting the Keypad NOTE: Resetting the keypad will cause some or all programmed data to be lost. Do not perform either of these steps unless it is absolutely necessary. Deleting all users Enter IMPORTANT: Once the key entry is made, all user codes and user cards will be deleted, and the keypad will return to Programming Mode. -
Page 15: Using The Keypad
Weatherproof Keypad with Proximity Reader Using the Keypad For programming instructions, see pg. 10, Programming Instructions. Entering a User Code To activate either Output #1 or Output #2, enter the user code directly into the keypad. Do not enter the user ID number. The user ID number is only used during Programming Mode. EXAMPLE: If a user code for Output #1 is 4321, enter to trigger Output #... -
Page 16: Quick Reference Guide
Weatherproof Keypad with Proximity Reader Quick Reference Guide NOTE: For complete programming instructions, please see pg. 10, Programming Instructions. Operation Function Action Enter an Output #1 user code Directly enter on the keypad Enter an Output #2 user code Directly enter on the keypad Ring doorbell Press (if programmed)
