Force P-50 Instruction Manual

a full body harness (conforming to EN 361) is the only acceptable body holding device that can be used, in a fall arrest system.
·
in full body harness use only attaching points marked with big letter "A" to attach a fall arrest system.
·
the anchor device or anchor point for the fall arrest system should always be positioned, and the work carried out in such a way, as to
·
minimise both the potential for falls and potential fall distance. The anchor device/point should be placed above the position of the user .
The shape and construction of the anchor device/point shall not allowed to self-acting disconnection of the equipment. Minimal static
strength of the anchor device/point is 12 kN. It is recommended to use certified and marked structural anchor point complied with EN795
it is obligatory to verify the free space required beneath the user at the workplace before each occasion of use the fall arrest system, so
·
that, in the case of a fall, there will be no collision with the ground or other obstacle in the fall path. The required value of the free space
should be taken from instruction manual of used equipment.
there are many hazards that may affect the performance of the equipment and corresponding safety precautions that have to be
·
observed during equipment utilization, especially: - trailing or looping of lanyards or lifelines over sharp edges, - any defects like cutting,
abrasion, corrosion, - climatic exposure, - pendulum falls, - extremes of temperature, - chemical reagents, - electrical conductivity.
personal protective equipment must be transported in the package (e.g.: bag made of moisture-proof textile or foil bag or cases made of
·
steel or plastic) to protect it against damage or moisture.
the equipment can be cleaned without causing adverse effect on the materials in the manufacture of the equipment. For textile products
·
use mild detergents for delicate fabrics, wash by hand or in a machine and rinse in water. Plastic parts can be cleaned only with water.
When the equipment becomes wet, either from being in use or when due cleaning, it shall be allowed to dry naturally, and shall be kept
away from direct heat. In metallic products some mechanic parts (spring, pin, hinge, etc.) can be regularly slightly lubricated to ensure
better operation. Other maintenance and cleaning procedures should be adhered to detailed instructions stated in the manual of the
equipment.
personal protective equipment should be stored loosely packed, in a well-ventilated place, protected from direct light, ultraviolet
·
degradation, damp environment, sharp edges, extreme temperatures and corrosive or aggressive substances.
IT IS THE RESPONSIBILITY OF THE USER ORGANISATION TO PROVIDE THE IDENTITY CARD AND TO FILL IN THE DETAILS REQUIRED. THE
IDENTITY CARD SHOULD BE FILLED IN BEFORE THE FIRST USE BY A COMPETENT PERSON, RESPONSIBLE INTHE USER ORGANIZATION FOR
PROTECTIVE EQUIPMENT. ANY INFORMATION ABOUT THE EQUIPMENT LIKE PERIODIC INSPECTIONS, REPAIRS, REASONS OF
EQUIPMENT'S WITHDRAWN FROM USE SHALL BE NOTED INTO THE IDENTITY CARD BY A COMPETENT PERSON. THE IDENTITY CARD
SHOULD BE STORAGED DURING A WHOLE PERIOD OF EQUIPMENT UTILIZATION. DO NOT USE THE EQUIPMENT WITHOUT THE IDENTITY
CARD. ALL RECORDS IN THE IDENTITY CARD CAN BE FILLED IN ONLY BY A COMPETENT PERSON.
IDENTITY CARD
MODEL AND TYPE OF EQUIPMENT
SERIAL NUMBER
USER NAME
DATE OF PURCHASE
PERIODIC EXAMINATION AND REPAIR HISTORY
REASON FOR
DATE
ENTRY PERIODIC EXAMINATION
OR REPAIR AND OTHER REVELANT INFORMATIONS
1
2
3
4
5
6
SafetyLiftinGear.com
Unit R1D Rockingham Gate Poplar Way
West Cabot Park Bristol BS11 0YW
Tel: 0808 123 69 69 Fax: 0117 9381 602
sales@safetyliftingear.com
REF. NUMBER
DATE OF MANUF.
DATE OF PUTTING
INTO OPERATION
DEFECTS NOTED, NAME AND SIGNATURE
REPAIRS CARRIED OUT OF COMPETENT PERSON
Notified body, at which the European certification was Iissued
and which supervises the production of the equipment:
APAVE SUDEUROPE SAS - 8 rue Jean-Jacques Vernazza -
CS-60193 – 13322 MARSEILLE Cedex 16, France - No. 0082
PRODUCENT: PROTEKT, 93-403 LODZ, ul. Starorudzka 9, POLAND,
TEL: (48 42) 680 20 83, FAX: (48 42) 680 20 93, www.protekt.com.pl
Instruction Manual
READ CAREFULLY BEFORE USE
Safety harness is the basic element of fall arrest equipment. The harness
complies with EN 361 (as a full body harness), EN 358 (as a work positioning
belt) - the maximum load of the sit harness is 140 kg.
DESCRIPTION
Full body harness is made of polyester webbings which are sewn and
connected by metal buckles.
This configuration guarantee full safety and comfort work.
BASIC EQUIPMENT
back attaching buckle - for attaching fall arrest system;
!
front attaching loops - for attaching fall arrest system;
!
connecting and adjusting buckles - for comfort wearing and using of harness;
!
work positioning belt.
!
SIZES
The harness is manufactured in two sizes:
- universal: M-XL
- extra large: XXL
Periodic inspections
The safety harness must be inspected at least once every 12 months from
the date of first use.
Periodic inspections must only be carried out by a competent person who
has the knowledge and training required for personal protective equipment
periodic inspections. Depending upon the type and environment of work,
inspections may be needed to be carried out more frequently than once
every 12 months. Every periodic inspection must be recorded in the Identity
Card of the equipment.
Maximum lifespan of the equipment
The maximum lifespan of the harness is 10 years from the date of
manufacture.
The harness must be withdrawn from use immediately and destroyed when it
has been used to arrest a fall or
doubt as to its reliability.
ATTENTION: The harness maximum lifetime depends on the intensity of
usage and the environment of usage. Using theharness in rough
environment, marine environment, contact with sharp edges, exposure to
extreme temperatures or agressive substances, etc. can lead to the
wthdrawal from use even after one use.
PERIODIC
EXAMINATION
HARNESS MARKING
NEXT DUE DATE
Model symbol
Device type
Reference number
Harness size
Month and year of manufacture
Serial number of the harness
Maximal weight of user
Number/year European standards
CE mark and number of the notified body
controlling manufacturing of the equipment
Caution: read and understand the
instruction manual before use
Identification of the harness
manufacturer or distributor
SAFETY
THE EQUIPMENT
HARNESS
EN 361:2002
EN 358:1999 Ref.: AB 150 01
shoulder strap
adjusting
buckle
of the shoulder
strap
thigh strap
connecting
and adjusting
buckle
of the thigh strap
it fails to pass inspection or there are any
back attaching
buckle for attaching
P-50
fall arrest system
SAFETY HARNESS
Ref. AB 150 01
Size: M-XL
identity label
XXL
Date
of manufacture: 03/2018
work
positioning
Serial
belt
number: 0000001
EN 361:2002
EN 358:1999
P-50
front view
connecting
and adjusting
plastic clip
of the chest
strap
front attaching loops
for attaching
fall arrest
system
side buckles
for attaching
work
positioning
system
back view
lenghtening element
of the back attaching buckle
for attaching
fall arrest system
