Ghent FPM1M164 Series Instruction Sheet

Fixed Partition (FPM1M1)
Instruction Sheet

Step 1: Remove and unpack carton contents.

(1)
Whiteboard

Step 2: Install the glides and end caps.

Step 3: Install bracket onto legs using 10-32 x 1-1/4" screws, thread screws into bracket. Do not tighten.
Step 4: Using a table (6) feet or more in length, organize the legs and cross brace as shown below,
hand tighten 10-24 x 1" screws with acorn nuts.
Acorn nut
10-24 x 1" Screw
www.ghent.com/install - Lebanon, OH 800-543-0550
(1)
Vinyl Board
(1)
(2)
Cross Brace
Leg
A
(6)
(2)
End cap
Bracket
10-24 x 1-1/2"
(2)
(4)
Acorn nut
Glide
10-24
DETAIL A
SCALE 1 : 5
(2)
10-24 x 1"
(4)
10-32 x 1-1/4"
(8)
IS-FPM1M1 (3/20)
(PAGE 1 OF 2)
