Safety, Warranty, and Setup Guide
Brief user notices
ThinkPad A475
Unpack
®
ThinkPad computer
Initial setup
1.
Install the battery.
2.
Connect the power cord to the ac power adapter
connector . If your computer is shipped with a USB-C
USB-C connector . Then connect the power cord to a properly grounded ac power outlet
Ensure that all power cord connectors are securely and completely plugged into receptacles.
3.
Press the power button to turn on the computer. Then follow the on-screen instructions to complete
the initial setup.
Accessing your User Guide
Your User Guide contains detailed information about your computer.
To access your User Guide, do the following:
Windows 10:
1. Open the Start menu and then click Lenovo Vantage.
2. Expand Health & Support and then click User Guide.
Windows 7:
1. From the Windows desktop, click Start and then click Help and
Support. The Windows Help and Support window opens.
2. Click Lenovo User Guide.
Lenovo makes constant improvements to the User Guide of your
computer. To ensure that you have the up-to-date information of
your computer, see "Downloading publications" for information
about downloading the latest User Guide.
Downloading publications
Electronic versions of your computer publications are available from
the Lenovo Support Web site. To download the publications for your
computer, go to:
https://support.lenovo.com
Read this documentation before using your
computer
This documentation provides critical safety and regulatory
information for Lenovo computers.
Safety information
Plastic bag notice
DANGER
Plastic bags can be dangerous. Keep plastic bags away
from babies and children to avoid danger of suffocation.
General battery notice
DANGER
Batteries supplied by Lenovo for use with your product
have been tested for compatibility and should only be
replaced with approved parts. A battery other than the one
specified by Lenovo, or a disassembled or modified
battery is not covered by the warranty.
Battery abuse or mishandling can cause overheat, liquid
leakage, or an explosion. To avoid possible injury, do the
following:
•
Do not open, dissemble, or service any battery.
•
Do not crush or puncture the battery.
•
Do not short-circuit the battery, or expose it to water or
other liquids.
•
Keep the battery away from children.
•
Keep the battery away from fire.
Stop using the battery if it is damaged, or if you notice any
discharge or the buildup of foreign materials on the
battery leads.
Store the rechargeable batteries or products containing
the rechargeable batteries at room temperature, charged
Battery
This system supports only batteries specially designed
for this specific system and manufactured by Lenovo
an authorized builder. The system does not support
unauthorized batteries or batteries designed for other
systems. If an unauthorized battery or a battery
designed for another system is installed, the system will
not charge.
Attention: Lenovo has no responsibility for the
performance or safety of unauthorized batteries, and
provides no warranties for failures or damage arising out
of their use.
. Connect the ac power adapter to the power
TM
type adapter, connect the adapter to the
to approximately 30% to 50% of capacity. We recommend
that the batteries be charged about once per year to
prevent overdischarge.
Do not put the battery in trash that is disposed of in
landfills. When disposing of the battery, comply with local
ordinances or regulations.
Notice for removable rechargeable battery
DANGER
Only recharge the battery strictly according to instructions
included in the product documentation.
If the battery is incorrectly replaced, there is danger of an
explosion. The battery contains a small amount of harmful
substances.
Notice for built-in rechargeable battery
DANGER
Do not attempt to remove or replace the built-in
rechargeable battery. Replacement of the battery must be
done by a Lenovo-authorized repair facility or technician.
Only recharge the battery strictly according to instructions
included in the product documentation.
The Lenovo-authorized repair facilities or technicians
recycle Lenovo batteries according to local laws and
regulations.
Notice for non-rechargeable coin-cell battery
DANGER
If the coin-cell battery is incorrectly replaced, there is
danger of an explosion. The battery contains a small amount
of harmful substances.
Do not heat to more than 100°C (212°F).
The following statement applies to users in the state of
California, U.S.A.
California Perchlorate Information:
Products containing manganese dioxide lithium coin-cell
batteries may contain perchlorate.
Perchlorate Material - special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Using headphones or earphones
CAUTION:
Excessive sound pressure from earphones and headphones
can cause hearing loss. Adjustment of the equalizer to
maximum increases the earphone and headphone output
voltage and the sound pressure level. Therefore, to protect
your hearing, adjust the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of
time at high volume can be dangerous if the output of the
headphone or earphone connectors do not comply with
specifications of EN 50332-2. The headphone output connector of
your computer complies with EN 50332-2 Sub clause 7. This
specification limits the computer's maximum wide band true RMS
output voltage to 150 mV. To help protect against hearing loss,
ensure that the headphones or earphones you use also comply with
EN 50332-2 (Clause 7 Limits) or a wide band characteristic voltage
of 75 mV. Using headphones that do not comply with EN 50332-2
can be dangerous due to excessive sound pressure levels.
If your Lenovo computer came with headphones or earphones in
the package, as a set, the combination of the headphones or
earphones and the computer already complies with the
specifications of EN 50332-1. If different headphones or earphones
are used, ensure that they comply with EN 50332-1 (Clause 6.5
Key Web resources
Lenovo support: https://support.lenovo.com
Lenovo user forums: https://forums.lenovo.com
Power cord and ac power adapter
Controls and indicators
Microphones
Camera＊
®
or
Screen (multi-touch/non-touch)
Power button
Fingerprint reader＊
®
TrackPoint buttons
ThinkPad trackpad
TrackPoint pointing stick
CapsLock key with the CapsLock indicator
Esc key with the Fn Lock indicator
.
F1 key with the speaker mute indicator
F4 key with the microphone mute indicator
＊
Available on some models.
Recovery information
Your computer might not come with a Windows
Windows operating system, see the recovery information in the User Guide. See "Accessing your User
Guide" later in this document for additional information.
Limitation Values). Using headphones that do not comply with EN
50332-1 can be dangerous due to excessive sound pressure levels.
Service, support, and warranty information
The following information describes the technical support that is
available for your product during the warranty period and
throughout the life of your product. Online technical support is
available during the lifetime of a product at
https://support.lenovo.com.
If you purchased Lenovo services, refer to the following terms and
conditions for detailed information:
•
For Lenovo Warranty Service Upgrades or Extensions, go to:
https://support.lenovo.com/lwsu
•
For Lenovo Accidental Damage Protection Services, go to:
https://support.lenovo.com/ladps
Warranty information
Lenovo provides a warranty period for your computer. To check the
warranty status of your computer, go to
https://www.lenovo.com/warranty-status, and then follow the
instructions on the screen.
Your computer is covered by the terms of the Lenovo Limited
Warranty (LLW), version L505-0010-02 08/2011. The LLW is
displayed on your computer during the initial setup. If you cannot
view the LLW either from your computer or from the Web site
(https://www.lenovo.com/warranty/llw_02), contact your local
Lenovo office or reseller to obtain a printed version.
After the initial setup has been completed, you can view the
warranty information from your computer by doing the following:
Windows 10:
1. Open the Start menu and then click Lenovo Vantage.
2. Expand Health & Support and then click Warranty & Service.
Windows 7:
From the Windows desktop, click Start → All Programs → Lenovo
PC Experience → Warranty Information.
Customer Replaceable Units
Customer Replaceable Units (CRUs) are parts that can be
upgraded or replaced by the customer. To view the instructions on
replacing the CRUs, see the respective section in the User Guide.
See "Accessing your User Guide" for additional information.
For the CRU information of your computer, refer to the following list.
Self-service CRUs
•
ac power adapter and power cord
•
Removable battery
•
Base cover assembly
•
Coin-cell battery
•
Internal storage drive
•
Internal storage drive cable
Optional-service CRUs
•
Keyboard
•
Memory module
•
Wireless LAN card
•
Wireless WAN card*
* Available on some models.
Worldwide telephone technical support
This section lists Lenovo Support telephone numbers. If you cannot
find the support telephone number for your country or region,
contact your Lenovo reseller or Lenovo marketing representative.
Before contacting a Lenovo technical support representative, have
the following information available: model and serial number, the
exact wording of any error message, and a description of the
problem.
Third Edition (August 2018)
© Copyright Lenovo 2017, 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration "GSA" contract, use,
reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
PN: SP40Q51907
Printed in China
Lenovo USB-C to VGA adapter
Documentation
(available on some models)
®
recovery disc set or USB key. To restore the Microsoft
Important: Telephone numbers are subject to change without
notice. The most up-to-date telephone list for the Customer
Support Center is always available at:
https://pcsupport.lenovo.com/supportphonelist
Country or Telephone number
region
Algeria 33-6-7348 1739 (French, Spanish)
Anguilla 1-800-426-7378 (English)
Antigua and 1-800-426-7378 (English)
Barbuda
Argentina 0800-666-0011
(Spanish, English)
Armenia 374 11300300
374 10586048
(Standard charges apply)
(Russian, English)
Australia 1-800-043-849 (English)
Austria 0810-100-654 (German)
Bahamas 1-800-426-7378 (English)
Bahrain Kanoo IT: 00-973-1771-1722
Bahrain Business Machine LLC:
00-973-1758-4302
(Arabic, English)
Bangladesh AWSP Flora Limited:
70-200-6853 88-0171-000-0000 (Mobile)
Email: hasan_reaz@globalbrand.com.bd
Barbados 02-339-36-11 (Warranty service and support)
(Dutch, French)
1-800-426-7378 (English)
Belarus 375296885522 (Standard charges apply)
(Russian, English)
Bermuda 1-800-426-7378 (English)
Bolivia 0800-10-0189 (Spanish)
Bosnia and 387 (0)33 563-150 (Bosnian)
Herzegovina
Brazil Calls made from within the Sao Paulo region:
0800-885-0500
Calls made from outside the Sao Paulo
region: 0800-701-4815
(Portuguese)
Brunei 801-4440 (Malay, English)
Darussalam
Canada 1-800-565-3344 (English, French)
Cayman Islands 1-800-426-7378 (English)
Chile 800-361-213 (Spanish)
Colombia 01-800-912-3021
(Spanish)
Costa Rica 0-800-011-1029 (Spanish)
Croatia 30-32736 (Croatian)
Cyprus 357-227-11300 (Greek)
Czech Republic 800-353-637 (Czech)
Denmark 7010-5150 (Warranty service and support)
(Danish)
Dominica 1-800-426-7378
Dominican 1-866-434-2080 (Spanish)
Republic
Ecuador 1800 000 661 (Spanish)
El Salvador 800-6264 (English)
Egypt Primary: 0800-0000-850 Secondary: 0800-
0000-744
Estonia 372-66-00-800
(Estonian, Russian, English)
Finland 0974790251 and then press 3 (Finnish)
France (0)1.70.38.19.27 (Warranty service and
support) (French)
Georgia 99 5322945439 (Russian, English)
Germany 0800-500-4618 (Toll Free)
®
