Page 1: User Manual
User Manual EMBEDDED VIACCESS DIGITAL SATELLITE RECEIVER... -
Page 2: Table Of Contents
CONTENTS Safety instructions ------------------------------------------------------------------- 2 Features ------------------------------------------------------------------------------- 3 Front & Rear view ------------------------------------------------------------------- 4 4. Remote Control Unit (RCU) ------------------------------------------------------- 5 5. Getting started ------------------------------------------------------------------------ 6 6. Operation and menu program ------------------------------------------------------ 8 A. Receiver and TV set-up ------------ --------------------------------------------- 8 B. -
Page 3: Safety Instructions
1. Safety Instructions WARNING! Always follow these instructions to avoid the risk of injury to yourself or damage to your equipment. Unplug the receiver from the AC power outlet before cleaning. Use only a damp cloth for cleaning the exterior of the receiver. Do not use accessories or attachments not recommended by the receiver manufacturer, as they may cause hazards and will void the warranty. -
Page 4: Features
6. Capable of scanning the frequency for SMATV system 7. Plug & Play installing program set-up 8. Proprietary EchoStar OSG menu for full integrated functions 9. On-screen display with 256-color full resolution 10. Variety of LNB polarity control; 13/18V, 0/22KHz tone, 0/12V and DiSEqC LNB 11. -
Page 5: Front & Rear View
3. Front & Rear View Front Panel Front Panel Channel up/down On/Standby Smart card slot Selection/confirmation Volume up/down Rear Panel Rear Panel AC power cord LNB input Antenna input VIDEO (400mA Max) ANT IN AUDIO TV OUT AC power switch RF output connector to TV Note: All the cables used for Input/Output connection for the receiver should be well shielded. -
Page 6: Remote Control Unit (Rcu)
4. Remote Control Unit (RCU) The Power key turns the receiver on and off. The Mute key switches the sound on and off. Number / Input keys enable direct channel selection command using numeric keys. The TV/RAD(Radio) key switches between TV and radio mode. The MENU key is used to see main menu or to return to previous menu. -
Page 7: Getting Started
2. Connect the TV OUT socket of the EchoStar DSB-1100 Viaccess to the RF IN of the TV set. 3. Search on the TV set for UHF channel # 38. This is the default channel where the EchoStar DSB-1100 Viaccess is set to. - Page 8 3. Connect the RF OUT of the VCR to the RF IN of the TV set. 4. Search on the VCR for UHF channel # 38. This is the default channel where the EchoStar DSB-1100 Viaccess is programmed to. 5. Connect the SCART cable from the TV SCART of the EchoStar DSB-1100 Viaccess to the SCART of the TV set.
-
Page 9: Operation And Menu Program
Installation Check the To get the most out of the EchoStar DSB-1100 Viaccess it should be correctly installed, the dish should be optimally aligned and the mechanical limit switched on the dish should be set properly. Press remote control unit (RCU) or press The receiver is supplied with factory setting and will start up with the “Language Setting”... -
Page 10: Language Setting
User’s Setting Language Setting Local Time Setting A/V Output Setting About Echostar You can select a different language for the OSG (On-Screen Graphics) display using the , keys when the “Menu Language” option is selected. Similarly you can select a different audio channel when the “Audio Language”... -
Page 11: Local Time Setting
UHF frequency is set automatically according to the channel selection. About EchoStar You can see the details of the company information. If you have any questions about the EchoStar DSB-1100 Viaccess, firstly contact your local d ealer. Local Time Setting... -
Page 12: Main Menu & Installation
B. Main menu and Installation Main Menu Press the MENU key to display the “Main Menu” o n the screen. Select a sub-menu using the , keys or the numeric k eys. Please note that the OK key is always a confirma tion of your selection. -
Page 13: Auto Search
Auto Search Using the Auto Search option, the EchoStar DSB-110 0 Viaccess searches for all available channels (Radio and TV) on the currently selected satellite. The names of the found TV channels are shown on the left and th e total number of found TV and Radio channels are m entioned on the right. -
Page 14: Radio Channels
TV Channels You can select the channel you would like to watch either b y pressing the numeric keys for the channel number or by m oving the highlighted bar to the channel of your choice usin g the , keys. Press the OK key to select the channel. * Press the , keys to move one page up or down. -
Page 15: Receiver Lock
TV Channel Lock Press the OK key to lock / unlock the selected chan nel. The letter color of the locked channels will be chang ed into Grey color on the “TV Channels” menu. VIEW Press the key to see a thumb nail of the current channel in this menu. -
Page 16: Edit Transponder
Edit Radio Channel Use the same procedure for the Radio Channel s as used for editing the TV Channels as above. Edit Transponder To delete a transponder, press the red key when the highlighted bar is located at the transponder you want to delete. -
Page 17: Conditional Access
Conditional Access < Viaccess Embedded > Insert the Viaccess smart card into the Smart Card slot on the Front Panel. The chip should be faced upwards. ALT Audio If more than one audio channel is provided by the broadcaster on a specific channel, you can activate the audio mode display by pressing the key. -
Page 18: Advanced Installation
C. Advanced Installation Advanced Installation You can select the “Advanced Installation” menu on the “Installation” menu of Main menu by using the Channel up/down keys (Ù,Ú). Edit/Add SAT or TP You can edit a pre-programmed satellite name and a dd a new one in this menu. Also you can edit and add Transponder Frequency p arameter by using the ×,Ø... -
Page 19: Reset (Factory Default)
Edit LNB Local Frequency You can edit up to 8 local frequencies by using numeric keys. And if you want to save newly edited frequency, press the OK key. Reset (Factory Default) If you want to reset all the data edited, press the red ke y twice. -
Page 20: Specifications
6. Specifications 1. Tuner & channel Input connector Output connector Frequency range Input impedance Signal level IF frequency IF bandwidth LNB power & polarization Vertical 22kHz tone Demodulation Input symbol rate FEC decoder 2. MPEG transport stream A/V decoding Transport stream Profile &... - Page 21 4. A/V & data in/out SCART RGB video out CVBS video out 0/12V out Analog audio out Data interface 5. Conditional Access Embedded Viaccess 6. RF-Modulator RF-connect Output frequency Output channel TV standard 7. Power supply AC power switch Input voltage Type Power consumption Protection...
