Summary of Contents for Advantech FPM-3220
- Page 1 FPM-3220 Industrial Control Panel with 12.1" LCD and Data-Function Keypad Users Manual...
- Page 2 Copyright This document is copyrighted February, 2002, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time. Spec- ifications are thus subject to change without notice.
- Page 3 FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a commercial environment.
-
Page 4: Packing List
Packing List Before you set up the FPM-3220, make sure that the following items have been included in your package, and that this manual is in good condition. If anything is missing or damaged, contact your dealer immediately: • FPM-3220 control panel •... -
Page 5: Safety Instructions
Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. -
Page 6: Wichtige Sicherheishinweise
- Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. FPM-3220 Users Manual... -
Page 7: Table Of Contents
Complete Functionality ... 4 Figure 1.1: Front panel layout ... 4 Figure 1.2: Rear chassis layout ... 4 Dimensions... 5 Figure 1.3: FPM-3220 Dimensions... 5 Chapter 2 System Setup...7 Connecting the Controller ... 8 Figure 2.1: Connecting the Controller... 8 Install the Power Adaptor... - Page 8 OSD function and operation... 28 Figure A.1: OSD menu ... 28 Table A.3: OSD Functionality... 28 Appendix B Touchscreen (optional) ...29 Specifications ... 30 Installation of Touchscreen Driver... 31 viii...
-
Page 9: Chapter 1 Introduction
Introduction • Introduction • Specifications • Complete Functionality • Dimensions Chapter 1 Introduction... -
Page 10: Chapter 1 Introduction
FPM-3220 a powerful panel programming benefit like stan- dard workstation, but none of deep space problem. Equipped with direct VGA interface, FPM-3220 can connect to any PC Box in long distance range without wiring and cabling limit faced by tradition bulky worksta- tion. - Page 11 • Operating temperature: 0° ~ 50° C (32° ~ 122° F) • Relative humidity: 5 ~ 85% @ 40° C, non-condensing • Storage temperature: -20° ~ 60° C • Storage humidity: 5 ~ 95% non-condensing • Dimensions (W x H x D): 482 x 266 x 63 mm (19.0" x 10.5" x 2.5") •...
-
Page 12: Figure 1.2: Rear Chassis Layout
1.3 Complete Functionality FPM-3220 features rich and complete functions especially designed for industrial control applications. OSD Keypad FPM-3220 User’s Manual 12.1” TFT LCD Display with VGA Interface & optional Touchscreen Figure 1.1: Front panel layout Rear PS/2 KB/Mouse Connector To PC KB/Mouse Connector... -
Page 13: Figure 1.3: Fpm-3220 Dimensions
1.4 Dimensions Figure 1.3: FPM-3220 Dimensions Chapter 1 Introduction... - Page 14 FPM-3220 User’s Manual...
- Page 15 System Setup • Connecting to Controller • Install the Power Adapter • Connecting External Keyboard and Mouse • Panel Mounting • Rack Mounting • Wall Mounting • Desktop Stand • Swing Arm Mounting Chapter 2 System Setup...
-
Page 16: Figure 2.1: Connecting The Controller
Chapter 2 System Setup 2.1 Connecting the Controller The FPM-3220 is designed to be the operation panel for your system. It’s equipped with PC standard interfaces that are easily found on PC-based controller. There are three connections between the FPM-3220 and the controller: VGA, Keyboard, and optional RS-232 of touch screen. -
Page 17: Figure 2.2: Mounting The Power Adaptor
2.2 Install the Power Adaptor The power adapter could be mounted on the back cover with a power adapter-mounting bracket in the accessory box as following figure shown. In order to secure the power connector, there is a connector fixing plate in the accessory box also, and it could be installed as shown in the following figure. -
Page 18: Figure 2.3: Connecting Front External Keyboard/Mouse
2.3 Connecting External Keyboard and Mouse You can connect an external keyboard and mouse to FPM-3220. The first place to the connect keyboard and mouse is the PS/2 connector on the front panel, under the dust-protection door. You can connect a PS/2 key- board to the connector if you do not need a mouse. -
Page 19: Figure 2.5: Panel Mounting
2.4 Panel Mounting A cutout need be made to accommodate panel mounting. Four panel- mount brackets are included in the accessory box. Slide the unit backward into the panel opening. Attach the four mounting brackets by inserting the screws into the keyhole slots on the flat panel monitor cover. Use the screws to secure the brackets to the cover. -
Page 20: Figure 2.6: Rack Mounting
2.5 Rack Mounting The FPM-3220 can be directly mounted in a standard 19" rack. Just mount the panel on the rack and secure with four screws. FPM-3220 User’s Manual Figure 2.6: Rack Mounting... -
Page 21: Figure 2.7: Wall Mounting
2.6 Wall Mounting First mount the wall/desktop-mounting bracket to the wall, then mount the FPM-3220 on the bracket through the three screws, finally secure the panel to the mounting plate with the locking plate. Figure 2.7: Wall Mounting Chapter 2 System Setup... -
Page 22: Figure 2.8: Desktop Stand
2.7 Desktop Stand Mount the wall/desktop-mounting bracket to the back of FPM-3220 with two screws as following drawing shown. FPM-3220 User’s Manual Figure 2.8: Desktop Stand... -
Page 23: Figure 2.9: Swing Arm Mounting
2.8 Swing Arm Mounting There are two sets of Swing-ARM mounting holes, 75 mm and 100 mm format, on the back chassis. You could Mount FPM-3220 on the Swing- ARM through the mounting holes and secure with four screws. Figure 2.9: Swing Arm Mounting... - Page 24 FPM-3220 User’s Manual...
- Page 25 Macro Key Program- ming • Introduction • Macro key overview • Syntax • Using SFED3220.COM • Examples Chapter 3 Macro Key Programming...
-
Page 26: Chapter 3 Macro Key Programming
DOS, but there are some differences. In a Macro, you have to specify the ENTER key explicitly. Also, macros give you the option of entering key sequences in an application that was executed by the macro itself. FPM-3220 User’s Manual... -
Page 27: Syntax
3.3 Syntax Macro definitions consist of ASCII characters or character codes for spe- cial characters (ALT, ENTER, SHIFT, F1, SF2, and so on). These codes are predefined, and SFED3220.COM will display them on the screen for you. They are easily recognizable, appearing between the square brackets, "["... - Page 28 SFED3220.COM displays the codes that you can use for various delays. For example: [86] - wait for 10 seconds before executing next keystroke [88] - wait for 1 minute before executing next keystroke [26]A[90][86][26]B[90] means ALT-A, wait 10 seconds, ALT-B FPM-3220 User’s Manual...
-
Page 29: Figure 3.1: The Macro Editor Screen
Here we will create a new file by typing SFED3220 NEWKEY.TXT [ENTER]. The following screen will appear: Advantech Workstation Special Function Key Edit Program Table of Control Codes : [24] HOME [3C]... -
Page 30: Figure 3.2: Macro Examples
PLE.TXT We will explain all macro functions that you can find in the EXAMPLE.TXT macro script file. When typing SFED3220 EXAM- PLE.TXT the following editor screen will appear: Advantech Workstation Special Function Key Edit Program Table of Control Codes : [24]... - Page 31 SF1 = CD\TOOL[33] SFED825 EXAMPLE.TXT[33] This macro changes to the TOOL directory, then starts up SFED3220.COM with EXAMPLE.TXT. SF2 = COPY C:\CONFIG.EMM C:\CONFlG.SYS [33] Y [33] [85] [79] The configuration information is changed by copying CONFIG.EMM to CONFIG.SYS. After a delay of 5 seconds, [85], the macro invokes macro function key SF10, [79], which was defined to reset the system.
- Page 32 FPM-3220 User’s Manual...
-
Page 33: Appendix A Display Timing Mode & Osd
Display Timing Mode & • Supported input timing modes • OSD operation keypad • OSD function and operation Appx. A... -
Page 34: Table A.1: Supported Input Formats
Note 3: Because adjustments may not fit, such as differing magnifying ratios or, in the case that you use it except for the display timing that was preset. FPM-3220 User’s Manual 70 Hz 72 Hz 75 Hz... -
Page 35: Table A.2: Keypad Functions
A.2 OSD Operation Keypad The OSD keypad, including six keys and a two color indicator, is designed as the OSD operation interface. The six keypad functions are in Table A-2. Auto Press this button to execute auto adjustment process Press to show the OSD screen or select an item to change its setting To move between items or increase or decrease setting Exit... -
Page 36: A.3 Osd Function And Operation
H. Size Clock Phase Position H. Position V. Position Information All Reset FPM-3220 User’s Manual button to scroll to the desired menu option. button to adjust the setting. Figure A.1: OSD menu Sub Menu Adjust display brightness Reset Contrast Adjust RGB contrast simultaneously... -
Page 37: Touchscreen (Optional)
Touchscreen (optional) • Installation of touchscreen driver Appx. B... -
Page 38: B.1 Specifications
Storage Temperature High: Storage Temperature Low: Accelerated Aging: Thermal Shock: Mechanical Activation Method: Activation Force: FPM-3220 User’s Manual 3.3 to 5 V typical 350 ± 22% W/square +/- 1.5% full scale linearity error in either direction. > 20 ΜΩ @ 25 V -20°C to +50°C, 2 weeks at 50°C/90%... -
Page 39: B.2 Installation Of Touchscreen Driver
Character Activation Life: B.2 Installation of Touchscreen Driver The touchscreen for the FPM-3220 Series provides drivers for use with MS-DOS, Windows 3.1, 95, 98, NT, and 2000. For the detailed touch- screen driver installation procedure, please refer to the "TSCB-9516 Driver Installation Guide"... - Page 40 FPM-3220 User’s Manual...
