- Page 1 Operating and Servicing Instructions RS-Q STATIONARY Serial Number : 120090 Purchase Date: Must be read before first use! Retain for future reference!
-
Page 2: Table Of Contents
Electrical Hazard ..........................16 Servicing and Care ..........................17 REPLACEMENT PARTS ......................17 PERIODIC INSPECTION ......................18 SCOPE OF DELIVERY / ACCESSORIES ................19 Operating Instructions RS-Q STATIONARY - 2 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 3: Introduction
Introduction About this Product In the Rosensteiner “RS-Q STATIONARY” hoof care crush, you have purchased a tool with forward-looking technology for the care of animal hooves. The hoof care crush is for periodic, correct and efficient hoof care, in a position that is ergonomic, functional and non-tiring for the carer. -
Page 4: Intended Use
Operating and Servicing Instructions Intended Use The RS-Q STATIONARY hoof care crush is intended exclusively for the care of animal hooves. The hoof care crush is suitable for cattle from 300 kg to maximum of 1,100 kg. Any action that differs from the “intended use” is considered misuse and is thus prohibited. -
Page 5: Eu- Declaration Of Conformity
Rosensteiner. Expenses will not be accepted by the manufacturer unless expressly agreed. Faulty parts must be kept by the dealer or sent to Rosensteiner, as agreed: the device must be bought to the dealer carriage paid. -
Page 6: Technical Data
Operating and Servicing Instructions Technical Data Machine type Hoof care crush RS-Q STATIONARY 2,100 / 2,200 / 2,150 mm (L/W/H – folded together) Dimensions 3,550 / 3,150 / 2,170 mm (L/W/H – opened) 300 – 1,100 kg Recommended animal size... -
Page 7: Changes To These Operating Instructions
Work that is specialised and requires specialist ability on the part of the person carrying it out, (welding, electrical work, ...) 1.8.7 Work Space Operation Recommended space requirement for the RS-Q STATIONARY: Tracteur / Mur Operating Instructions RS-Q STATIONARY - 7 of 19 -... -
Page 8: Explanation Of The Information And Hazard Notices
Read and follow the operating instructions and safety notices before commissioning! Switch off motor and disconnect power before repair, servicing and cleaning work. Maintain a safe distance from high-voltage electric components. Operating Instructions RS-Q STATIONARY - 8 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 9: Transport Position
To move the hoof care crush with the tractor, the balls of the lower link are first fitted to the lower link bolts of the RS-Q STATIONARY. Then move the tractor backwards to the appliance taking care that nobody is in the hazard area, especially between the tractor and the hoof care crush, raise the lower link until the balls on the lower limb engage. -
Page 10: Driving Hoof Care Crush With A Tractor
Then release first the upper link, then the lower link. Operating Instructions RS-Q STATIONARY - 10 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 11: Commissioning /Operation
Control for foot holder L & R Control for foot stretcher 1-4 Foot stretcher 1-4 Angle grinder holder Knife holder Socket 230V Operating Instructions RS-Q STATIONARY - 11 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 12: Safety Instructions Before Commissioning The Machine
Check the working area and ensure that no other unauthorised persons are in the working area – particularly children. Use personal protective equipment Operating Instructions RS-Q STATIONARY - 12 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 13: Hazard Area / Work Area
The ground must be suitable for fixing and be able to support an axial load of at least 20kN. With appropriate permanent fixing to the ground, the RS-Q Stationary is a stationary appliance. - Page 14 1) Set down the RS-Q Stationary as described above and secure against tipping. 2) Take electrical cable from the sub-frame (1) and connect RS-Q Stationary to the mains. 3) Switch on motor switch (6) and tip the tipping wall vertically using the tipping wall control (7).
-
Page 15: Emergency Program Connection For External Hydraulics
Pressure Return In operation with emergency program, the appliance must be disconnected from the mains! Lever Position Normal Operation Tractor Operation Operating Instructions RS-Q STATIONARY - 15 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 16: Cleaning
Check loosened bolt connections for tightness before commissioning Loosening bolt connections: when opening bolt connections, first loosen them slowly to allow pressure in the lines to equalise. Operating Instructions RS-Q STATIONARY - 16 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 17: Servicing And Care
Operating Instructions RS-Q STATIONARY - 17 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 18: Periodic Inspection
Periodic Inspection NOTICE The electrical installations of the machine must be inspected annually by an electrical specialist. Operating Instructions RS-Q STATIONARY - 18 of 19 - Valid as of: 07/2020 – technical changes may be undertaken... -
Page 19: Scope Of Delivery / Accessories
Hydraulic drive 400V / 4.0kW Emergency program connection for external hydraulics (e.g. of tractor) Whole construction galvanized and powder-coated Operating Instructions RS-Q STATIONARY - 19 of 19 - Valid as of: 07/2020 – technical changes may be undertaken...
