CAYMON PSR429 Series Quick Start Manual

PSR429 series
Power distribution unit
Quick Start Guide
The quick start guide gives you an overview of all the front and rear controls and
connections on the PSR429 series. It allows you to get started with the installation of
it in your project.

Front:

1
1) USB charger
The two USB type A connectors offer
the possibility to charge various devices
such as smartphones, tablets or similar
devices. It is not designed for plugging in
USB memory devices.
2) Power button LED light
Switches the LED light ON or OFF
3
2
4
3) LED dimmer
The LED light can be dimmed by turning
the dial.
4) Circuit breaker
If a short-circuit occurs, the circuit
breaker will automatically switch over.
5
4
