RVM74TOP175
Full Back Tilting Flat Panel Mount
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D' INSTRUCTIONS
!
CAUTION:
THE MAXIMUM LOADING WEIGHT IS
175LBS. USE WITH PRODUCTS HEAVIER THAN THE
MAXIMUM WEIGHT INDICATED MAY RESULT IN
INSTABILITY AND POSSIBLE PERSONAL INJURY.
Max Screen Size: 90"
V1
V1
P1
Advertisement
Related Manuals for Rapid video mounts RVM74TOP175
Summary of Contents for Rapid video mounts RVM74TOP175
- Page 1 RVM74TOP175 Full Back Tilting Flat Panel Mount INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES MANUEL D’ INSTRUCTIONS CAUTION: THE MAXIMUM LOADING WEIGHT IS 175LBS. USE WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHT INDICATED MAY RESULT IN INSTABILITY AND POSSIBLE PERSONAL INJURY. Max Screen Size: 90”...
-
Page 2: Tools Needed
Tampoco prevé todas las posibles contingencias relacionadas con la instalación o el uso de este producto. La información que contiene este documento queda sujeta a cambio sin aviso previo o compromiso alguno. RAPID VIDEO MOUNTS no ofrece ninguna garantía, ni expresa ni implícita, respecto de la información aquí incluida. RAPID VIDEO MOUNTS no se responsabiliza de la precisión de la información provista en este documento, ni tampoco de que sea completa o suficiente. - Page 3 HARDWARE PRODUCT NUMBERS M4 x 12 M5 x 12 M6 x 15 M8 x 15 M4 x 25 M5 x 25 M6 x 25 M8 x 25 SQUARE WASHER SPACER STEEL WASHER STEEL WASHER 8 mm LAG ANCHOR BOLT PRODUCT COMPONENT PARTS Flat Panel Mounting Pattern (W x H) Minimum: 100mm x 100mm Maximum: 700mm x 450mm...
- Page 4 STEP 1A - FLAT BACK FLAT PANEL (VERTICAL RAILS) Connect Vertical Rails to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur STEP 1B - CURVED BACK FLAT PANEL (VERTICAL RAILS) Connect Vertical Rails to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Spacers can also be used to provide clearance for cables...
- Page 5 STEP 1C- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT ARE TOO LONG Diagrams show three options for using additional washers if hardware screws are too long to properly tighten into back of flat panel television.
- Page 6 STEP 2- WOOD STUD INSTALLATION (CONCRETE INSTALLATION SKIP TO STEP 3) STEP 2- CENTER UNIVERSAL MONITOR PLATE Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro. Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre. LEVEL WALL PLATE WITH INCLUDED BUBBLE LEVEL AND...
- Page 7 STEP 2C- MOUNT WALL PLATE TO WALL Mount wall plate Coloque la placa de pared Montez la plaque murale Works with 16” or 24” stud spacing.
- Page 8 STEP 3 – SOLID CONCRETE INSTALLATION Use wall plate to mark mounting locations/ drill pilot holes Use la placa de pared para marcar el lugar donde se realizará la instalación Utilisez la plaque murale pour marquer l'emplacement de montage Level Solid Concrete Drill Bit Drill Pilot Hole...
- Page 9 STEP 3C- SOLID CONCRETE INSTALLATION. Mount wall plate Coloque la placa de pared Montez la plaque murale Insert wall Anchors gently into concrete wall with hammer if necessary Hammer...
- Page 10 STEP 4A- ATTACH PANELTO WALL PLATE & ADJUST TILT ANGLE Hang vertical rails with monitor attached Tilt Cuelgue con el monitor adherido. -3°~12° Accrochez avec le moniteur installé. Pull spring lock Rotate lever cord down and clockwise gently push to hold bottom of panel desired tilt to wall and...
- Page 11 STEP 4C- ADDITIONAL SECURITY FEATURE (OPTIONAL) Option Opcione Option Vertical Rails Flat Panel Wall Plate Vertical Rails have 7mm hole located at the bottom for placement of pad lock for additional theft) security (pad lock not included)
-
Page 12: Warranty Information
Esta garantía se aplica a los residentes de los Estados Unidos que realizaron la compra en un distribuidor autorizado de RAPID VIDEO MOUNTS. Esta garantía cubre los productos RAPID VIDEO MOUNTS de los defectos de materiales y de mano de obra por un periodo de 5 años. RAPID VIDEO MOUNTS, a su exclusivo criterio, reparará o reemplazará...
