Now, it is time to place the arm to arm Intermediate
Kevlar Support cords as shown in fig.9
Support Cords are mounted between
the two arms in front of the beam.
Front of beam
VHQ BEAM ORIENTATION
Note: Coax Standoffs are on
the back of the beam
Fig.9
