Page 9
PHOTO EYES Amazing Gates strongly recommends the use, AT LEAST, of two sets of photo eye controls (A and B below) to prevent the gate from closing on a person, pet, vehicle or inanimate object. Photo eyes A and B are only active when the gate is standing open or during the closing cycle.
Page 10
IR-3000G PHOTO EYE PAIRED WITH AGA GATE OPERATORS Here are two configur- ations for using two sets of photo- eyes as "auto- BEAM reversing" controls. 3' to 4' landscaping timbers make TRANSMITTERS good mounting posts. Set the photo-eyes about 16" above grade.
Page 11
PULL ARM Steel plate 127x117x8mm The Amazing gates post attachment arm does not require Bolt M12x150 drilling of the post to be installed. You simply set into position and bolt it tight. The angle in pre set.
Page 12
With the purchase of a Full Gate System (Gate, post & Steel plate 127x127x5mm AMAZING GATES swing operator) you will receive the Amazing Gates pre- assembled pull or push arm, if this is the case you will not Steel tube 50x50x3mm...
Page 15
Amazing Gates of America Instructions for attaching finials Encircle inside the base of the finial (spear, ball or flat cap) with a continuous bead of silicone. Note: Only a small amount of silicone is needed. Excess may form at the base when fitted over the picket.
