PUREPRO EVERYTHING 'STAT
INSTALLATION AND OPERATING INSTRUCTIONS
1.
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.
COMPATIBILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1. HEAT STAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.2. COOLING/COMPRESSOR STAGES . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.3. ELECTRICAL RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.1. TOOLS REQUIRED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.2. LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.3. REMOVAL OF OLD UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.4. MOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.5. WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.5.1 TERMINAL DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.5.2 FREEZE PROTECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.5.3 SPECIAL WIRING NOTES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.5.4 COMMON WIRING OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.5.7 SINGLE STAGE FURNACE HEATING AND SINGLE STAGE
COOLING SYSTEM LABEL CROSS REFERENCE . . . . . . . . . . . . . . . . . . 4
3.5.8 TWO STAGE HEAT, SINGLE STAGE COOL HEAT PUMP SYSTEM
LABEL CROSS REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.5.9 WIRING DIAGRAMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.6. INSTALL BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.7. INSTALLER SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.7.1 ACCESS AND NAVIGATE INSTALLER SETUP MENU. . . . . . . . . . . . . . . 9
FURNACE SYSTEM TYPE SELECTED: . . . . . . . . . . . . . . . . . . . . . . . . . . 10
PUMP SYSTEM TYPE SELECTED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.7.4 COMPLETING YOUR INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1. OPERATING BASICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.1 UP/DOWN ARROW CHANGE KEYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.2 SET DAY AND TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.3 DEFAULT PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
WARNING: Use Energizer
Mt. Laurel, New Jersey 08054, USA
Energizer
®
is a registered trademark of Eveready Battery Company, Inc.
DURACELL
®
is a registered trademark of The Gillette Company, Inc.
4.1.4 MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.5 DISPLAY ILLUMINATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2. USER SETUP MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2.1 ACCESS AND NAVIGATE USER SETUP MENU. . . . . . . . . . . . . . . . . . . . 12
4.2.2 KEYBOARD LOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2.3 BEEP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2.4 TEMPERATURE DISPLAY FORMAT (F/C DISPLAY) . . . . . . . . . . . . . . . . 13
4.2.5 CLOCK FORMAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.6 CALIBRATION OFFSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.7 MAXIMUM HEAT SETTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.8 MINIMUM COOL SETTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.9 SMART RECOVERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.10 FILTER LIMIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.11 USER SETUP MENU: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3. ADVANCED FEATURES AND OPERATION . . . . . . . . . . . . . . . . . . . . 13
4.3.1 EMERGENCY HEAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3.2 FAN MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3.3 VACATION HOLD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3.4 DAYLIGHT SAVINGS TIME ADJUSTMENT (DST) . . . . . . . . . . . . . . . . . 14
4.3.5 AIR FILTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3.6 ENERGY USAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3.7 FUTURE OUTDOOR SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3.8 FUTURE REMOTE INDOOR SENSORS. . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3.9 RESET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.4. PROGRAMMING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4.1 WEEKDAY TEMPERATURE PROGRAMMING. . . . . . . . . . . . . . . . . . . . . 15
4.4.2 WEEKDAY FAN PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4.3 WEEKEND PROGRAMMING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4.4 COPY PROGRAMMING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.
BATTERIES/MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1. BATTERY INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.
TECHNICAL DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.1. STAGING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.
TECHNICAL ASSISTANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8.
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
®
or DURACELL
®
Alkaline Batteries Only.
www.luxproproducts.com
l
DP722
52119
®
DP722

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PurePro Everything'Stat DP722 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lux Products PurePro Everything'Stat DP722

  • Page 1: Table Of Contents

    DP722 52119 PUREPRO EVERYTHING ’STAT ® DP722 INSTALLATION AND OPERATING INSTRUCTIONS FEATURES ..........2 4.1.4 MODES .
  • Page 2: Features

    LARGE HYBRID DISPLAY WITH ELECTRO-LUMINESCENT DISPLAY BACKLIGHT MODE SET WEEKEND NEXT PROGRAMS DOWN Auto Heat Off Cool SET WEEKDAY SET DAY PROGRAMS AND TIME COPY Auto On ENERGY USAGE FILTER Setup NEXT INDEPENDENTLY PROGRAMMABLE EASY PROGRAMMING MENU DRIVEN WITH SETUP LUX SPEED DIAL ®...
  • Page 3: Removal Of Old Unit

    On replacement installations, mount the new thermostat Route the wires through the open areas in the base ● in place of the old one unless the conditions listed below plate above the terminals. Hold the base against the wall, suggest otherwise. On new installations, follow the with the wires coming through.
  • Page 4: Freeze Protection

    9. W2 This terminal is active when the thermostat common to power the thermostat from the system in any is calling for a second stage of furnace or electric wiring configuration. heat. It will remain inactive unless two stages of WARNINGS: 1.
  • Page 5: Label Cross Reference

    3.5.8 TWO STAGE HEAT, SINGLE STAGE COOL, HEAT PUMP SYSTEM LABEL CROSS REFERENCE Previ o us Thermostat New Thermostat System Termi n al Marki n g Termi n al s Wi r e To Heat Pump 2 Heat, 1 Cool RH, RC, R, V RH &...
  • Page 6 TYPICAL INSTALLER SETUP: TYPICAL 24VAC 4 WIRE HOOKUP [0 1 ] SYSTEM TYPE = FURNACE SINGLE STAGE HEATING AND COOLING [0 2 ] HEAT STAGES =1 [0 3 ] COMPRESSOR STAGES = 1 G O Y2 Y1 RC C RH W1 W2 E B [04] MODES = Ht-Off-Cl-Auto [ 09 ]...
  • Page 7 TYPICAL INSTALLER SETUP: TYPICAL SINGLE-STAGE HEAT PUMP WITH [0 1 ] SYSTEM TYPE = HEAT PUMP (2 STAGES HEAT AND 1 STAGE COOL) [0 2 ] HEAT STAGES =1 OPTIONAL AUX AND EMERGENCY HEAT [0 3 ] COMPRESSOR STAGES = 1 G O Y2 Y1 RC C RH W1 W2 E B [04] MODES = Ht-Off-Cl-...
  • Page 8 TYPICAL INSTALLER SETUP: MULTI-STAGE FURNACE HEAT [0 1 ] SYSTEM TYPE = FURNACE AND COOLING HOOKUP [0 2 ] HEAT STAGES =(MATCH SYSTEM) G O Y2 Y1 RC C RH W1 W2 E B [0 3 ] COMPRESSOR STAGES = (MATCH SYSTEM) [04] MODES = Ht-Off-Cl-Auto [ 09 ]...
  • Page 9: Install Batteries

    3.6. INSTALL BATTERIES 3.7.1.2 HEAT STAGES Install batteries at this time. For instructions, see BAT- Set this to the number of non-compressor driven heat TERY INSTALLATION. stages to use for temperature control by this system. 3.7. INSTALLER SETUP 3.7.1.3 COMPRESSOR STAGES (COOL/HEAT PUMP Configuration items are selected from the Installer Set up STAGES) Menu.
  • Page 10: Installer Setup Menu With

    3.7.1.10 SWING 2 3.7.2 INSTALLER SETUP MENU WITH FURNACE SYS- This value is similar to the Swing 1, but it controls the TEM TYPE SELECTED: temperature variation the system allows above and below Menu Swing 1’s lower limit before calling for a second stage. Item Di s pl a y Sel e cti o ns...
  • Page 11: Completing Your Installation

    Outdoor Sensor 4.1.3 DEFAULT PROGRAM (future) NA/ON/OFF NA/OFF As supplied from the factory, the following program ● Internal Temp Sensor ON / OFF will be used for temperature control. This program and Remote Sensor 1 all other settings maybe restored to their default values (future) NA/ON/OFF NA/OFF...
  • Page 12: Display Illumination

    required. Heating and cooling set temperatures may not button is pressed again, or if no other keys are pressed be adjusted until heating or cooling is necessary, or one for 20 seconds. of these modes is manually selected by pressing and 4.2.2 KEYBOARD LOCK releasing both arrow keys at the same time.
  • Page 13: Temperature Display Format (F/C Display)

    4.2.4 TEMPERATURE DISPLAY FORMAT (F/C DISPLAY) grammed for. A general rule of thumb is to assume that Temperature may be displayed in Fahrenheit or Celsius the fan will run at 1/3 duty cycle. A 90 day filter will then with this option. be good for 90*24/3=720 hours.
  • Page 14: Vacation Hold

    Today’s cumulative heating time ● 4.3.3 VACATION HOLD Today’s cumulative cooling time ● Use this feature to instruct the thermostat to hold a fixed Yesterdays cumulative heating time ● temperature for a period of from 1 to 30 days. Yesterdays cumulative cooling time ●...
  • Page 15: Programming

    Pressing this button will write default values of all ing the settings for that day. temperature programs and setup menus into the unit’s Rotate the dial back to RUN to and accept all current ● nonvolatile memory. Take care not to unintentionally values and end the programming session.
  • Page 16: Copy Programming

    Stage one of a cooling system will be deactivated at the 4.4.4 COPY PROGRAMMING value of swing 1 below the temperature set point. The COPY button allows you to easily copy temperature Stage two of a heating system will be activated at the ●...
