- Page 1 Operation and maintenance manual Red 5 hoof trimming chute Serial number: Equipment number: Date of installation: Date of purchase: Read this manual before commissioning. Retain this manual for future reference. Rev. 06/2020...
-
Page 2: Table Of Contents
Operation and maintenance manual Contents INTRODUCTION....................3 Product information ........................3 Intended use ..........................4 Examples of improper use ......................4 EC Declaration of Conformity ....................5 Warranty Statement ........................5 Specifications ..........................6 Type plate ........................... 6 Operating manual structure and scope .................. 6 1.8.1 Document structure ......................... -
Page 3: Introduction
1 Introduction 1.1 Product information Your new Rosensteiner RED 5 hoof trimming chute is a quality product featuring innovative technology for animal hoof care. This hoof trimming chute is intended to be used for periodic, qualified, efficient hoof care while enabling the user to assume ergonomic, appropriate, non- fatigue posture. -
Page 4: Intended Use
Operation and maintenance manual 1.2 Intended use The RED 5 hoof trimming chute is solely intended for hoof care work performed on animal hoofs. This hoof trimming chute is suitable for cattle weight from 450 kg up to a maximum of 950 kg. -
Page 5: Ec Declaration Of Conformity
Rosensteiner. The manufacturer will not incur any expenditure without their express consent. Any defective parts shall be stored at the dealership or sent to Rosensteiner as agreed: The customer’s transfer of the product to the dealership shall be free of any transportation charges. -
Page 6: Specifications
Provided that we replace the device or product in question under this warranty, any warranty claims against the selling dealership shall be excluded. 1.6 Specifications Machine type RED 5 hoof trimming chute Dimensions 2510/1220/2340 mm (L/W/H) Recommended animal weight 450-950kg... -
Page 7: How To Store This Operating Manual
If you decide to re-sell your hoof trimming chute, please remember to pass this operating manual on to its new owner. The manual is a legally required component of the machine. This operating manual is ready for download at www.rosensteiner.at. 1.8.5 Space limitations This product has been designed for portable use in varying locations. -
Page 8: Informational And Safety Symbols
Operation and maintenance manual 1.8.8 Informational and safety symbols Any additional information provided in this manual is identified by the above information symbol. SIGNAL WORD Identifies the type and source of the hazard and any associated risks. Potential consequence for people, machine parts, tools and work pieces (residual risk). Action taken to avoid the danger to life and to reduce any residual risks. - Page 9 Operation and maintenance manual Before disconnecting or parking the machine use chocks to prevent it from rolling off. Avoid bumpy terrain or slopes which may cause the device to slip, tip over or overturn. Stop the engine and remove the key before performing any maintenance or repair work. Caution: High-pressure fluids may escape.
-
Page 10: Transport
Operation and maintenance manual 2 Transport 2.1 Attaching the hoof trimming chute to a tractor WARNING If a tractor is used to transport the hoof trimming chute, the chute will be attached to the tractor’s lower links and, using the 3-point chain, to the top link. Reverse the tractor up to the machine, ensuring that nobody is in the hazard area between the tractor and the hoof trimming chute. -
Page 11: Disconnecting And Parking The Hoof Trimming Chute
Operation and maintenance manual During the day, two warning panels should be attached to the left and right rear of the hoof trimming chute without obstructing the tractor’s rear lights. In the dark, a fully- equipped light rail (LH and RH lights corresponding to the tractor lighting) should be attached to the rear of the hoof trimming chute. -
Page 12: Commissioning And Operation
Operation and maintenance manual 3 Commissioning and operation 3.1 Component overview and main controls Ref. Description Ref. Description Pressure roller safety crank Hind leg retention bracket Head catch control Leg strap Attachment tube Hind leg lift winch Ankle strap Knee rope Rope clamp Leg strap sling Front leg winch... -
Page 13: Safety Precautions Before Commissioning
Operation and maintenance manual 3.2 Safety precautions before commissioning NOTE When initially commissioning the product, ask for the assistance of a person experienced in using the product and trimming hoofs. Never trim hoofs immediately after feeding the cattle. WARNING ... -
Page 14: Commissioning The Hoof Trimming Chute
Operation and maintenance manual 3.3 Commissioning the hoof trimming chute Refer to the component overview for call-outs: 1. Place the hoof trimming chute on an even, non-slip surface located in an easily accessible area. For livestock kept in free-stall barns we recommend using a cattle alley. 2. - Page 15 Operation and maintenance manual Ensure the metal D-ring is in the proper position, enabling the strap to be run smoothly. Otherwise the D-ring may become twisted. 11) To attach a front leg: Caution: Never perform any work on the animal’s front leg unless the hind leg on the same side is properly secured.
-
Page 16: Transport
Operation and maintenance manual 3.4 Transport Transport using the dolly wheels The dolly wheels should only be used to achieve the product’s final position before commencing hoof care. They are not intended for general transport purposes. 1 set of dolly wheels comprises: 2 push-on wheels 1 lifting/steering rod ... -
Page 17: Allowing Natural Movements
Operation and maintenance manual 3.5 Allow natural movements Make sure the animal does not suffer pain or injuries caused by unnatural movements, particularly when raising and moving its legs. To make this easier for you, this operating manual shows an overview of the animal’s skeletal system. -
Page 18: Cleaning The Product
Operation and maintenance manual 4 Cleaning the product NOTE Follow all safety guidelines contained in the safety data sheet supplied with the cleaning agents and disinfectants used. Dispose of the waste water in accordance with the relevant national regulations. ... -
Page 19: Maintenance, Servicing And Repair
Operation and maintenance manual 5 Maintenance, servicing and repair CAUTION Service work must only be performed by trained, qualified personnel or by the manufacturer. Maintenance and service work must only be performed if the lighting in the work area is sufficient for the work to be performed. -
Page 20: Spare Part Information
Operation and maintenance manual 6 Spare part information NOTE If a machine component needs to be replaced, make sure to use genuine parts only. Third-party replacement or wear parts used for genuine components and accessories have not been checked or approved by the manufacturer. ... -
Page 21: Frequent Checks
Operating manual (also provided on-line) Quick-release leg holder - retractable for gentle & safe operation Type Description 95 000 RED 5 Standard equipment Accessory 90 171 Dolly wheels + lifting rod and 2x push-on wheels 90 176 Additional wheels for trailer transport + rod and lifting rod Cattle alley assembly “Comfort”...
