MagSled
User Guide
SPP mode
1/18
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Advertisement
Table of Contents
Related Manuals for AXEM Technology MagSled
Summary of Contents for AXEM Technology MagSled
- Page 1 File : MagSled User Guide Version : V1.0 MagSled User Guide SPP mode 1/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
-
Page 2: Table Of Contents
Installation instruction ......................6 Appearance ........................6 Battery charge ........................7 Buttons and function area display ..................7 Adhesive metal plate for the MagSled ................8 Demo Test ..........................9 Install demo-uhf-bt (1.0.8) ....................9 Pairing device ........................9 UHF Scan function ......................11 UHF configuration ...................... -
Page 3: Révision
File : MagSled User Guide Version : V1.0 1 Révision Description Date Version Auteur Check First release 2020/11/20 CLO, FDA 3/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 4: Product Introduction
The Magsled makes any mobile terminal in a smartphone shape a professional data collection device. It adapts to any smartphone running under Android or iOS. Connect your device and the MagSled very easily in a Bluetooth connection. The MagSled has several features such as powerful UHF RFID reading/writing and 1D/2D barcodes scanning. -
Page 5: Charger
File : MagSled User Guide Version : V1.0 Charger The charger type is GME10D-050200FGu, output voltage/current is 5V DC/2A. The plug considered as disconnect device of adapter. Notes Note 1: Using the incorrect type battery has danger of explosion. Please dispose the used battery according to instructions. -
Page 6: Installation Instruction
File : MagSled User Guide Version : V1.0 3 Installation instruction Appearance Indicating lamp instructions 6/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €... -
Page 7: Battery Charge
By using USB contact, the original adaptor should be used for charging the device. Make sure not to use other adaptors to charge the device. Buttons and function area display MagSled has 1 power button and 3 indicating lamps. Indicating lamp Power... -
Page 8: Adhesive Metal Plate For The Magsled
Adhesive metal plate for the MagSled A 40x50mm metal plate with a strong adhesive is delivered with the Magsled. The metal plate needs to be placed on the rear of the PDA/Tablet and interacts with the magnet installed on the upper side of the Magsled. -
Page 9: Demo Test
File : MagSled User Guide Version : V1.0 4 Demo Test Install demo-uhf-bt (1.0.8) 1. Copy demo-uhf-bt (1.0.8.) into internal storage of smartphone. 2. Click to install. 3. Click to open demo. Pairing device 1. Switch on Bluetooth function of your smartphone or MBA5-P1x device. - Page 10 File : MagSled User Guide Version : V1.0 Your device is connected. 10/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
-
Page 11: Uhf Scan Function
Version : V1.0 UHF Scan function 1. Click SINGLE or AUTO in demo or pull the trigger on MagSled, the UHF tags could be read. 2. Click STOP in demo to stop reading of UHF tags. 3. Click CLEAR to clean all EPC information. -
Page 12: Uhf Configuration
File : MagSled User Guide Version : V1.0 UHF configuration Click CONFIG in demo to adjust working mode and output power. 12/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... - Page 13 File : MagSled User Guide Version : V1.0 13/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
-
Page 14: Uhf Tag Reading And Writing
File : MagSled User Guide Version : V1.0 UHF Tag Reading and Writing The storage of one tag has 4 zones: RESERVED, EPC, TID and USER. Normally, the default password is 00000000. And TID zone can only be read, other zones can be read and written. -
Page 15: Uhf Tag Lock And Kill
File : MagSled User Guide Version : V1.0 UHF Tag Lock and Kill 4.6.1 Lock Function For example. User could try to lock down EPC zone. 15/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 16: Kill Function
File : MagSled User Guide Version : V1.0 4.6.2 Kill Function Kill function can be used to kill the tag permanently. Input the correct access password and click kill. 16/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 17: Firmware Upgrade
File : MagSled User Guide Version : V1.0 Firmware Upgrade 1. Click CHOOSE FILE. 2. Click SELECT the file in the internal storage. 3. Click UPGRADE to upgrade firmware. 17/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 18: Barcode Scan Test
File : MagSled User Guide Version : V1.0 Barcode Scan Test Select BARCODE SCAN in the demo and click SCAN button on the screen to scan barcodes. Click CLEAR to clean all information 18/18 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com...
