- Page 1 INSTALLATION INSTRUCTIONS WALL MOUNTED PACKAGE AIR CONDITIONERS MODELS WL423 WL484 WL605 Bard Manufacturing Company, Inc. Manual : 2100-504 Supersedes: Bryan, Ohio 43506 File: Volume III Tab 16 Since 1914...Moving ahead just as planned. Date: 01-31-08 Manual 2100-504 Page 1 of 20...
-
Page 2: Table Of Contents
CONTENTS Start Up Getting Other Information and Publications Important Installer Note ......... 16 High Pressure Switch ..........16 Wall Mount General Information Three Phase Scroll Compressor Start Up ....16 Wall Mount Model Nomenclature ......4 Phase Monitor ............16 Shipping Damage ............ -
Page 3: Getting Other Information And Publications
Getting Other Information and Publications These publications can help you install the air For more information, contact these conditioner or heat pump. You can usually find these at publishers: your local library or purchase them directly from the publisher. Be sure to consult current edition of each ACCA Air Conditioning Contractors of America standard. -
Page 4: Wall Mount General Information
WALL MOUNT GENERAL INFORMATION HEAT PUMP WALL MOUNT MODEL NOMENCLATURE – CONTROL MODULES REVISIONS MODEL NUMBER (See Chart Below) COIL OPTIONS VOLTS & PHASE X - Standard CAPACITY A - 230/208/60/1 1 - Phenolic Coated Evaporator 42 - 3½ Ton B - 230/208/60/3 COLOR OPTIONS 2 - Phenolic Coated Condenser... -
Page 5: Figure 1 Unit Dimensions
Manual 2100-504 Page 5 of 20... -
Page 6: Table 2 Electrical Specifications
TABLE 2 ELECTRICAL SPECIFICATIONS & Maximum size of the time delay fuse or HACR type circuit breaker for protection of field wiring conductors. Based on 75°C copper wire. All wiring must conform to NEC and all local codes. These “Minimum Circuit Ampacity” values are to be used for sizing the field power conductors. Refer to the National Electric Code (latest revision), Article 310 for power conductor sizing. -
Page 7: Shipping Damage
Any grille that meets with 5/8 inch louver criteria may is made. See Page 3 for information on codes and be used. It is recommended that Bard Return Air Grille standards. Kit RG2 through RG5 or RFG2 through RFG5 be Size of unit for a proposed installation should be based installed when no return duct is used. -
Page 8: Filters
FILTERS All capacity, efficiency and cost of operation information as required for Department of Energy A 1-inch throwaway filter is supplied with each unit. “Energyguide” Fact Sheets is based upon the fresh air The filter slides into position making it easy to service. blank-off plate in place and is recommended for This filter can be serviced from the outside by removing maximum energy efficiency. -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS WALL MOUNTING INFORMATION WARNING 1. Two holes for the supply and return air openings must be cut through the wall as shown in Figure 3. 2. On wood frame walls, the wall construction must be Failure to provide the 1/4 inch clearance strong and rigid enough to carry the weight of the between the supply duct and a combustible unit without transmitting any unit vibration. -
Page 10: Figure 3 Mounting Instructions
Manual 2100-504 Page 10 of 20... -
Page 11: Figure 4 Electric Heat Clearance
FIGURE 4 ELECTRIC HEAT CLEARANCE SIDE SECTION VIEW OF SUPPLY AIR DUCT FOR WALL MOUNTED UNIT SHOWING 1/4 INCH CLEARANCE TO COMBUSTIBLE SURFACES. WARNING minimum of 1/4 inch clearance must be maintained between the supply air duct and combustible materials. This is required for the first 3 feet of ducting. -
Page 12: Figure 5 Wall Mounting Instructions
FIGURE 5 WALL MOUNTING INSTRUCTIONS SEE FIGURE 3 – MOUNTING INSTRUCTIONS FIGURE 6 WALL MOUNTING INSTRUCTIONS SEE UNIT DIMENSIONS, FIGURE 1, FOR ACTUAL DIMENSIONS Manual 2100-504 Page 12 of 20... -
Page 13: Figure 7 Common Wall Mounting Installations
FIGURE 7 COMMON WALL MOUNTING INSTALLATIONS Manual 2100-504 Page 13 of 20... -
Page 14: Wiring - Main Power
WIRING – MAIN POWER WIRING – LOW VOLTAGE WIRING Refer to the unit rating plate for wire sizing information 230/208V, 1 phase and 3 phase equipment dual primary and maximum fuse or “HACR” type circuit breaker voltage transformers. All equipment leaves the factory size. -
Page 15: Figure 8 Unit 24V Terminal Board
FIGURE 8 UNIT 24V TERMINAL BOARD Manual 2100-504 Page 15 of 20... -
Page 16: Start Up
The phase monitor in this unit is equipped with two LEDs. If the Y signal is present at the phase monitor The WL484 and WL605 models are supplied with a and phases are correct, the green LED will light. remote reset high pressure switch. If tripped, this... -
Page 17: Compressor Control Module
The compressor control module is standard on the pressure switch and low pressure switch cut out WL484 and WL605 models covered by this manual and and cut in settings are fixed by specific air is optional on the WL423 model. The compressor conditioner or heat pump unit model. -
Page 18: Figure 9 Fan Blade Setting
TROUBLESHOOTING FAN BLADE SETTING DIMENSIONS 3. Remove screws holding fan shroud to condenser and bottom. Nine (9) screws. Shown in Figure 9 is the correct fan blade setting dimension for proper air delivery across the outdoor 4. Unwire condenser fan motor. coil. -
Page 19: Pressure Table
TABLE 8 TABLE 9 RECOMMENDED AIRFLOW MAXIMUM ESP OF OPERATION ELECTRIC HEAT ONLY f r i * Rated CFM and ESP on high speed tap. Values shown are for units equipped with standard 1 inch throwaway filter or 1 inch washable filter. Derate ESP by .15 for 2 inch pleated filters. -
Page 20: Optional Accessories
TABLE 11 OPTIONAL ACCESSORIES l a i i t n t a l & t i u l l u t i u t i u t i u Manual 2100-504 Page 20 of 20...
