PCB Piezotronics ICP 261A03 Installation And Operating Manual page 11

Model Number
261A03
Performance
Sensitivity(± 20 %)(z axis)
Sensitivity(± 20 %)(x or y axis)
Measurement Range(z axis)
Measurement Range(x or y axis)
Maximum Force(z axis)
Maximum Force(x or y axis)
Maximum Moment(z axis)
Maximum Moment(x or y axis)
Broadband Resolution(x or y axis)
Broadband Resolution(x or y axis)
Upper Frequency Limit
Low Frequency Response(-5 %)(z-axis)
Low Frequency Response(-5 %)(x or y axis)
Non-Linearity
Cross Talk(between x and y axis)
Cross Talk(between (x or y axis) and z axis)
Environmental
Temperature Range
Electrical
Full Scale Output(Z Direction)
Full Scale Output(X and Y Direction)
Discharge Time Constant(z axis)
Discharge Time Constant(x or y axis)
Excitation Voltage(all channels)
Constant Current Excitation(all channels)
Output Impedance
Output Bias Voltage
Spectral Noise(1 Hz)(X & Y)
Spectral Noise(10 Hz)(X & Y)
Spectral Noise(100 Hz)(X & Y)
Spectral Noise(1000 Hz)(X & Y)
Spectral Noise(1 Hz)(Z)
Spectral Noise(10 Hz)(Z)
Spectral Noise(100 Hz)(Z)
Spectral Noise(1000 Hz)(Z)
Output Polarity
Physical
Stiffness(z axis)
Stiffness(x or y axis)
Size (Height x Length x Width)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
3-COMPONENT ICP® FORCE SENSOR
ENGLISH SI
0.25 mV/lb 0.06 mV/N
1.25 mV/lb 0.28 mV/N
10,000 lb 44.48 kN
4000 lb 17.79 kN
11,000 lb 48.93 kN
4400 lb 19.57 kN
240 ft-lb 325.4 Nm
325 ft-lb 440.7 Nm
0.05 lb-rms 0.222 N-rms
0.01 lb-rms 0.04 N-rms
10,000 Hz 10,000 Hz
0.01 Hz 0.01 Hz
0.001 Hz 0.001 Hz
≤ 1 % FS ≤ 1 % FS
± 3 % ± 3 %
± 5 % ± 5 %
-65 to +250 °F -54 to +121 °C
± 2.5 VDC ± 2.5 VDC
± 5 VDC ± 5 VDC
≥ 50 sec ≥ 50 sec
≥ 500 sec ≥ 500 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
0.003 lb/√Hz 0.0134 N/√Hz
0.001 lb/√Hz 0.00445 N/√Hz
0.0004 lb/√Hz 0.00178 N/√Hz
0.0001 lb/√Hz 0.000445 N/√Hz
0.02 lb/√Hz 0.089 N/√Hz
0.005 lb/√Hz 0.0222 N/√Hz
0.002 lb/√Hz 0.0089 N/√Hz
0.0005 lb/√Hz 0.00222 N/√Hz
Positive Positive
19.4 lb/µin 3.4 kN/µm
5.7 lb/µin 1.0 kN/µm
3.54 in x 3.15 in x 3.15 in 89.9 mm x 80.0 mm x 80.0 mm
96.25 oz 2994 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
4-Pin 4-Pin
Side Side
