PRODUCT LITERATURE
Lennox Industries Inc.
Dallas, Texas
INSTALLATION
INSTRUCTIONS
GCWB95F-150
CONDENSING
GAS BOILER
RETAIN THESE INSTRUCTIONS
FUTURE REFERENCE
These instructions must be affixed
on or adjacent to the boiler.
WARNING
Improper installation, adjustment, alteration,
service, or maintenance could result in death
or serious injury. Refer to this manual for
assistance. For additional information consult
a qualified installer, service agency, or the gas
supplier.
GAS-FIRED HOT WATER BOILERS
These Gas-Fired Water boilers are low pressure, Design
Certified by CSA (Canadian Standards Association) for use
with Natural and Propane Gases. They are constructed
and hydrostatically tested for a maximum working pressure
of 50 psi (pounds per square inch) in accordance with
A.S.M.E. (American Society of Mechanical Engineers)
Boiler and Pressure Vessel Code Section IV Standards
for Heating Boilers.
FOR
240012999 Rev. A [08/31/2020]
