KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS
Key Features
• Generation Four (G4) Digital Control Module – provides precise control over all aspects of brewing: time,
temperature, volume plus specialty coffee needs from pre-infusion to pulse-brewing to water bypass. Large,
4.3" touch screen with icon-driven interface, streamlines operation. On-screen instructions provide fast,
intuitive training; reduces service calls.
• Built-in Self Diagnostic System – Includes real-time feedback of the brewing process and energy saving mode.
• Field selectable for 0.5, 1.0 or 1.5 gal. (1.9, 3.8 or 5.7 L) batch brewing.
• IntelliFresh ® Technology – Temperature and time information follows the satellite.
• LED noti cation of freshness timing.
• Industry's most effective mineral tolerant design.
Speci cations (Selected Models)
Electrical Supply Requirements
MODEL # DESCRIPTION
Single, 1.5 Gal. with IntelliFresh,
G4GEMXN63x
Narrow
Single, 1.5 Gal. with IntelliFresh,
G4GEMXN3x
Narrow
Dimensions
MODEL # HEIGHT
G4GEMXN63x
34.48"
G4GEMXN3x
[87.6 cm]
Following are the factory default settings for the IntelliFresh brewer:
• Brew Temperature = 200°F [92°C]
• Water Bypass = On LARGE and MEDIUM brew only
• Brew Volume = Large-Medium-Small
G4GEMXN, KEY FEATURES/SPECS/SYSTEM REQUIREMENTS
PHASE VOLTS
1 PH 120/220 V
1 PH 220-240V
WIDTH DEPTH SHIP WEIGHT
10.50" 26.44" 59.5 lb.
[26.7 cm] [67.2 cm] [37.0 kg]
HEATING
AMPS WIRE
CONFIG
13.5/13.5 A 2 X 1600 W 2W/3W + G
2W + G
11.9-13.0A 1 X 2500 W
(1/N/PE)
Water Supply Requirements
SHIP CUBE WATER CONNECTOR
5.54 cu. ft.
3/8" are
3
[0.16 m ]
• Energy Save Mode = Off
• Quality Timer = 120 Minutes
• Warmer Auto-Off = 18 Hours
FS109
WATTS HERTZ CAPACITY
4.5/10.0 gal./hr.
1650/2800 W 50/60 Hz
[17.0/37.9 L/hr.]
9.0 gal./hr.
2624-3122 W 50/60 Hz
[34.1 L/hr.]
WATER PRESSURE MIN. FLOW RATE
20 - 90 psi 1.0 gpm
[138 - 620 kPa] [3.8 Lpm]
080321B
