The Mircom Digital Communicator is configured by connecting the CFG-100 Configuration Tool to P4 of the DACT-100A or
UDACT-100A Main Board. Once connected, if no text appears immediately on the LCD screen, hit any key on the numeric
keypad.
The UDACT product supports two levels of restricted access to the Configuration Mode which allows for parameter
configuration and control of operation. Each level is associated with a separate Passcode (up to 8-digit numeric code) and may
be individually modified. Once a user gains access to the Configuration Mode, they are presented with a menu of selections
according to the level of access granted. The factory default Passcodes are:
Level I - OPERATOR
Level II - INSTALLER
A Restore-to-Factory-Defaults can be initiated from the CFG-100 without having to first access program mode, by using the
special Passcode ...
Restore-to-Factory-Defaults
NOTE: When reviewing the configuration (account numbers, etc.) DO NOT hit the # key, use the * key to exit. Hitting the # key
when reviewing the configuration will delete the existing data. This "deleting" feature is required when entries need to be
removed; example 1-800 number changed to a local number.
Items accessible to Level(s) I and II
ITEM Access Menu Category
Number Level
00 I, II Access Control
01 I, II Access Control
02 I, II Access Control
10 I, II Event Logging
11 I, II Event Logging
12 I, II Event Logging
13 I, II Event Logging
14 II Zone Mapping
15 II Zone Mapping
16 II Zone Mapping
20 I, II RTC
Parameters
21 I, II RTC
Parameters
22 I, II RTC
Parameters
SYSTEM CONFIGURATION & OPERATION
"11111111"
"22222222"
"12345678" (Do Not use this passcode as a Level I or Level II passcode)
Menu Label
Logout of DACT/UDACT
About DACT/UDACT
Change Passcode
Flush all events
Send Test-Report
Abort-Reporting
AC-Power Loss (delay)
Default is 6 Hours
View
Edit Mapping
Mapping Enable
Set System DATE
Set System TIME
Auto-Report Time
Page 1
Description
Exit from PROGRAM mode on LCD/Keypad.
Display copyright (company and date) and firmware version
information on LCD.
Support modification to specific passcode associated with
individual level (I=OPERATOR and II=INSTALLER).
Terminate any in-progress event reporting.
Remove "report pending" trigger (i.e. cancel attempts to report
queued events) and
Force event queue (FIFO) to empty state (i.e. erase any queued
event history).
Immediately initiate test-report generated to Account #1.
Terminate any in-progress event reporting.
Remove "report pending" trigger (i.e. cancel attempts to report
queued events).
NOTE: Unreported events are still resident within FIFO. Any
future events logged will restart attempts at reporting ALL
queued (unreported) event items. This action will also add a
"Line (x) Trouble" event to the event queue.
Specify an (optional) delay time (in hours), from 00 (no delay) to
20 (maximum delay). A report of the "AC-Power Loss" event will
be delayed by this value, and then only sent after the period has
expired with the signal still present. A "restoral" event of this
signal will be reported immediately, but only if a prior "off-
normal" event was successfully reported earlier.
View zone mapping. UDACT ONLY
Edit zone mapping. UDACT ONLY
1=DISABLE (default), 2= ENABLE
Assign local DATE (dd/mm/yy) to UDACT Real-Time-Clock
device. The Year field will be presented in 4-digit format on LCD
status line, with automatic 20/21 century adjustment for Y2K
compliance.
Assign local TIME (ss/mm/hh) to DACT/UDACT Real-Time-
Clock device. The Hour field will be presented in 24-hour
(military) format on LCD status line.
Assign time (mm/hh) for DACT/UDACT to perform periodic (24
hr intervals) Test-report generation to monitoring station. Must
set real time clock (Item 21) to ensure 24 hr test will initialize.
UDACT ONLY
