- Page 1 INSTRUCTION MANUAL Cordless Lawn Mower DLM465 DLM534 DLM536 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: DLM465 DLM534 DLM536 Mowing width (blade diameter) 460 mm 534 mm No load speed Normal mode 3,300 min 2,800 min Noise reduction mode 2,500 min 2,300 min Part number of replacement Straight mower blade 191D51-9 191D52-7 mower blade... -
Page 3: Safety Warnings
Check the blades or blade bolts carefully for SAFETY WARNINGS cracks or damage before operation. Replace cracked or damaged blades or blade bolts immediately. IMPORTANT SAFETY INSTRUCTIONS Remove foreign matters such as rocks, wire, bottles, bones and large sticks from the work WARNING: area before mowing to prevent personal injury Read all safety warnings and all... - Page 4 13. Do not tilt the mower when switching on the 30. Avoid working in poor environment where motor, except if the mower has to be tilted for increased user fatigue is expected. starting. In this case, do not tilt it more than 31.
- Page 5 16. Perform inspection or maintenance in a place If the battery cartridge gets wet, drain the where rain can be avoided. water inside and then wipe it with a dry cloth. Dry the battery cartridge completely in a dry 17. After using the machine, remove the adhered place before use.
-
Page 6: Installing The Handle
Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. ► 1 . Lower handle 2. Bolt Tips for maintaining maximum... -
Page 7: Removing The Mulching Plug
CAUTION: Hold the upper handle firmly so that it does not drop off your hand. Otherwise, the handle may fall and cause an injury. Attach the holders to the handle. Align the protrusions on the holder with the holes on the handle so that the protrusions fit in the holes. Position the cords as shown in the figure. ► 1 . Cord 2. Holder ► 1 . - Page 8 ► 1 . Lever 2. Mulching plug Attaching the discharge attachment ► 1 . Rear cover For DLM534/DLM536 Hold the handle of the grass basket, and then Open the rear cover, and then remove the grass hook the grass basket on the rod of the mower body as basket.
-
Page 9: Functional Description
Open the right side cover, and then attach the To install the battery cartridge; discharge attachment. Pull up the locking lever, and then open the battery Insert the hooks of the discharge attachment under the cover. rod of the right side cover. ► 1 . -
Page 10: Overload Protection
To remove the battery cartridge; Indicating the remaining battery Pull up the locking lever and open the battery cover. capacity Pull out the battery cartridge from the machine while sliding the button on the front of the cartridge. Only for battery cartridges with the indicator Pull out the lock key. -
Page 11: Control Panel
If you notice anything unusual with either of the pulled for a certain period after the main power switch lock key or switch, stop the operation immediately and is turned on. have them checked by your nearest Makita Authorized Service Center. Mode switching button For DLM465/DLM536 You can switch the operating mode by pressing the Install the battery cartridges. -
Page 12: Adjusting The Mowing Height
Release the drive lever and the switch lever to stop the machine. For DLM534 Install the battery cartridges. Insert the lock key, and then close the battery cover. Select the battery cartridges used for operation by turning the battery selection switch. -
Page 13: Adjusting The Handle Height
The table below shows the relationship between the number When the grass basket is almost full, the indicator does on the mower body and the approximate mowing height. not float while the blades are running. In this case, stop the operation immediately and empty the basket. Number Mowing height 20 mm 26 mm 32 mm 39 mm... -
Page 14: Electronic Function
Electric brake This machine is equipped with an electric brake. If the machine consistently fails to quickly stop the mower blades after releasing the switch lever, have the machine serviced at Makita Authorized Service Center. OPERATION ► 1 . Speed lever The traveling speed can be adjusted with the speed lever. -
Page 15: Emptying The Grass Basket
Release the switch lever and drive lever (for DLM465/DLM536), or release the switch lever (for DLM534). Remove the lock key. Open the rear cover and take out the grass basket ► 1 . Mowing width 2. Overlapping area 3. Center line by holding the handle. -
Page 16: Maintenance
Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Maintenance Remove the lock key and battery cartridges, and then close the battery cover. - Page 17 Removing the mower blade For models equipped with swing back mower blades For models equipped with straight mower Put the mower on its side so that the mowing blade height adjusting lever comes to the upper side. Put the mower on its side so that the mowing To lock the base plate, insert the pin supplied with height adjusting lever comes to the upper side.
- Page 18 To remove the individual mower blade, turn the NOTICE: When tightening the nuts to install the bolt counterclockwise with box wrench 17 while holding individual mower blades, apply 30 N•m as tighten- the base plate. ing torque. NOTICE: When installing the individual mower blade, be sure to attach the spring washer in the direction as shown in the figure.
-
Page 19: Troubleshooting
TROUBLESHOOTING Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to disassemble the machine. Instead, ask Makita Authorized Service Centers, always using Makita replacement parts for repairs. State of abnormality Probable cause (malfunction) Remedy Mower does not start. Two battery cartridges are not installed. Install two charged battery cartridges. - Page 20 Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885847-924 www.makita.com 20200720...
